#13392
Oldman2
nagyúr
st3v3np3t3r
#13097
Oldman2
nagyúr
válasz
st3v3np3t3r
#13097
üzenetére
App-ból
-
#13389
jonnyjoker01
veterán
jonnyjoker01
veterán
Teszt123
-
zebra_hun
veterán
-
zebra_hun
veterán
-
zebra_hun
veterán
válasz
jokeph
#13368
üzenetére
Ez az, köszi
Érdekes az 5000 warning. Nekem igaz, ki volt hegyezve a Vcore, de Y alatt sem kapott whea-t.
SFT már nem menne le, de ész nélkül nem szívesen tolom rá ha nem fontos.
Majd még tesztelgetem ezt a bench-et, nekem új. Csak szemet szúrt a hibalista.
A 13600k-d jobb a többiekétől
Köszi mégegyszer! -
válasz
zebra_hun
#13367
üzenetére
13600K, némi hangolgatással:
SiSoftware Sandra
Benchmark Results
Aggregate Inter-Thread Bandwidth : 98.62GB/s
Results Interpretation : Higher Scores mean Better Performance.
Binary Numeral System (base 2) : 1GB(/s) = 1024MB(/s), 1MB(/s) = 1024kB(/s), 1kB(/s) = 1024 bytes(/s), etc.
Benchmark Results
Average Inter-Thread Latency : 37.4ns (13.5ns - 45.9ns)
Inter-Thread (same Core) Latency : 13.8ns
Inter-Core (same Module) Latency : 33.5ns
Inter-LITTLE-cores (same Module) Latency : 44.2ns
Inter-big/LITTLE-Core (same Module) Latency : 39.4ns
Results Interpretation : Lower Scores mean Better Performance.
Decimal Numeral System (base 10) : 1s = 1000ms, 1ms = 1000µs, 1µs = 1000ns, etc.
Performance per Thread
Aggregate Inter-Thread Bandwidth : 5GB/s
No. Threads : 20
Results Interpretation : Higher Scores mean Better Performance.
Binary Numeral System (base 2) : 1GB(/s) = 1024MB(/s), 1MB(/s) = 1024kB(/s), 1kB(/s) = 1024 bytes(/s), etc.
Performance vs. Power
Processor(s) Power : 150.00W
Aggregate Inter-Thread Bandwidth : 673.22MB/s/W
Results Interpretation : Higher Scores mean Better Performance.
Average Inter-Thread Latency : 2.49ns/W
Results Interpretation : Lower Scores mean Better Performance.
Capacity vs. Power
Total Cache Size : 303.57kB/W
Results Interpretation : Higher Scores mean Better Performance.
Performance vs. Speed
Aggregate Inter-Thread Bandwidth : 18.73MB/s/MHz
Results Interpretation : Higher Scores mean Better Performance.
Average Inter-Thread Latency : 0.07ns/MHz
Results Interpretation : Lower Scores mean Better Performance.
Detailed Results
Processor Affinity : U0-U1 U2-U3 U4-U5 U6-U7 U8-U9 U10-U11 U12-U18 U13-U16 U14-U19 U15-U17
U0-C0T0 <> U2-C1T0 Data Latency : 35.3ns
U0-C0T0 <> U4-C2T0 Data Latency : 35.2ns
U0-C0T0 <> U6-C3T0 Data Latency : 35.0ns
U0-C0T0 <> U8-C4T0 Data Latency : 35.4ns
U0-C0T0 <> U10-C5T0 Data Latency : 36.1ns
U0-C0T0 <> U12-c6 Data Latency : 42.0ns
U0-C0T0 <> U13-c7 Data Latency : 41.9ns
U0-C0T0 <> U14-c8 Data Latency : 42.2ns
U0-C0T0 <> U15-c9 Data Latency : 42.0ns
U0-C0T0 <> U16-c10 Data Latency : 39.7ns
U0-C0T0 <> U17-c11 Data Latency : 40.7ns
U0-C0T0 <> U18-c12 Data Latency : 40.9ns
U0-C0T0 <> U19-c13 Data Latency : 39.8ns
U0-C0T0 <> U1-C0T1 Data Latency : 13.9ns
U0-C0T0 <> U3-C1T1 Data Latency : 35.0ns
U0-C0T0 <> U5-C2T1 Data Latency : 35.0ns
U0-C0T0 <> U7-C3T1 Data Latency : 35.3ns
U0-C0T0 <> U9-C4T1 Data Latency : 35.9ns
U0-C0T0 <> U11-C5T1 Data Latency : 36.0ns
U2-C1T0 <> U4-C2T0 Data Latency : 32.7ns
U2-C1T0 <> U6-C3T0 Data Latency : 32.7ns
U2-C1T0 <> U8-C4T0 Data Latency : 33.4ns
U2-C1T0 <> U10-C5T0 Data Latency : 33.6ns
U2-C1T0 <> U12-c6 Data Latency : 41.2ns
U2-C1T0 <> U13-c7 Data Latency : 41.2ns
U2-C1T0 <> U14-c8 Data Latency : 41.1ns
U2-C1T0 <> U15-c9 Data Latency : 41.1ns
U2-C1T0 <> U16-c10 Data Latency : 40.7ns
U2-C1T0 <> U17-c11 Data Latency : 40.6ns
U2-C1T0 <> U18-c12 Data Latency : 40.6ns
U2-C1T0 <> U19-c13 Data Latency : 40.5ns
U2-C1T0 <> U1-C0T1 Data Latency : 35.3ns
U2-C1T0 <> U3-C1T1 Data Latency : 13.7ns
U2-C1T0 <> U5-C2T1 Data Latency : 32.5ns
U2-C1T0 <> U7-C3T1 Data Latency : 32.9ns
U2-C1T0 <> U9-C4T1 Data Latency : 33.4ns
U2-C1T0 <> U11-C5T1 Data Latency : 33.8ns
U4-C2T0 <> U6-C3T0 Data Latency : 31.3ns
U4-C2T0 <> U8-C4T0 Data Latency : 31.7ns
U4-C2T0 <> U10-C5T0 Data Latency : 32.1ns
U4-C2T0 <> U12-c6 Data Latency : 36.7ns
U4-C2T0 <> U13-c7 Data Latency : 36.6ns
U4-C2T0 <> U14-c8 Data Latency : 36.7ns
U4-C2T0 <> U15-c9 Data Latency : 36.6ns
U4-C2T0 <> U16-c10 Data Latency : 37.3ns
U4-C2T0 <> U17-c11 Data Latency : 37.3ns
U4-C2T0 <> U18-c12 Data Latency : 37.2ns
U4-C2T0 <> U19-c13 Data Latency : 37.4ns
U4-C2T0 <> U1-C0T1 Data Latency : 35.2ns
U4-C2T0 <> U3-C1T1 Data Latency : 32.5ns
U4-C2T0 <> U5-C2T1 Data Latency : 13.5ns
U4-C2T0 <> U7-C3T1 Data Latency : 31.5ns
U4-C2T0 <> U9-C4T1 Data Latency : 32.0ns
U4-C2T0 <> U11-C5T1 Data Latency : 32.2ns
U6-C3T0 <> U8-C4T0 Data Latency : 32.0ns
U6-C3T0 <> U10-C5T0 Data Latency : 32.1ns
U6-C3T0 <> U12-c6 Data Latency : 37.6ns
U6-C3T0 <> U13-c7 Data Latency : 37.5ns
U6-C3T0 <> U14-c8 Data Latency : 37.3ns
U6-C3T0 <> U15-c9 Data Latency : 37.4ns
U6-C3T0 <> U16-c10 Data Latency : 38.0ns
U6-C3T0 <> U17-c11 Data Latency : 37.8ns
U6-C3T0 <> U18-c12 Data Latency : 37.9ns
U6-C3T0 <> U19-c13 Data Latency : 38.0ns
U6-C3T0 <> U1-C0T1 Data Latency : 35.2ns
U6-C3T0 <> U3-C1T1 Data Latency : 32.7ns
U6-C3T0 <> U5-C2T1 Data Latency : 31.3ns
U6-C3T0 <> U7-C3T1 Data Latency : 13.9ns
U6-C3T0 <> U9-C4T1 Data Latency : 31.9ns
U6-C3T0 <> U11-C5T1 Data Latency : 32.1ns
U8-C4T0 <> U10-C5T0 Data Latency : 32.8ns
U8-C4T0 <> U12-c6 Data Latency : 38.4ns
U8-C4T0 <> U13-c7 Data Latency : 37.7ns
U8-C4T0 <> U14-c8 Data Latency : 37.8ns
U8-C4T0 <> U15-c9 Data Latency : 38.2ns
U8-C4T0 <> U16-c10 Data Latency : 38.5ns
U8-C4T0 <> U17-c11 Data Latency : 38.3ns
U8-C4T0 <> U18-c12 Data Latency : 38.1ns
U8-C4T0 <> U19-c13 Data Latency : 38.3ns
U8-C4T0 <> U1-C0T1 Data Latency : 35.5ns
U8-C4T0 <> U3-C1T1 Data Latency : 33.4ns
U8-C4T0 <> U5-C2T1 Data Latency : 31.7ns
U8-C4T0 <> U7-C3T1 Data Latency : 32.0ns
U8-C4T0 <> U9-C4T1 Data Latency : 14.0ns
U8-C4T0 <> U11-C5T1 Data Latency : 32.6ns
U10-C5T0 <> U12-c6 Data Latency : 38.5ns
U10-C5T0 <> U13-c7 Data Latency : 38.4ns
U10-C5T0 <> U14-c8 Data Latency : 38.6ns
U10-C5T0 <> U15-c9 Data Latency : 38.5ns
U10-C5T0 <> U16-c10 Data Latency : 38.6ns
U10-C5T0 <> U17-c11 Data Latency : 38.5ns
U10-C5T0 <> U18-c12 Data Latency : 38.9ns
U10-C5T0 <> U19-c13 Data Latency : 38.6ns
U10-C5T0 <> U1-C0T1 Data Latency : 35.8ns
U10-C5T0 <> U3-C1T1 Data Latency : 33.6ns
U10-C5T0 <> U5-C2T1 Data Latency : 32.1ns
U10-C5T0 <> U7-C3T1 Data Latency : 32.0ns
U10-C5T0 <> U9-C4T1 Data Latency : 32.6ns
U10-C5T0 <> U11-C5T1 Data Latency : 13.7ns
U12-c6 <> U13-c7 Data Latency : 44.7ns
U12-c6 <> U14-c8 Data Latency : 44.7ns
U12-c6 <> U15-c9 Data Latency : 44.7ns
U12-c6 <> U16-c10 Data Latency : 43.7ns
U12-c6 <> U17-c11 Data Latency : 43.5ns
U12-c6 <> U18-c12 Data Latency : 43.5ns
U12-c6 <> U19-c13 Data Latency : 43.5ns
U12-c6 <> U1-C0T1 Data Latency : 40.4ns
U12-c6 <> U3-C1T1 Data Latency : 41.1ns
U12-c6 <> U5-C2T1 Data Latency : 38.9ns
U12-c6 <> U7-C3T1 Data Latency : 39.8ns
U12-c6 <> U9-C4T1 Data Latency : 40.7ns
U12-c6 <> U11-C5T1 Data Latency : 40.6ns
U13-c7 <> U14-c8 Data Latency : 44.8ns
U13-c7 <> U15-c9 Data Latency : 44.6ns
U13-c7 <> U16-c10 Data Latency : 43.4ns
U13-c7 <> U17-c11 Data Latency : 44.1ns
U13-c7 <> U18-c12 Data Latency : 43.2ns
U13-c7 <> U19-c13 Data Latency : 43.6ns
U13-c7 <> U1-C0T1 Data Latency : 40.5ns
U13-c7 <> U3-C1T1 Data Latency : 41.0ns
U13-c7 <> U5-C2T1 Data Latency : 39.0ns
U13-c7 <> U7-C3T1 Data Latency : 39.8ns
U13-c7 <> U9-C4T1 Data Latency : 40.3ns
U13-c7 <> U11-C5T1 Data Latency : 40.6ns
U14-c8 <> U15-c9 Data Latency : 44.7ns
U14-c8 <> U16-c10 Data Latency : 43.4ns
U14-c8 <> U17-c11 Data Latency : 43.5ns
U14-c8 <> U18-c12 Data Latency : 43.5ns
U14-c8 <> U19-c13 Data Latency : 43.3ns
U14-c8 <> U1-C0T1 Data Latency : 40.4ns
U14-c8 <> U3-C1T1 Data Latency : 41.1ns
U14-c8 <> U5-C2T1 Data Latency : 39.0ns
U14-c8 <> U7-C3T1 Data Latency : 39.8ns
U14-c8 <> U9-C4T1 Data Latency : 40.3ns
U14-c8 <> U11-C5T1 Data Latency : 40.9ns
U15-c9 <> U16-c10 Data Latency : 43.3ns
U15-c9 <> U17-c11 Data Latency : 44.2ns
U15-c9 <> U18-c12 Data Latency : 43.4ns
U15-c9 <> U19-c13 Data Latency : 43.5ns
U15-c9 <> U1-C0T1 Data Latency : 40.3ns
U15-c9 <> U3-C1T1 Data Latency : 41.0ns
U15-c9 <> U5-C2T1 Data Latency : 39.1ns
U15-c9 <> U7-C3T1 Data Latency : 40.0ns
U15-c9 <> U9-C4T1 Data Latency : 40.4ns
U15-c9 <> U11-C5T1 Data Latency : 40.4ns
U16-c10 <> U17-c11 Data Latency : 45.9ns
U16-c10 <> U18-c12 Data Latency : 45.7ns
U16-c10 <> U19-c13 Data Latency : 45.6ns
U16-c10 <> U1-C0T1 Data Latency : 42.5ns
U16-c10 <> U3-C1T1 Data Latency : 38.2ns
U16-c10 <> U5-C2T1 Data Latency : 38.4ns
U16-c10 <> U7-C3T1 Data Latency : 39.1ns
U16-c10 <> U9-C4T1 Data Latency : 39.2ns
U16-c10 <> U11-C5T1 Data Latency : 39.9ns
U17-c11 <> U18-c12 Data Latency : 45.7ns
U17-c11 <> U19-c13 Data Latency : 45.6ns
U17-c11 <> U1-C0T1 Data Latency : 42.6ns
U17-c11 <> U3-C1T1 Data Latency : 38.0ns
U17-c11 <> U5-C2T1 Data Latency : 38.4ns
U17-c11 <> U7-C3T1 Data Latency : 39.0ns
U17-c11 <> U9-C4T1 Data Latency : 39.4ns
U17-c11 <> U11-C5T1 Data Latency : 39.7ns
U18-c12 <> U19-c13 Data Latency : 45.7ns
U18-c12 <> U1-C0T1 Data Latency : 42.6ns
U18-c12 <> U3-C1T1 Data Latency : 37.9ns
U18-c12 <> U5-C2T1 Data Latency : 38.4ns
U18-c12 <> U7-C3T1 Data Latency : 39.1ns
U18-c12 <> U9-C4T1 Data Latency : 39.2ns
U18-c12 <> U11-C5T1 Data Latency : 39.6ns
U19-c13 <> U1-C0T1 Data Latency : 42.8ns
U19-c13 <> U3-C1T1 Data Latency : 38.3ns
U19-c13 <> U5-C2T1 Data Latency : 38.4ns
U19-c13 <> U7-C3T1 Data Latency : 38.9ns
U19-c13 <> U9-C4T1 Data Latency : 39.5ns
U19-c13 <> U11-C5T1 Data Latency : 39.8ns
U1-C0T1 <> U3-C1T1 Data Latency : 35.3ns
U1-C0T1 <> U5-C2T1 Data Latency : 35.0ns
U1-C0T1 <> U7-C3T1 Data Latency : 35.8ns
U1-C0T1 <> U9-C4T1 Data Latency : 35.5ns
U1-C0T1 <> U11-C5T1 Data Latency : 36.0ns
U3-C1T1 <> U5-C2T1 Data Latency : 32.7ns
U3-C1T1 <> U7-C3T1 Data Latency : 33.3ns
U3-C1T1 <> U9-C4T1 Data Latency : 33.3ns
U3-C1T1 <> U11-C5T1 Data Latency : 33.6ns
U5-C2T1 <> U7-C3T1 Data Latency : 31.3ns
U5-C2T1 <> U9-C4T1 Data Latency : 32.1ns
U5-C2T1 <> U11-C5T1 Data Latency : 31.9ns
U7-C3T1 <> U9-C4T1 Data Latency : 32.1ns
U7-C3T1 <> U11-C5T1 Data Latency : 32.2ns
U9-C4T1 <> U11-C5T1 Data Latency : 33.0ns
1x 64bytes Blocks Bandwidth : 8GB/s
4x 64bytes Blocks Bandwidth : 15.5GB/s
4x 256bytes Blocks Bandwidth : 59.48GB/s
4x 1kB Blocks Bandwidth : 246.41GB/s
4x 4kB Blocks Bandwidth : 585.76GB/s
16x 4kB Blocks Bandwidth : 357.26GB/s
4x 64kB Blocks Bandwidth : 377.4GB/s
16x 64kB Blocks Bandwidth : 376.29GB/s
8x 256kB Blocks Bandwidth : 354.24GB/s
4x 1MB Blocks Bandwidth : 100GB/s
16x 1MB Blocks Bandwidth : 21.9GB/s
8x 4MB Blocks Bandwidth : 20.08GB/s
Benchmark Status
Result ID : 13th Gen Intel(R) Core(TM) i5-13600K (6C + 8c 20T 5.39GHz + 4.3GHz, 4.5GHz IMC, 6x 2MB + 2x 4MB L2, 24MB L3)
Microcode : 0B0671-11D
Computer : GigaByte Z790 AORUS ELITE AX DDR4 Z790 MB
Platform Compliance : x64
No. Threads : 20
System Timer : 10MHz
Page Size : 4kB
Processor
Model : 13th Gen Intel(R) Core(TM) i5-13600K
URL : https://www.intel.com
Revision/Stepping : B7 / 1
Microcode : 0B0671-11D
Latest Version : 0B0671-11F
Front-Side Bus Speed : 100MHz
Rated Power (TDP) : 150.00W
Min/Max/Turbo Power : N/A - 150.00W - 181.00W
Power/Current/Voltage Unlocked : Yes
big Cores Cluster
Cores per Processor : 6 Unit(s)
Threads per Core : 2 Unit(s)
Speed : 5.39GHz
Supported Speed(s) : 800MHz - 3.5GHz - 5.4GHz
Multiplier Unlocked : Yes
L1D (1st Level) Data Cache : 6x 48kB, 12-Way, Exclusive, 64bytes Line Size, 2 Thread(s)
L1I (1st Level) Code Cache : 6x 32kB, 8-Way, Exclusive, 64bytes Line Size, 2 Thread(s)
L2 (2nd Level) Unified/Data Cache : 6x 2MB, ECC, 16-Way, Exclusive, 64bytes Line Size, 8 Thread(s)
L3 (3rd Level) Unified/Data Cache : 24MB, ECC, 12-Way, Exclusive, 64bytes Line Size, 128 Thread(s)
Rated Voltage (DV) : 1.23V
Min/Max/Turbo Voltage : N/A - 1.23V
LITTLE cores Cluster
Cores per Processor : 8 Unit(s)
Speed : 4.3GHz
Supported Speed(s) : 800MHz - 3.5GHz - 4.3GHz
Multiplier Unlocked : Yes
L1D (1st Level) Data Cache : 8x 32kB, 8-Way, Exclusive, 64bytes Line Size, 2 Thread(s)
L1I (1st Level) Code Cache : 8x 64kB, 8-Way, Exclusive, 64bytes Line Size, 2 Thread(s)
L2 (2nd Level) Unified/Data Cache : 2x 4MB, ECC, 16-Way, Exclusive, 64bytes Line Size, 8 Thread(s)
L3 (3rd Level) Unified/Data Cache : 24MB, ECC, 12-Way, Exclusive, 64bytes Line Size, 128 Thread(s)
Rated Voltage (DV) : 1.22V
Min/Max/Turbo Voltage : N/A - 1.22V - 1.22V
Memory Controller
Speed : 4.5GHz
Min/Max/Turbo Speed : 800MHz - 4.5GHz
Performance Enhancing Tips
Warning 5010 : Cannot use Large Memory Pages due to lack of privileges.
Tip 229 : CPU microcode update available. Check for an updated System BIOS with updated microcode.
Warning 208 : Hybrid processor with big/LITTLE cores. Performance may vary with type of cores used.
Notice 241 : Dynamic OverClocking/Turbo enabled. Performance may vary when engaged.
Tip 3 : Double-click tip or press Enter while a tip is selected for more information about the tip. -
zebra_hun
veterán
SiSoftware Sandra
Benchmark Results
Aggregate Inter-Thread Bandwidth : 165.38GB/s
Results Interpretation : Higher Scores mean Better Performance.
Binary Numeral System (base 2) : 1GB(/s) = 1024MB(/s), 1MB(/s) = 1024kB(/s), 1kB(/s) = 1024 bytes(/s), etc.
Benchmark Results
Average Inter-Thread Latency : 39.1ns (10.2ns - 54.0ns)
Inter-Thread (same Core) Latency : 10.7ns
Inter-Core (same Module) Latency : 31.6ns
Inter-LITTLE-cores (same Module) Latency : 46.6ns
Inter-big/LITTLE-Core (same Module) Latency : 39.7ns
Results Interpretation : Lower Scores mean Better Performance.
Decimal Numeral System (base 10) : 1s = 1000ms, 1ms = 1000µs, 1µs = 1000ns, etc.
Performance per Thread
Aggregate Inter-Thread Bandwidth : 5.17GB/s
No. Threads : 32
Results Interpretation : Higher Scores mean Better Performance.
Binary Numeral System (base 2) : 1GB(/s) = 1024MB(/s), 1MB(/s) = 1024kB(/s), 1kB(/s) = 1024 bytes(/s), etc.
Performance vs. Power
Processor(s) Power : 150.00W
Aggregate Inter-Thread Bandwidth : 1129.02MB/s/W
Results Interpretation : Higher Scores mean Better Performance.
Average Inter-Thread Latency : 2.61ns/W
Results Interpretation : Lower Scores mean Better Performance.
Capacity vs. Power
Total Cache Size : 469.33kB/W
Results Interpretation : Higher Scores mean Better Performance.
Performance vs. Speed
Aggregate Inter-Thread Bandwidth : 29.32MB/s/MHz
Results Interpretation : Higher Scores mean Better Performance.
Average Inter-Thread Latency : 0.07ns/MHz
Results Interpretation : Lower Scores mean Better Performance.
Detailed Results
Processor Affinity : U0-U1 U2-U3 U4-U5 U6-U7 U8-U9 U10-U11 U12-U13 U14-U15 U16-U24 U17-U25 U18-U26 U19-U27 U20-U23 U21-U22 U28-U31 U29-U30
U0-C0T0 <> U2-C1T0 Data Latency : 31.9ns
U0-C0T0 <> U4-C2T0 Data Latency : 31.7ns
U0-C0T0 <> U6-C3T0 Data Latency : 31.4ns
U0-C0T0 <> U8-C4T0 Data Latency : 31.9ns
U0-C0T0 <> U10-C5T0 Data Latency : 33.2ns
U0-C0T0 <> U12-C6T0 Data Latency : 33.9ns
U0-C0T0 <> U14-C7T0 Data Latency : 33.9ns
U0-C0T0 <> U16-c8 Data Latency : 42.1ns
U0-C0T0 <> U17-c9 Data Latency : 42.1ns
U0-C0T0 <> U18-c10 Data Latency : 42.2ns
U0-C0T0 <> U19-c11 Data Latency : 42.5ns
U0-C0T0 <> U20-c12 Data Latency : 42.3ns
U0-C0T0 <> U21-c13 Data Latency : 42.2ns
U0-C0T0 <> U22-c14 Data Latency : 42.2ns
U0-C0T0 <> U23-c15 Data Latency : 42.1ns
U0-C0T0 <> U24-c16 Data Latency : 41.4ns
U0-C0T0 <> U25-c17 Data Latency : 41.5ns
U0-C0T0 <> U26-c18 Data Latency : 41.5ns
U0-C0T0 <> U27-c19 Data Latency : 41.5ns
U0-C0T0 <> U28-c20 Data Latency : 40.0ns
U0-C0T0 <> U29-c21 Data Latency : 40.1ns
U0-C0T0 <> U30-c22 Data Latency : 40.3ns
U0-C0T0 <> U31-c23 Data Latency : 39.9ns
U0-C0T0 <> U1-C0T1 Data Latency : 10.8ns
U0-C0T0 <> U3-C1T1 Data Latency : 31.6ns
U0-C0T0 <> U5-C2T1 Data Latency : 31.7ns
U0-C0T0 <> U7-C3T1 Data Latency : 31.4ns
U0-C0T0 <> U9-C4T1 Data Latency : 32.1ns
U0-C0T0 <> U11-C5T1 Data Latency : 33.2ns
U0-C0T0 <> U13-C6T1 Data Latency : 34.0ns
U0-C0T0 <> U15-C7T1 Data Latency : 34.1ns
U2-C1T0 <> U4-C2T0 Data Latency : 30.8ns
U2-C1T0 <> U6-C3T0 Data Latency : 31.0ns
U2-C1T0 <> U8-C4T0 Data Latency : 32.1ns
U2-C1T0 <> U10-C5T0 Data Latency : 32.7ns
U2-C1T0 <> U12-C6T0 Data Latency : 33.2ns
U2-C1T0 <> U14-C7T0 Data Latency : 33.7ns
U2-C1T0 <> U16-c8 Data Latency : 41.5ns
U2-C1T0 <> U17-c9 Data Latency : 41.5ns
U2-C1T0 <> U18-c10 Data Latency : 41.5ns
U2-C1T0 <> U19-c11 Data Latency : 41.7ns
U2-C1T0 <> U20-c12 Data Latency : 42.0ns
U2-C1T0 <> U21-c13 Data Latency : 41.8ns
U2-C1T0 <> U22-c14 Data Latency : 41.4ns
U2-C1T0 <> U23-c15 Data Latency : 41.7ns
U2-C1T0 <> U24-c16 Data Latency : 37.2ns
U2-C1T0 <> U25-c17 Data Latency : 36.6ns
U2-C1T0 <> U26-c18 Data Latency : 36.9ns
U2-C1T0 <> U27-c19 Data Latency : 37.5ns
U2-C1T0 <> U28-c20 Data Latency : 37.5ns
U2-C1T0 <> U29-c21 Data Latency : 37.3ns
U2-C1T0 <> U30-c22 Data Latency : 36.7ns
U2-C1T0 <> U31-c23 Data Latency : 37.2ns
U2-C1T0 <> U1-C0T1 Data Latency : 31.1ns
U2-C1T0 <> U3-C1T1 Data Latency : 11.7ns
U2-C1T0 <> U5-C2T1 Data Latency : 30.8ns
U2-C1T0 <> U7-C3T1 Data Latency : 31.1ns
U2-C1T0 <> U9-C4T1 Data Latency : 32.0ns
U2-C1T0 <> U11-C5T1 Data Latency : 33.3ns
U2-C1T0 <> U13-C6T1 Data Latency : 33.7ns
U2-C1T0 <> U15-C7T1 Data Latency : 34.0ns
U4-C2T0 <> U6-C3T0 Data Latency : 31.1ns
U4-C2T0 <> U8-C4T0 Data Latency : 32.2ns
U4-C2T0 <> U10-C5T0 Data Latency : 33.1ns
U4-C2T0 <> U12-C6T0 Data Latency : 33.8ns
U4-C2T0 <> U14-C7T0 Data Latency : 33.1ns
U4-C2T0 <> U16-c8 Data Latency : 42.1ns
U4-C2T0 <> U17-c9 Data Latency : 42.3ns
U4-C2T0 <> U18-c10 Data Latency : 42.2ns
U4-C2T0 <> U19-c11 Data Latency : 42.5ns
U4-C2T0 <> U20-c12 Data Latency : 41.9ns
U4-C2T0 <> U21-c13 Data Latency : 42.0ns
U4-C2T0 <> U22-c14 Data Latency : 42.1ns
U4-C2T0 <> U23-c15 Data Latency : 42.1ns
U4-C2T0 <> U24-c16 Data Latency : 37.1ns
U4-C2T0 <> U25-c17 Data Latency : 36.9ns
U4-C2T0 <> U26-c18 Data Latency : 36.7ns
U4-C2T0 <> U27-c19 Data Latency : 36.7ns
U4-C2T0 <> U28-c20 Data Latency : 36.6ns
U4-C2T0 <> U29-c21 Data Latency : 36.5ns
U4-C2T0 <> U30-c22 Data Latency : 36.8ns
U4-C2T0 <> U31-c23 Data Latency : 36.6ns
U4-C2T0 <> U1-C0T1 Data Latency : 31.7ns
U4-C2T0 <> U3-C1T1 Data Latency : 31.3ns
U4-C2T0 <> U5-C2T1 Data Latency : 11.0ns
U4-C2T0 <> U7-C3T1 Data Latency : 30.5ns
U4-C2T0 <> U9-C4T1 Data Latency : 31.7ns
U4-C2T0 <> U11-C5T1 Data Latency : 32.6ns
U4-C2T0 <> U13-C6T1 Data Latency : 32.8ns
U4-C2T0 <> U15-C7T1 Data Latency : 32.3ns
U6-C3T0 <> U8-C4T0 Data Latency : 28.5ns
U6-C3T0 <> U10-C5T0 Data Latency : 28.6ns
U6-C3T0 <> U12-C6T0 Data Latency : 29.5ns
U6-C3T0 <> U14-C7T0 Data Latency : 29.8ns
U6-C3T0 <> U16-c8 Data Latency : 36.4ns
U6-C3T0 <> U17-c9 Data Latency : 36.0ns
U6-C3T0 <> U18-c10 Data Latency : 37.5ns
U6-C3T0 <> U19-c11 Data Latency : 36.7ns
U6-C3T0 <> U20-c12 Data Latency : 36.9ns
U6-C3T0 <> U21-c13 Data Latency : 36.7ns
U6-C3T0 <> U22-c14 Data Latency : 36.8ns
U6-C3T0 <> U23-c15 Data Latency : 37.3ns
U6-C3T0 <> U24-c16 Data Latency : 38.5ns
U6-C3T0 <> U25-c17 Data Latency : 37.7ns
U6-C3T0 <> U26-c18 Data Latency : 38.6ns
U6-C3T0 <> U27-c19 Data Latency : 38.3ns
U6-C3T0 <> U28-c20 Data Latency : 39.7ns
U6-C3T0 <> U29-c21 Data Latency : 38.1ns
U6-C3T0 <> U30-c22 Data Latency : 38.2ns
U6-C3T0 <> U31-c23 Data Latency : 39.1ns
U6-C3T0 <> U1-C0T1 Data Latency : 31.0ns
U6-C3T0 <> U3-C1T1 Data Latency : 31.1ns
U6-C3T0 <> U5-C2T1 Data Latency : 30.7ns
U6-C3T0 <> U7-C3T1 Data Latency : 10.4ns
U6-C3T0 <> U9-C4T1 Data Latency : 28.1ns
U6-C3T0 <> U11-C5T1 Data Latency : 28.7ns
U6-C3T0 <> U13-C6T1 Data Latency : 29.7ns
U6-C3T0 <> U15-C7T1 Data Latency : 30.1ns
U8-C4T0 <> U10-C5T0 Data Latency : 29.3ns
U8-C4T0 <> U12-C6T0 Data Latency : 30.4ns
U8-C4T0 <> U14-C7T0 Data Latency : 30.8ns
U8-C4T0 <> U16-c8 Data Latency : 37.8ns
U8-C4T0 <> U17-c9 Data Latency : 39.0ns
U8-C4T0 <> U18-c10 Data Latency : 38.4ns
U8-C4T0 <> U19-c11 Data Latency : 38.3ns
U8-C4T0 <> U20-c12 Data Latency : 38.5ns
U8-C4T0 <> U21-c13 Data Latency : 38.2ns
U8-C4T0 <> U22-c14 Data Latency : 37.9ns
U8-C4T0 <> U23-c15 Data Latency : 37.5ns
U8-C4T0 <> U24-c16 Data Latency : 39.0ns
U8-C4T0 <> U25-c17 Data Latency : 39.4ns
U8-C4T0 <> U26-c18 Data Latency : 39.8ns
U8-C4T0 <> U27-c19 Data Latency : 39.8ns
U8-C4T0 <> U28-c20 Data Latency : 40.4ns
U8-C4T0 <> U29-c21 Data Latency : 40.6ns
U8-C4T0 <> U30-c22 Data Latency : 40.6ns
U8-C4T0 <> U31-c23 Data Latency : 39.9ns
U8-C4T0 <> U1-C0T1 Data Latency : 32.0ns
U8-C4T0 <> U3-C1T1 Data Latency : 32.1ns
U8-C4T0 <> U5-C2T1 Data Latency : 31.7ns
U8-C4T0 <> U7-C3T1 Data Latency : 28.5ns
U8-C4T0 <> U9-C4T1 Data Latency : 10.5ns
U8-C4T0 <> U11-C5T1 Data Latency : 29.3ns
U8-C4T0 <> U13-C6T1 Data Latency : 30.3ns
U8-C4T0 <> U15-C7T1 Data Latency : 30.7ns
U10-C5T0 <> U12-C6T0 Data Latency : 30.9ns
U10-C5T0 <> U14-C7T0 Data Latency : 30.9ns
U10-C5T0 <> U16-c8 Data Latency : 38.7ns
U10-C5T0 <> U17-c9 Data Latency : 37.0ns
U10-C5T0 <> U18-c10 Data Latency : 38.1ns
U10-C5T0 <> U19-c11 Data Latency : 37.8ns
U10-C5T0 <> U20-c12 Data Latency : 38.7ns
U10-C5T0 <> U21-c13 Data Latency : 37.9ns
U10-C5T0 <> U22-c14 Data Latency : 38.2ns
U10-C5T0 <> U23-c15 Data Latency : 38.6ns
U10-C5T0 <> U24-c16 Data Latency : 39.5ns
U10-C5T0 <> U25-c17 Data Latency : 40.4ns
U10-C5T0 <> U26-c18 Data Latency : 40.4ns
U10-C5T0 <> U27-c19 Data Latency : 39.5ns
U10-C5T0 <> U28-c20 Data Latency : 40.6ns
U10-C5T0 <> U29-c21 Data Latency : 39.7ns
U10-C5T0 <> U30-c22 Data Latency : 39.7ns
U10-C5T0 <> U31-c23 Data Latency : 39.6ns
U10-C5T0 <> U1-C0T1 Data Latency : 33.1ns
U10-C5T0 <> U3-C1T1 Data Latency : 32.8ns
U10-C5T0 <> U5-C2T1 Data Latency : 32.2ns
U10-C5T0 <> U7-C3T1 Data Latency : 28.9ns
U10-C5T0 <> U9-C4T1 Data Latency : 29.4ns
U10-C5T0 <> U11-C5T1 Data Latency : 10.2ns
U10-C5T0 <> U13-C6T1 Data Latency : 30.5ns
U10-C5T0 <> U15-C7T1 Data Latency : 30.9ns
U12-C6T0 <> U14-C7T0 Data Latency : 31.8ns
U12-C6T0 <> U16-c8 Data Latency : 40.0ns
U12-C6T0 <> U17-c9 Data Latency : 38.8ns
U12-C6T0 <> U18-c10 Data Latency : 39.1ns
U12-C6T0 <> U19-c11 Data Latency : 39.3ns
U12-C6T0 <> U20-c12 Data Latency : 38.4ns
U12-C6T0 <> U21-c13 Data Latency : 39.1ns
U12-C6T0 <> U22-c14 Data Latency : 38.3ns
U12-C6T0 <> U23-c15 Data Latency : 39.1ns
U12-C6T0 <> U24-c16 Data Latency : 41.2ns
U12-C6T0 <> U25-c17 Data Latency : 41.2ns
U12-C6T0 <> U26-c18 Data Latency : 40.8ns
U12-C6T0 <> U27-c19 Data Latency : 41.4ns
U12-C6T0 <> U28-c20 Data Latency : 41.7ns
U12-C6T0 <> U29-c21 Data Latency : 42.0ns
U12-C6T0 <> U30-c22 Data Latency : 41.5ns
U12-C6T0 <> U31-c23 Data Latency : 41.5ns
U12-C6T0 <> U1-C0T1 Data Latency : 33.7ns
U12-C6T0 <> U3-C1T1 Data Latency : 34.1ns
U12-C6T0 <> U5-C2T1 Data Latency : 33.0ns
U12-C6T0 <> U7-C3T1 Data Latency : 29.7ns
U12-C6T0 <> U9-C4T1 Data Latency : 30.3ns
U12-C6T0 <> U11-C5T1 Data Latency : 30.4ns
U12-C6T0 <> U13-C6T1 Data Latency : 10.9ns
U12-C6T0 <> U15-C7T1 Data Latency : 31.8ns
U14-C7T0 <> U16-c8 Data Latency : 39.2ns
U14-C7T0 <> U17-c9 Data Latency : 37.4ns
U14-C7T0 <> U18-c10 Data Latency : 39.9ns
U14-C7T0 <> U19-c11 Data Latency : 38.2ns
U14-C7T0 <> U20-c12 Data Latency : 38.5ns
U14-C7T0 <> U21-c13 Data Latency : 39.0ns
U14-C7T0 <> U22-c14 Data Latency : 40.0ns
U14-C7T0 <> U23-c15 Data Latency : 39.6ns
U14-C7T0 <> U24-c16 Data Latency : 40.8ns
U14-C7T0 <> U25-c17 Data Latency : 41.2ns
U14-C7T0 <> U26-c18 Data Latency : 41.6ns
U14-C7T0 <> U27-c19 Data Latency : 42.1ns
U14-C7T0 <> U28-c20 Data Latency : 41.9ns
U14-C7T0 <> U29-c21 Data Latency : 41.1ns
U14-C7T0 <> U30-c22 Data Latency : 40.4ns
U14-C7T0 <> U31-c23 Data Latency : 41.1ns
U14-C7T0 <> U1-C0T1 Data Latency : 33.6ns
U14-C7T0 <> U3-C1T1 Data Latency : 34.0ns
U14-C7T0 <> U5-C2T1 Data Latency : 33.4ns
U14-C7T0 <> U7-C3T1 Data Latency : 30.1ns
U14-C7T0 <> U9-C4T1 Data Latency : 30.5ns
U14-C7T0 <> U11-C5T1 Data Latency : 31.1ns
U14-C7T0 <> U13-C6T1 Data Latency : 31.8ns
U14-C7T0 <> U15-C7T1 Data Latency : 10.4ns
U16-c8 <> U17-c9 Data Latency : 47.3ns
U16-c8 <> U18-c10 Data Latency : 48.3ns
U16-c8 <> U19-c11 Data Latency : 45.7ns
U16-c8 <> U20-c12 Data Latency : 42.7ns
U16-c8 <> U21-c13 Data Latency : 42.7ns
U16-c8 <> U22-c14 Data Latency : 42.1ns
U16-c8 <> U23-c15 Data Latency : 42.2ns
U16-c8 <> U24-c16 Data Latency : 41.0ns
U16-c8 <> U25-c17 Data Latency : 46.4ns
U16-c8 <> U26-c18 Data Latency : 47.1ns
U16-c8 <> U27-c19 Data Latency : 41.4ns
U16-c8 <> U28-c20 Data Latency : 46.7ns
U16-c8 <> U29-c21 Data Latency : 48.7ns
U16-c8 <> U30-c22 Data Latency : 48.6ns
U16-c8 <> U31-c23 Data Latency : 47.3ns
U16-c8 <> U1-C0T1 Data Latency : 41.6ns
U16-c8 <> U3-C1T1 Data Latency : 41.6ns
U16-c8 <> U5-C2T1 Data Latency : 41.8ns
U16-c8 <> U7-C3T1 Data Latency : 35.9ns
U16-c8 <> U9-C4T1 Data Latency : 35.1ns
U16-c8 <> U11-C5T1 Data Latency : 37.0ns
U16-c8 <> U13-C6T1 Data Latency : 36.7ns
U16-c8 <> U15-C7T1 Data Latency : 38.0ns
U17-c9 <> U18-c10 Data Latency : 47.2ns
U17-c9 <> U19-c11 Data Latency : 48.8ns
U17-c9 <> U20-c12 Data Latency : 46.7ns
U17-c9 <> U21-c13 Data Latency : 45.9ns
U17-c9 <> U22-c14 Data Latency : 42.3ns
U17-c9 <> U23-c15 Data Latency : 45.2ns
U17-c9 <> U24-c16 Data Latency : 47.7ns
U17-c9 <> U25-c17 Data Latency : 41.1ns
U17-c9 <> U26-c18 Data Latency : 45.2ns
U17-c9 <> U27-c19 Data Latency : 48.4ns
U17-c9 <> U28-c20 Data Latency : 47.9ns
U17-c9 <> U29-c21 Data Latency : 47.4ns
U17-c9 <> U30-c22 Data Latency : 43.4ns
U17-c9 <> U31-c23 Data Latency : 41.8ns
U17-c9 <> U1-C0T1 Data Latency : 41.5ns
U17-c9 <> U3-C1T1 Data Latency : 41.7ns
U17-c9 <> U5-C2T1 Data Latency : 42.4ns
U17-c9 <> U7-C3T1 Data Latency : 36.1ns
U17-c9 <> U9-C4T1 Data Latency : 36.0ns
U17-c9 <> U11-C5T1 Data Latency : 35.2ns
U17-c9 <> U13-C6T1 Data Latency : 36.8ns
U17-c9 <> U15-C7T1 Data Latency : 38.5ns
U18-c10 <> U19-c11 Data Latency : 48.5ns
U18-c10 <> U20-c12 Data Latency : 46.7ns
U18-c10 <> U21-c13 Data Latency : 46.3ns
U18-c10 <> U22-c14 Data Latency : 46.2ns
U18-c10 <> U23-c15 Data Latency : 46.2ns
U18-c10 <> U24-c16 Data Latency : 41.7ns
U18-c10 <> U25-c17 Data Latency : 41.0ns
U18-c10 <> U26-c18 Data Latency : 41.5ns
U18-c10 <> U27-c19 Data Latency : 42.4ns
U18-c10 <> U28-c20 Data Latency : 42.0ns
U18-c10 <> U29-c21 Data Latency : 41.6ns
U18-c10 <> U30-c22 Data Latency : 41.7ns
U18-c10 <> U31-c23 Data Latency : 45.1ns
U18-c10 <> U1-C0T1 Data Latency : 41.4ns
U18-c10 <> U3-C1T1 Data Latency : 41.6ns
U18-c10 <> U5-C2T1 Data Latency : 41.6ns
U18-c10 <> U7-C3T1 Data Latency : 36.3ns
U18-c10 <> U9-C4T1 Data Latency : 35.9ns
U18-c10 <> U11-C5T1 Data Latency : 36.3ns
U18-c10 <> U13-C6T1 Data Latency : 36.4ns
U18-c10 <> U15-C7T1 Data Latency : 37.9ns
U19-c11 <> U20-c12 Data Latency : 42.0ns
U19-c11 <> U21-c13 Data Latency : 45.3ns
U19-c11 <> U22-c14 Data Latency : 45.9ns
U19-c11 <> U23-c15 Data Latency : 45.5ns
U19-c11 <> U24-c16 Data Latency : 47.8ns
U19-c11 <> U25-c17 Data Latency : 48.3ns
U19-c11 <> U26-c18 Data Latency : 48.1ns
U19-c11 <> U27-c19 Data Latency : 40.8ns
U19-c11 <> U28-c20 Data Latency : 46.1ns
U19-c11 <> U29-c21 Data Latency : 47.4ns
U19-c11 <> U30-c22 Data Latency : 47.8ns
U19-c11 <> U31-c23 Data Latency : 42.7ns
U19-c11 <> U1-C0T1 Data Latency : 41.8ns
U19-c11 <> U3-C1T1 Data Latency : 41.8ns
U19-c11 <> U5-C2T1 Data Latency : 41.8ns
U19-c11 <> U7-C3T1 Data Latency : 36.2ns
U19-c11 <> U9-C4T1 Data Latency : 37.4ns
U19-c11 <> U11-C5T1 Data Latency : 38.0ns
U19-c11 <> U13-C6T1 Data Latency : 37.8ns
U19-c11 <> U15-C7T1 Data Latency : 39.0ns
U20-c12 <> U21-c13 Data Latency : 47.2ns
U20-c12 <> U22-c14 Data Latency : 47.8ns
U20-c12 <> U23-c15 Data Latency : 46.7ns
U20-c12 <> U24-c16 Data Latency : 41.0ns
U20-c12 <> U25-c17 Data Latency : 47.0ns
U20-c12 <> U26-c18 Data Latency : 47.4ns
U20-c12 <> U27-c19 Data Latency : 45.0ns
U20-c12 <> U28-c20 Data Latency : 48.1ns
U20-c12 <> U29-c21 Data Latency : 48.0ns
U20-c12 <> U30-c22 Data Latency : 48.2ns
U20-c12 <> U31-c23 Data Latency : 48.2ns
U20-c12 <> U1-C0T1 Data Latency : 42.0ns
U20-c12 <> U3-C1T1 Data Latency : 41.7ns
U20-c12 <> U5-C2T1 Data Latency : 42.0ns
U20-c12 <> U7-C3T1 Data Latency : 36.0ns
U20-c12 <> U9-C4T1 Data Latency : 35.5ns
U20-c12 <> U11-C5T1 Data Latency : 35.0ns
U20-c12 <> U13-C6T1 Data Latency : 38.2ns
U20-c12 <> U15-C7T1 Data Latency : 38.3ns
U21-c13 <> U22-c14 Data Latency : 45.4ns
U21-c13 <> U23-c15 Data Latency : 46.9ns
U21-c13 <> U24-c16 Data Latency : 48.3ns
U21-c13 <> U25-c17 Data Latency : 46.5ns
U21-c13 <> U26-c18 Data Latency : 41.2ns
U21-c13 <> U27-c19 Data Latency : 46.1ns
U21-c13 <> U28-c20 Data Latency : 48.5ns
U21-c13 <> U29-c21 Data Latency : 48.2ns
U21-c13 <> U30-c22 Data Latency : 48.3ns
U21-c13 <> U31-c23 Data Latency : 46.4ns
U21-c13 <> U1-C0T1 Data Latency : 42.0ns
U21-c13 <> U3-C1T1 Data Latency : 41.8ns
U21-c13 <> U5-C2T1 Data Latency : 41.9ns
U21-c13 <> U7-C3T1 Data Latency : 35.8ns
U21-c13 <> U9-C4T1 Data Latency : 35.3ns
U21-c13 <> U11-C5T1 Data Latency : 37.2ns
U21-c13 <> U13-C6T1 Data Latency : 37.9ns
U21-c13 <> U15-C7T1 Data Latency : 38.6ns
U22-c14 <> U23-c15 Data Latency : 47.5ns
U22-c14 <> U24-c16 Data Latency : 49.1ns
U22-c14 <> U25-c17 Data Latency : 48.2ns
U22-c14 <> U26-c18 Data Latency : 48.5ns
U22-c14 <> U27-c19 Data Latency : 47.4ns
U22-c14 <> U28-c20 Data Latency : 48.1ns
U22-c14 <> U29-c21 Data Latency : 42.3ns
U22-c14 <> U30-c22 Data Latency : 42.4ns
U22-c14 <> U31-c23 Data Latency : 42.3ns
U22-c14 <> U1-C0T1 Data Latency : 42.0ns
U22-c14 <> U3-C1T1 Data Latency : 41.9ns
U22-c14 <> U5-C2T1 Data Latency : 42.0ns
U22-c14 <> U7-C3T1 Data Latency : 35.7ns
U22-c14 <> U9-C4T1 Data Latency : 36.5ns
U22-c14 <> U11-C5T1 Data Latency : 36.6ns
U22-c14 <> U13-C6T1 Data Latency : 38.0ns
U22-c14 <> U15-C7T1 Data Latency : 38.2ns
U23-c15 <> U24-c16 Data Latency : 41.8ns
U23-c15 <> U25-c17 Data Latency : 46.5ns
U23-c15 <> U26-c18 Data Latency : 47.2ns
U23-c15 <> U27-c19 Data Latency : 48.2ns
U23-c15 <> U28-c20 Data Latency : 47.9ns
U23-c15 <> U29-c21 Data Latency : 47.6ns
U23-c15 <> U30-c22 Data Latency : 47.8ns
U23-c15 <> U31-c23 Data Latency : 48.2ns
U23-c15 <> U1-C0T1 Data Latency : 42.1ns
U23-c15 <> U3-C1T1 Data Latency : 41.9ns
U23-c15 <> U5-C2T1 Data Latency : 42.0ns
U23-c15 <> U7-C3T1 Data Latency : 34.9ns
U23-c15 <> U9-C4T1 Data Latency : 36.0ns
U23-c15 <> U11-C5T1 Data Latency : 37.3ns
U23-c15 <> U13-C6T1 Data Latency : 37.6ns
U23-c15 <> U15-C7T1 Data Latency : 38.5ns
U24-c16 <> U25-c17 Data Latency : 52.3ns
U24-c16 <> U26-c18 Data Latency : 52.3ns
U24-c16 <> U27-c19 Data Latency : 53.3ns
U24-c16 <> U28-c20 Data Latency : 48.8ns
U24-c16 <> U29-c21 Data Latency : 43.9ns
U24-c16 <> U30-c22 Data Latency : 47.4ns
U24-c16 <> U31-c23 Data Latency : 49.3ns
U24-c16 <> U1-C0T1 Data Latency : 44.5ns
U24-c16 <> U3-C1T1 Data Latency : 44.3ns
U24-c16 <> U5-C2T1 Data Latency : 44.2ns
U24-c16 <> U7-C3T1 Data Latency : 37.8ns
U24-c16 <> U9-C4T1 Data Latency : 38.0ns
U24-c16 <> U11-C5T1 Data Latency : 37.8ns
U24-c16 <> U13-C6T1 Data Latency : 40.2ns
U24-c16 <> U15-C7T1 Data Latency : 39.2ns
U25-c17 <> U26-c18 Data Latency : 52.7ns
U25-c17 <> U27-c19 Data Latency : 52.6ns
U25-c17 <> U28-c20 Data Latency : 49.0ns
U25-c17 <> U29-c21 Data Latency : 49.4ns
U25-c17 <> U30-c22 Data Latency : 49.4ns
U25-c17 <> U31-c23 Data Latency : 44.2ns
U25-c17 <> U1-C0T1 Data Latency : 44.1ns
U25-c17 <> U3-C1T1 Data Latency : 43.9ns
U25-c17 <> U5-C2T1 Data Latency : 44.2ns
U25-c17 <> U7-C3T1 Data Latency : 37.9ns
U25-c17 <> U9-C4T1 Data Latency : 38.9ns
U25-c17 <> U11-C5T1 Data Latency : 39.3ns
U25-c17 <> U13-C6T1 Data Latency : 39.8ns
U25-c17 <> U15-C7T1 Data Latency : 39.8ns
U26-c18 <> U27-c19 Data Latency : 51.4ns
U26-c18 <> U28-c20 Data Latency : 48.3ns
U26-c18 <> U29-c21 Data Latency : 43.7ns
U26-c18 <> U30-c22 Data Latency : 44.1ns
U26-c18 <> U31-c23 Data Latency : 43.9ns
U26-c18 <> U1-C0T1 Data Latency : 44.1ns
U26-c18 <> U3-C1T1 Data Latency : 44.3ns
U26-c18 <> U5-C2T1 Data Latency : 44.1ns
U26-c18 <> U7-C3T1 Data Latency : 37.3ns
U26-c18 <> U9-C4T1 Data Latency : 37.4ns
U26-c18 <> U11-C5T1 Data Latency : 39.7ns
U26-c18 <> U13-C6T1 Data Latency : 39.3ns
U26-c18 <> U15-C7T1 Data Latency : 39.2ns
U27-c19 <> U28-c20 Data Latency : 49.2ns
U27-c19 <> U29-c21 Data Latency : 49.9ns
U27-c19 <> U30-c22 Data Latency : 48.7ns
U27-c19 <> U31-c23 Data Latency : 49.6ns
U27-c19 <> U1-C0T1 Data Latency : 44.4ns
U27-c19 <> U3-C1T1 Data Latency : 44.1ns
U27-c19 <> U5-C2T1 Data Latency : 44.3ns
U27-c19 <> U7-C3T1 Data Latency : 37.4ns
U27-c19 <> U9-C4T1 Data Latency : 39.2ns
U27-c19 <> U11-C5T1 Data Latency : 38.8ns
U27-c19 <> U13-C6T1 Data Latency : 39.1ns
U27-c19 <> U15-C7T1 Data Latency : 39.4ns
U28-c20 <> U29-c21 Data Latency : 53.2ns
U28-c20 <> U30-c22 Data Latency : 54.0ns
U28-c20 <> U31-c23 Data Latency : 49.2ns
U28-c20 <> U1-C0T1 Data Latency : 44.0ns
U28-c20 <> U3-C1T1 Data Latency : 44.0ns
U28-c20 <> U5-C2T1 Data Latency : 44.5ns
U28-c20 <> U7-C3T1 Data Latency : 37.8ns
U28-c20 <> U9-C4T1 Data Latency : 38.9ns
U28-c20 <> U11-C5T1 Data Latency : 40.4ns
U28-c20 <> U13-C6T1 Data Latency : 40.8ns
U28-c20 <> U15-C7T1 Data Latency : 41.1ns
U29-c21 <> U30-c22 Data Latency : 53.2ns
U29-c21 <> U31-c23 Data Latency : 53.6ns
U29-c21 <> U1-C0T1 Data Latency : 43.8ns
U29-c21 <> U3-C1T1 Data Latency : 44.0ns
U29-c21 <> U5-C2T1 Data Latency : 44.5ns
U29-c21 <> U7-C3T1 Data Latency : 37.7ns
U29-c21 <> U9-C4T1 Data Latency : 39.4ns
U29-c21 <> U11-C5T1 Data Latency : 40.2ns
U29-c21 <> U13-C6T1 Data Latency : 40.6ns
U29-c21 <> U15-C7T1 Data Latency : 39.4ns
U30-c22 <> U31-c23 Data Latency : 53.4ns
U30-c22 <> U1-C0T1 Data Latency : 43.9ns
U30-c22 <> U3-C1T1 Data Latency : 44.1ns
U30-c22 <> U5-C2T1 Data Latency : 44.4ns
U30-c22 <> U7-C3T1 Data Latency : 37.7ns
U30-c22 <> U9-C4T1 Data Latency : 39.3ns
U30-c22 <> U11-C5T1 Data Latency : 40.5ns
U30-c22 <> U13-C6T1 Data Latency : 40.6ns
U30-c22 <> U15-C7T1 Data Latency : 40.9ns
U31-c23 <> U1-C0T1 Data Latency : 43.8ns
U31-c23 <> U3-C1T1 Data Latency : 44.1ns
U31-c23 <> U5-C2T1 Data Latency : 44.7ns
U31-c23 <> U7-C3T1 Data Latency : 38.3ns
U31-c23 <> U9-C4T1 Data Latency : 38.5ns
U31-c23 <> U11-C5T1 Data Latency : 40.3ns
U31-c23 <> U13-C6T1 Data Latency : 41.1ns
U31-c23 <> U15-C7T1 Data Latency : 41.1ns
U1-C0T1 <> U3-C1T1 Data Latency : 31.5ns
U1-C0T1 <> U5-C2T1 Data Latency : 31.4ns
U1-C0T1 <> U7-C3T1 Data Latency : 30.8ns
U1-C0T1 <> U9-C4T1 Data Latency : 31.9ns
U1-C0T1 <> U11-C5T1 Data Latency : 32.5ns
U1-C0T1 <> U13-C6T1 Data Latency : 33.5ns
U1-C0T1 <> U15-C7T1 Data Latency : 33.8ns
U3-C1T1 <> U5-C2T1 Data Latency : 31.3ns
U3-C1T1 <> U7-C3T1 Data Latency : 31.3ns
U3-C1T1 <> U9-C4T1 Data Latency : 32.2ns
U3-C1T1 <> U11-C5T1 Data Latency : 33.2ns
U3-C1T1 <> U13-C6T1 Data Latency : 33.9ns
U3-C1T1 <> U15-C7T1 Data Latency : 33.5ns
U5-C2T1 <> U7-C3T1 Data Latency : 31.5ns
U5-C2T1 <> U9-C4T1 Data Latency : 32.1ns
U5-C2T1 <> U11-C5T1 Data Latency : 32.8ns
U5-C2T1 <> U13-C6T1 Data Latency : 33.7ns
U5-C2T1 <> U15-C7T1 Data Latency : 33.8ns
U7-C3T1 <> U9-C4T1 Data Latency : 28.4ns
U7-C3T1 <> U11-C5T1 Data Latency : 28.9ns
U7-C3T1 <> U13-C6T1 Data Latency : 29.7ns
U7-C3T1 <> U15-C7T1 Data Latency : 30.0ns
U9-C4T1 <> U11-C5T1 Data Latency : 29.5ns
U9-C4T1 <> U13-C6T1 Data Latency : 30.2ns
U9-C4T1 <> U15-C7T1 Data Latency : 30.9ns
U11-C5T1 <> U13-C6T1 Data Latency : 30.4ns
U11-C5T1 <> U15-C7T1 Data Latency : 31.3ns
U13-C6T1 <> U15-C7T1 Data Latency : 32.0ns
1x 64bytes Blocks Bandwidth : 12.32GB/s
4x 64bytes Blocks Bandwidth : 23.48GB/s
4x 256bytes Blocks Bandwidth : 96.68GB/s
4x 1kB Blocks Bandwidth : 370GB/s
4x 4kB Blocks Bandwidth : 867GB/s
16x 4kB Blocks Bandwidth : 552.64GB/s
4x 64kB Blocks Bandwidth : 615.07GB/s
16x 64kB Blocks Bandwidth : 608.81GB/s
8x 256kB Blocks Bandwidth : 621.77GB/s
4x 1MB Blocks Bandwidth : 189.22GB/s
16x 1MB Blocks Bandwidth : 44.66GB/s
8x 4MB Blocks Bandwidth : 42.93GB/s
Benchmark Status
Result ID : Intel(R) Core(TM) i9-14900K (8C + 16c 32T 5.78GHz + 4.38GHz, 4.9GHz IMC, 8x 2MB + 4x 4MB L2, 36MB L3)
Microcode : 0B0671-11F
Computer : ASUS System Product Name (ASUS ROG MAXIMUS Z790 APEX)
Platform Compliance : x64
No. Threads : 32
System Timer : 10MHz
Page Size : 2MB
Processor
Model : Intel(R) Core(TM) i9-14900K
URL : https://www.intel.com
Revision/Stepping : B7 / 1
Microcode : 0B0671-11F
Front-Side Bus Speed : 100MHz
Rated Power (TDP) : 150.00W
Min/Max/Turbo Power : N/A - 150.00W - 290.00W
Power/Current/Voltage Unlocked : Yes
big Cores Cluster
Cores per Processor : 8 Unit(s)
Threads per Core : 2 Unit(s)
Speed : 5.78GHz
Supported Speed(s) : 800MHz - 3.2GHz - 5.8GHz
Multiplier Unlocked : Yes
L1D (1st Level) Data Cache : 8x 48kB, 12-Way, Exclusive, 64bytes Line Size, 2 Thread(s)
L1I (1st Level) Code Cache : 8x 32kB, 8-Way, Exclusive, 64bytes Line Size, 2 Thread(s)
L2 (2nd Level) Unified/Data Cache : 8x 2MB, ECC, 16-Way, Exclusive, 64bytes Line Size, 8 Thread(s)
L3 (3rd Level) Unified/Data Cache : 36MB, ECC, 12-Way, Exclusive, 64bytes Line Size, 128 Thread(s)
Rated Voltage (DV) : 1.28V
Min/Max/Turbo Voltage : N/A - 1.28V
LITTLE cores Cluster
Cores per Processor : 16 Unit(s)
Speed : 4.38GHz
Supported Speed(s) : 800MHz - 3.2GHz - 4.4GHz
Multiplier Unlocked : Yes
L1D (1st Level) Data Cache : 16x 32kB, 8-Way, Exclusive, 64bytes Line Size, 2 Thread(s)
L1I (1st Level) Code Cache : 16x 64kB, 8-Way, Exclusive, 64bytes Line Size, 2 Thread(s)
L2 (2nd Level) Unified/Data Cache : 4x 4MB, ECC, 16-Way, Exclusive, 64bytes Line Size, 8 Thread(s)
L3 (3rd Level) Unified/Data Cache : 36MB, ECC, 12-Way, Exclusive, 64bytes Line Size, 128 Thread(s)
Rated Voltage (DV) : 1.30V
Min/Max/Turbo Voltage : N/A - 1.50V - 1.30V
Memory Controller
Speed : 4.9GHz
Min/Max/Turbo Speed : 800MHz - 4.9GHz
Performance Enhancing Tips
Warning 208 : Hybrid processor with big/LITTLE cores. Performance may vary with type of cores used.
Notice 241 : Dynamic OverClocking/Turbo enabled. Performance may vary when engaged.
Warning 205 : Turbo Power/Voltage/Current is low. Performance may be constrained.
Tip 3 : Double-click tip or press Enter while a tip is selected for more information about the tip. -
Qru
MODERÁTOR
Subaru topik
A Fuji Heavy Industries (FHI) 1953. július 15-én alakult hat cég egybeolvadásával Tokyoban. Gépjármű üzletáguk a Subaru márkanevet használja, jelenleg a Toyota társtulajdonlása mellett működik.
A cég a közelmúltban Subaru Corporation-re változtatta a nevét, ezzel is kihangsúlyozva, hogy a gépjárműgyártás a fő profiljuk. Emellett több kisebb üzletágtól is megváltak de a repülőgép alkatrész gyártás megmaradt másodprofilként a cég életében.A Subaru japánul a Bika csillagkép egy nyílt halmazát jelenti (6 jól látható csillag), ősidők óta a japánok egyik legkedveltebb csillaghalmaza. A nyugati kultúrában ez a Plejádok, magyarul a Fiastyúk nevet viseli. Japánban ez a csillagalakzat általánosan ismert mint az egyesülés, illetve a jó uralkodás szinonimája. Érdekességként, az FHI hat cég összeolvadásaként jött létre, így látható, hogy a Subaru valóban találó név.
Vezérképviselet, alkatrész rendelés:
Emil Frey: [link]
Tuning alkatrészek: [link]
Subaru parts US (angol): [link]
Subaru OEM parts US (angol): [link]Ajánlott szervizek:
Márkaszerviz:
- Duna AutóSzakszerviz:
- Boxer Crew
- Hace Car
- Nieszmotorsport
- Seibiko
- Szépvölgyi Autójavító
- Victory MotorsTudástár:
Subaru service manual: [link]
AWD enckilopédia (angol): [link]
Subaru enciklopédia (angol): [link]
Subaru sebességváltók listája (angol): [link] és Wiki
Front vs Top IC előnyei (angol): [link]
Lefújószelep (BOV) FAQ (angol): [link]
Subaru motorok listája (angol): [link]
Subaru motorok leírása (angol): [link]
A Subaru motorokról bővebben (angol): WikiMotors
AVLS (nem azonos az i-AVLS-el) leírása (angol): [link]
Subaru Legacy/Outbcak 2005-2009 hibakód kiolvasás műszerfalról: [link]
Service manual (angol): [link]
Tesztek:
Subaru Crosstrek - 2023 (mk1): [link]
Subaru Solterra - 2023 (mk1): [link]
Subaru Outback 2.5i - 2022 (mk6): [link]
Subaru Outback 2.5i - 2021 (mk6): [link] és [link] és [link]
Subaru Forester 2.0e - 2020 (mk5): [link]
Subaru XV 2.0i e-Boxer - 2020 (mk2): [link]
Subaru Forester 2.0i e-Boxer - 2020 (mk5): [link]
Subaru XV 2.0i - 2018 (mk2): [link] és [link]
Subaru Impreza 2.0i - 2017 (mk5): [link]
Subaru XV 2.0i - 2017 (mk2): [link]
Subaru BRZ 2.0i - 2017 (mk1): [link]
Subaru Levorg 1.6GT - 2016 (mk1): [link]
Subaru Outback 2.0D - 2016 (mk5): [link]
Subaru Outback 2.0D 2015 (mk5) vs Subaru Forester 2.0D 2015 (mk4): [link]
Subaru Outback 2.5i - 2015 (mk5): [link]
Subaru Forester 2.0D - 2015 (mk4): [link]
Subaru WRX STI - 2014 (mk5): [link]
Subaru Forester XT - 2013 (mk4): [link]
Subaru XV 2.0i - 2013 (mk1): [link]
Subaru XV 1.6i - 2012 (mk1): [link]
Subaru XV 2.0D - 2012 (mk1): [link]
Subaru Outback 2.5i 2010 (mk5): [link]
Subaru Legacy 2.5i - 2010 (mk5): [link]
Subaru Outback 2.0D - 2010 (mk4): [link]
Subaru Legacy 2.0D - 2010 (mk5): sedan / kombi
Subaru Impreza 2.0D - 2009 (mk3): [link]
Subaru Forester 2.0D - 2008 (mk3): [link] és [link]
Subaru Impreza 2.0i - 2008 (mk3): [link] és [link]
Subaru Legacy 2.0D - 2008 (mk4): [link]
Subaru B9 Tribeca 3.0i - 2006 (mk1): [link]
Subaru Outback 2.5i - 2006 (mk3): [link]
Subaru Legacy 2.0i - 2006 (mk4): [link]
Subaru Outback 3.0i - 2004 (mk3): [link]Subaru Forester SG típus teszt (2002-2008): [link]
Subaru Legacy/Outback BL/BP típus teszt (2003-2009): [link]
Subaru Impreza GD/GG típus teszt (2000-2007): [link]Topiktagok autói:
Acheron - Subaru Outback 3.6R (BR / EZ36D)
AddyKing - Subaru Impreza 1.6i (GF / EJ16)
balage. - Subaru Outback 3.0i (BP / EZ30D)
blasko92 - Subaru Impreza 2.0R (GD F-G / EJ204)
carr - Subaru Impreza 1.6i (GF / EJ16)
CB - Subaru Forester 2.0X (SJ / FB20B)
czanga - Subaru Impreza 2.0GT (GF / EJ205)
filatis1 - Subaru Outback 3.0i (BP / EZ30D)
Jorus - Subaru Outback 3.0i (BP / EZ30D)
Lacerta - Subaru Forester 2.0D (SH / EE20)
MasterMark - Subaru Legacy 3.0R (BL / EZ30D)
mmcc02 - Subaru XV 2.0i (GP / FB20B)
Omli85 - Subaru Legacy 2.5GT (BR / EJ255)
Parci - Subaru Forester 2.0X (SH / EJ204)
Petester - Subaru Outback 3.0i (BP / EZ30D)
Qru - Subaru Impreza 2.5i (GH / EJ253)
tom956ster - Subaru Impreza WRX (GD A / EJ205)
Gub4cs_1 - Subaru WRX STI (VA / EJ257)
Downsampling - Subaru Impreza Outback 2.0i (GG / EJ201) -
#13359
philoxenia
MODERÁTOR
philoxenia
MODERÁTOR
-
zebra_hun
veterán
[2024/01/07 12:10:12]
Ai Overclock Tuner [Auto]
Intel(R) Adaptive Boost Technology [Auto]
ASUS MultiCore Enhancement [Enabled – Remove All limits (90°C)]
SVID Behavior [Trained]
BCLK Frequency : DRAM Frequency Ratio [100:100]
Memory Controller : DRAM Frequency Ratio [1:2]
DRAM Frequency [DDR5-7200MHz]
Performance Core Ratio [Auto]
Performance Core0 Specific Ratio Limit [Auto]
Performance Core0 specific Voltage [Auto]
Performance Core1 Specific Ratio Limit [Auto]
Performance Core1 specific Voltage [Auto]
*Performance Core2 Specific Ratio Limit [Auto]
Performance Core2 specific Voltage [Auto]
*Performance Core3 Specific Ratio Limit [Auto]
Performance Core3 specific Voltage [Auto]
Performance Core4 Specific Ratio Limit [Auto]
Performance Core4 specific Voltage [Auto]
Performance Core5 Specific Ratio Limit [Auto]
Performance Core5 specific Voltage [Auto]
Performance Core6 Specific Ratio Limit [Auto]
Performance Core6 specific Voltage [Auto]
Performance Core7 Specific Ratio Limit [Auto]
Performance Core7 specific Voltage [Auto]
Efficient Core Ratio [Auto]
Efficient Core Group0 Specific Ratio Limit [Auto]
Efficient Core Group0 specific Voltage [Auto]
Efficient Core Group1 Specific Ratio Limit [Auto]
Efficient Core Group1 specific Voltage [Auto]
Efficient Core Group2 Specific Ratio Limit [Auto]
Efficient Core Group2 specific Voltage [Auto]
Efficient Core Group3 Specific Ratio Limit [Auto]
Efficient Core Group3 specific Voltage [Auto]
AVX2 [Auto]
AVX2 Ratio Offset to per-core Ratio Limit [Auto]
AVX2 Voltage Guardband Scale Factor [Auto]
Maximus Tweak [Mode 2]
DRAM CAS# Latency [32]
DRAM RAS# to CAS# Delay Read [42]
DRAM RAS# to CAS# Delay Write [16]
DRAM RAS# PRE Time [42]
DRAM RAS# ACT Time [54]
DRAM Command Rate [2N]
DRAM RAS# to RAS# Delay L [12]
DRAM RAS# to RAS# Delay S [8]
DRAM REF Cycle Time 2 [448]
DRAM REF Cycle Time Same Bank [Auto]
DRAM Refresh Interval [131071]
DRAM WRITE Recovery Time [24]
DRAM READ to PRE Time [12]
DRAM FOUR ACT WIN Time [32]
DRAM WRITE to READ Delay L [24]
DRAM WRITE to READ Delay S [10]
DRAM CKE Minimum Pulse Width [Auto]
DRAM Write Latency [30]
Ctl0 dqvrefup [154]
Ctl0 dqvrefdn [72]
Ctl0 dqodtvrefup [Auto]
Ctl0 dqodtvrefdn [Auto]
Ctl1 cmdvrefup [Auto]
Ctl1 ctlvrefup [Auto]
Ctl1 clkvrefup [Auto]
Ctl1 ckecsvrefup [Auto]
Ctl2 cmdvrefdn [Auto]
Ctl2 ctlvrefdn [Auto]
Ctl2 clkvrefdn [Auto]
Read Equalization RxEq Start Sign [-]
Read Equalization RxEq Start [Auto]
Read Equalization RxEq Stop Sign [-]
Read Equalization RxEq Stop [Auto]
ODT_READ_DURATION [Auto]
ODT_READ_DELAY [Auto]
ODT_WRITE_DURATION [Auto]
ODT_WRITE_DELAY [Auto]
DQ RTT WR [40 DRAM Clock]
DQ RTT NOM RD [40 DRAM Clock]
DQ RTT NOM WR [40 DRAM Clock]
DQ RTT PARK [34 DRAM Clock]
DQ RTT PARK DQS [34 DRAM Clock]
GroupA CA ODT [240 DRAM Clock]
GroupA CS ODT [0 DRAM Clock]
GroupA CK ODT [0 DRAM Clock]
GroupB CA ODT [60 DRAM Clock]
GroupB CS ODT [40 DRAM Clock]
GroupB CK ODT [40 DRAM Clock]
Pull-up Output Driver Impedance [34 DRAM Clock]
Pull-Down Output Driver Impedance [34 DRAM Clock]
DQ RTT WR [40 DRAM Clock]
DQ RTT NOM RD [40 DRAM Clock]
DQ RTT NOM WR [40 DRAM Clock]
DQ RTT PARK [34 DRAM Clock]
DQ RTT PARK DQS [34 DRAM Clock]
GroupA CA ODT [240 DRAM Clock]
GroupA CS ODT [0 DRAM Clock]
GroupA CK ODT [0 DRAM Clock]
GroupB CA ODT [60 DRAM Clock]
GroupB CS ODT [40 DRAM Clock]
GroupB CK ODT [40 DRAM Clock]
Pull-up Output Driver Impedance [34 DRAM Clock]
Pull-Down Output Driver Impedance [34 DRAM Clock]
Round Trip Latency Init Value MC0 CHA [Auto]
Round Trip Latency Max Value MC0 CHA [Auto]
Round Trip Latency Offset Value Mode Sign MC0 CHA [-]
Round Trip Latency Offset Value MC0 CHA [Auto]
Round Trip Latency Init Value MC0 CHB [Auto]
Round Trip Latency Max Value MC0 CHB [Auto]
Round Trip Latency Offset Value Mode Sign MC0 CHB [-]
Round Trip Latency Offset Value MC0 CHB [Auto]
Round Trip Latency Init Value MC1 CHA [Auto]
Round Trip Latency Max Value MC1 CHA [Auto]
Round Trip Latency Offset Value Mode Sign MC1 CHA [-]
Round Trip Latency Offset Value MC1 CHA [Auto]
Round Trip Latency Init Value MC1 CHB [Auto]
Round Trip Latency Max Value MC1 CHB [Auto]
Round Trip Latency Offset Value Mode Sign MC1 CHB [-]
Round Trip Latency Offset Value MC1 CHB [Auto]
Round Trip Latency MC0 CHA R0 [Auto]
Round Trip Latency MC0 CHA R1 [Auto]
Round Trip Latency MC0 CHA R2 [0]
Round Trip Latency MC0 CHA R3 [0]
Round Trip Latency MC0 CHA R4 [0]
Round Trip Latency MC0 CHA R5 [0]
Round Trip Latency MC0 CHA R6 [0]
Round Trip Latency MC0 CHA R7 [0]
Round Trip Latency MC0 CHB R0 [Auto]
Round Trip Latency MC0 CHB R1 [Auto]
Round Trip Latency MC0 CHB R2 [0]
Round Trip Latency MC0 CHB R3 [0]
Round Trip Latency MC0 CHB R4 [0]
Round Trip Latency MC0 CHB R5 [0]
Round Trip Latency MC0 CHB R6 [0]
Round Trip Latency MC0 CHB R7 [0]
Round Trip Latency MC1 CHA R0 [Auto]
Round Trip Latency MC1 CHA R1 [Auto]
Round Trip Latency MC1 CHA R2 [0]
Round Trip Latency MC1 CHA R3 [0]
Round Trip Latency MC1 CHA R4 [0]
Round Trip Latency MC1 CHA R5 [0]
Round Trip Latency MC1 CHA R6 [0]
Round Trip Latency MC1 CHA R7 [0]
Round Trip Latency MC1 CHB R0 [Auto]
Round Trip Latency MC1 CHB R1 [Auto]
Round Trip Latency MC1 CHB R2 [0]
Round Trip Latency MC1 CHB R3 [0]
Round Trip Latency MC1 CHB R4 [0]
Round Trip Latency MC1 CHB R5 [0]
Round Trip Latency MC1 CHB R6 [0]
Round Trip Latency MC1 CHB R7 [0]
Early Command Training [Auto]
SenseAmp Offset Training [Auto]
Early ReadMPR Timing Centering 2D [Auto]
Read MPR Training [Auto]
Receive Enable Training [Auto]
Jedec Write Leveling [Auto]
Early Write Time Centering 2D [Auto]
Early Read Time Centering 2D [Auto]
Write Timing Centering 1D [Auto]
Write Voltage Centering 1D [Auto]
Read Timing Centering 1D [Auto]
Read Timing Centering with JR [Auto]
Dimm ODT Training* [Disabled]
Max RTT_WR [ODT Off]
DIMM RON Training* [Disabled]
Write Drive Strength/Equalization 2D* [Auto]
Write Slew Rate Training* [Auto]
Read ODT Training* [Disabled]
Comp Optimization Training [Auto]
Read Equalization Training* [Auto]
Read Amplifier Training* [Auto]
Write Timing Centering 2D [Auto]
Read Timing Centering 2D [Auto]
Command Voltage Centering [Auto]
Early Command Voltage Centering [Auto]
Write Voltage Centering 2D [Auto]
Read Voltage Centering 2D [Auto]
Late Command Training [Auto]
Round Trip Latency [Auto]
Turn Around Timing Training [Auto]
CMD CTL CLK Slew Rate [Auto]
CMD/CTL DS & E 2D [Auto]
Read Voltage Centering 1D [Auto]
TxDqTCO Comp Training* [Auto]
ClkTCO Comp Training* [Auto]
TxDqsTCO Comp Training* [Auto]
VccDLL Bypass Training [Auto]
CMD/CTL Drive Strength Up/Dn 2D [Auto]
DIMM CA ODT Training [Auto]
PanicVttDnLp Training* [Auto]
Read Vref Decap Training* [Auto]
Vddq Training [Disabled]
Duty Cycle Correction Training [Auto]
Periodic DCC [Auto]
Rank Margin Tool Per Bit [Auto]
DIMM DFE Training [Auto]
EARLY DIMM DFE Training [Auto]
Tx Dqs Dcc Training [Auto]
DRAM DCA Training [Auto]
Write Driver Strength Training [Auto]
Rank Margin Tool [Auto]
Memory Test [Auto]
DIMM SPD Alias Test [Auto]
Receive Enable Centering 1D [Auto]
Retrain Margin Check [Auto]
Write Drive Strength Up/Dn independently [Auto]
LPDDR DqDqs Re-Training [Auto]
Margin Check Limit [Disabled]
tRDRD_sg_Training [Auto]
tRDRD_sg_Runtime [16]
tRDRD_dg_Training [Auto]
tRDRD_dg_Runtime [8]
tRDWR_sg [18]
tRDWR_dg [18]
tWRWR_sg [16]
tWRWR_dg [8]
tWRRD_sg [Auto]
tWRRD_dg [Auto]
tRDRD_dr [0]
tRDRD_dd [Auto]
tRDWR_dr [0]
tRDWR_dd [Auto]
tWRWR_dr [0]
tWRWR_dd [Auto]
tWRRD_dr [0]
tWRRD_dd [Auto]
tRPRE [Auto]
tWPRE [Auto]
tWPOST [Auto]
tWRPRE [Auto]
tPRPDEN [Auto]
tRDPDEN [Auto]
tWRPDEN [Auto]
tCPDED [Auto]
tREFIX9 [Auto]
Ref Interval [Auto]
tXPDLL [Auto]
tXP [Auto]
tPPD [Auto]
tCCD_L_tDLLK [Auto]
tZQCAL [Auto]
tZQCS [Auto]
OREF_RI [Auto]
Refresh Watermarks [High]
Refresh Hp Wm [Auto]
Refresh Panic Wm [Auto]
Refresh Abr Release [Auto]
tXSDLL [Auto]
tZQOPER [Auto]
tMOD [Auto]
CounttREFIWhileRefEn [Auto]
HPRefOnMRS [Auto]
SRX Ref Debits [Auto]
RAISE BLK WAIT [Auto]
Ref Stagger En [Auto]
Ref Stagger Mode [Auto]
Disable Stolen Refresh [Auto]
En Ref Type Display [Auto]
Trefipulse Stagger Disable [Auto]
tRPab ext [Auto]
derating ext [Auto]
Allow 2cyc B2B LPDDR [Auto]
tCSH [Auto]
tCSL [Auto]
powerdown Enable [Auto]
idle length [Auto]
raise cke after exit latency [Auto]
powerdown latency [Auto]
powerdown length [Auto]
selfrefresh latency [Auto]
selfrefresh length [Auto]
ckevalid length [Auto]
ckevalid enable [Auto]
idle enable [Auto]
selfrefresh enable [Auto]
Address mirror [Auto]
no gear4 param divide [Auto]
x8 device [Auto]
no gear2 param divide [Auto]
ddr 1dpc split ranks on subch [Auto]
write0 enable [Auto]
MultiCycCmd [Auto]
WCKDiffLowInIdle [Auto]
PBR Disable [Auto]
PBR OOO Dis [Auto]
PBR Disable on hot [Auto]
PBR Exit on Idle Cnt [Auto]
tXSR [Auto]
Dec tCWL [Auto]
Add tCWL [Auto]
Add 1Qclk delay [Auto]
MRC Fast Boot [Disabled]
MCH Full Check [Auto]
Mem Over Clock Fail Count [2]
Training Profile [Auto]
RxDfe [Auto]
Mrc Training Loop Count [2]
DRAM CLK Period [Auto]
Dll_bwsel [Auto]
Controller 0, Channel 0 Control [Enabled]
Controller 0, Channel 1 Control [Enabled]
Controller 1, Channel 0 Control [Enabled]
Controller 1, Channel 1 Control [Enabled]
MC_Vref0 [Auto]
MC_Vref1 [Auto]
MC_Vref2 [Auto]
Fine Granularity Refresh mode [Auto]
SDRAM Density Per Die [Auto]
SDRAM Banks Per Bank Group [Auto]
SDRAM Bank Groups [Auto]
Dynamic Memory Boost [Disabled]
Realtime Memory Frequency [Disabled]
SA GV [Disabled]
Voltage Monitor [Die Sense]
VRM Initialization Check [Enabled]
CPU Input Voltage Load-line Calibration [Auto]
CPU Load-line Calibration [Auto]
Synch ACDC Loadline with VRM Loadline [Disabled]
CPU Current Capability [Auto]
CPU Current Reporting [Auto]
Core Voltage Suspension [Auto]
CPU VRM Switching Frequency [Auto]
VRM Spread Spectrum [Auto]
CPU Power Duty Control [Auto]
CPU Power Phase Control [Auto]
CPU Power Thermal Control [125]
CPU Core/Cache Boot Voltage [Auto]
CPU Input Boot Voltage [Auto]
PLL Termination Boot Voltage [Auto]
CPU Standby Boot Voltage [Auto]
Memory Controller Boot Voltage [Auto]
CPU Core Auto Voltage Cap [Auto]
CPU Input Auto Voltage Cap [Auto]
Memory Controller Auto Voltage Cap [Auto]
Fast Throttle Threshold [Auto]
Package Temperature Threshold [Auto]
Regulate Frequency by above Threshold [Auto]
IVR Transmitter VDDQ ICCMAX [Auto]
Unlimited ICCMAX [Auto]
CPU Core/Cache Current Limit Max. [420.00]
Long Duration Package Power Limit [Auto]
Package Power Time Window [Auto]
Short Duration Package Power Limit [Auto]
Dual Tau Boost [Disabled]
IA AC Load Line [0.30]
IA DC Load Line [Auto]
IA CEP Enable [Disabled]
SA CEP Enable [Disabled]
IA SoC Iccmax Reactive Protector [Auto]
Inverse Temperature Dependency Throttle [Auto]
IA VR Voltage Limit [1650]
CPU SVID Support [Auto]
Cache Dynamic OC Switcher [Auto]
TVB Voltage Optimizations [Enabled]
Enhanced TVB [Enabled]
Overclocking TVB [Boost Until Target]
Max Boost Target in MHz [Auto]
Overclocking TVB Global Temperature Offset Sign [+]
Overclocking TVB Global Temperature Offset Value [Auto]
Offset Mode Sign 1 [+]
V/F Point 1 Offset [Auto]
Offset Mode Sign 2 [+]
V/F Point 2 Offset [Auto]
Offset Mode Sign 3 [+]
V/F Point 3 Offset [Auto]
Offset Mode Sign 4 [+]
V/F Point 4 Offset [Auto]
Offset Mode Sign 5 [-]
V/F Point 5 Offset [0.01000]
Offset Mode Sign 6 [-]
V/F Point 6 Offset [0.03000]
Offset Mode Sign 7 [-]
V/F Point 7 Offset [0.03000]
Offset Mode Sign 8 [-]
V/F Point 8 Offset [0.03000]
Offset Mode Sign 9 [-]
V/F Point 9 Offset [0.04000]
Offset Mode Sign 10 [-]
V/F Point 10 Offset [0.04000]
Offset Mode Sign 11 [-]
V/F Point 11 Offset [0.04000]
Initial BCLK Frequency [Auto]
Runtime BCLK OC [Auto]
BCLK Amplitude [Auto]
BCLK Slew Rate [Auto]
BCLK Spread Spectrum [Auto]
Initial PCIE Frequency [Auto]
PCIE/DMI Amplitude [Auto]
PCIE/DMI Slew Rate [Auto]
PCIE/DMI Spread Spectrum [Auto]
Cold Boot PCIE Frequency [Auto]
Realtime Memory Timing [Disabled]
SPD Write Disable [TRUE]
PVD Ratio Threshold [Auto]
SA PLL Frequency Override [Auto]
BCLK TSC HW Fixup [Enabled]
Core Ratio Extension Mode [Disabled]
FLL OC mode [Auto]
UnderVolt Protection [Disabled]
Switch Microcode [Current Microcode]
Xtreme Tweaking [Disabled]
Core PLL Voltage [Auto]
GT PLL Voltage [Auto]
Ring PLL Voltage [Auto]
System Agent PLL Voltage [Auto]
Memory Controller PLL Voltage [Auto]
Efficient-core PLL Voltage [Auto]
CPU 1.8V Small Rail [Auto]
PLL Termination Voltage [Auto]
CPU Standby Voltage [Auto]
PCH 1.05V Voltage [Auto]
PCH 0.82V Voltage [Auto]
CPU Input Voltage Reset Voltage [Auto]
Eventual CPU Input Voltage [Auto]
Eventual Memory Controller Voltage [Auto]
Package Temperature Threshold [Auto]
Regulate Frequency by above Threshold [Auto]
Cooler Efficiency Customize [Keep Training]
Cooler Re-evaluation Algorithm [Normal]
Optimism Scale [100]
Ring Down Bin [Auto]
Min. CPU Cache Ratio [Auto]
Max. CPU Cache Ratio [Auto]
BCLK Aware Adaptive Voltage [Auto]
Actual VRM Core Voltage [Auto]
Global Core SVID Voltage [Auto]
Cache SVID Voltage [Auto]
CPU L2 Voltage [Auto]
CPU System Agent Voltage [Manual Mode]
- CPU System Agent Voltage Override [1.12000]
CPU Input Voltage [Auto]
High DRAM Voltage Mode [Enabled]
DRAM VDD Voltage [1.45000]
DRAM VDDQ Voltage [1.43000]
IVR Transmitter VDDQ Voltage [1.24000]
Memory Controller Voltage [1.21250]
MC Voltage Calculation Voltage Base [Auto]
VDD Calculation Voltage Base [Auto]
PMIC Voltages [Auto]
PCI Express Native Power Management [Enabled]
Native ASPM [Disabled]
DMI Link ASPM Control [Disabled]
ASPM [Auto]
L1 Substates [Disabled]
DMI ASPM [Disabled]
DMI Gen3 ASPM [Disabled]
PEG - ASPM [Disabled]
PCI Express Clock Gating [Enabled]
Hardware Prefetcher [Enabled]
Adjacent Cache Line Prefetch [Enabled]
Intel (VMX) Virtualization Technology [Disabled]
Per P-Core Control [Disabled]
Per E-Core Control [Disabled]
Active Performance Cores [All]
Active Efficient Cores [All]
Hyper-Threading [Enabled]
Hyper-Threading of Core 0 [Enabled]
Hyper-Threading of Core 1 [Enabled]
Hyper-Threading of Core 2 [Enabled]
Hyper-Threading of Core 3 [Enabled]
Hyper-Threading of Core 4 [Enabled]
Hyper-Threading of Core 5 [Enabled]
Hyper-Threading of Core 6 [Enabled]
Hyper-Threading of Core 7 [Enabled]
Total Memory Encryption [Disabled]
Legacy Game Compatibility Mode [Disabled]
Boot performance mode [Auto]
Intel(R) SpeedStep(tm) [Enabled]
Intel(R) Speed Shift Technology [Disabled]
Turbo Mode [Enabled]
Acoustic Noise Mitigation [Disabled]
CPU C-states [Auto]
Thermal Monitor [Enabled]
Dual Tau Boost [Disabled]
VT-d [Disabled]
Memory Remap [Enabled]
Enable VMD controller [Enabled]
Map PCIE Storage under VMD [Disabled]
Map SATA Controller under VMD [Disabled]
M.2_1 Link Speed [Auto]
PCIEX16(G5)_1 Link Speed [Auto]
PCIEX16(G5)_2 Link Speed [Auto]
PCIEX1(G4) Link Speed [Auto]
PCIEX4(G4) Link Speed [Auto]
M.2_2 Link Speed [Auto]
DIMM.2_1 Link Speed [Auto]
DIMM.2_2 Link Speed [Auto]
SATA Controller(s) [Enabled]
Aggressive LPM Support [Disabled]
SMART Self Test [Enabled]
M.2_3 [Enabled]
M.2_3 Hot Plug [Disabled]
SATA6G_1 [Enabled]
SATA6G_1 Hot Plug [Disabled]
SATA6G_2 [Enabled]
SATA6G_2 Hot Plug [Disabled]
SATA6G_3 [Enabled]
SATA6G_3 Hot Plug [Disabled]
SATA6G_4 [Enabled]
SATA6G_4 Hot Plug [Disabled]
PTT [Enable]
Intel(R) Dynamic Tuning Technology [Disabled]
PCIE Tunneling over USB4 [Enabled]
Discrete Thunderbolt(TM) Support [Disabled]
Security Device Support [Enable]
SHA256 PCR Bank [Enabled]
Pending operation [None]
Platform Hierarchy [Enabled]
Storage Hierarchy [Enabled]
Endorsement Hierarchy [Enabled]
Physical Presence Spec Version [1.3]
Disable Block Sid [Disabled]
Password protection of Runtime Variables [Enable]
Above 4G Decoding [Enabled]
Resize BAR Support [Enabled]
SR-IOV Support [Disabled]
Legacy USB Support [Enabled]
XHCI Hand-off [Enabled]
SanDisk [Auto]
LAN_U32G2_1 [Enabled]
U32G1_E5 [Enabled]
U32G1_E6 [Enabled]
U32G1_E7 [Enabled]
U32G1_E8 [Enabled]
U32G2X2_C3 [Enabled]
U32G2_5 [Enabled]
U32G2_6 [Enabled]
U32G2_7 [Enabled]
U32G2_P8 [Enabled]
U32G2X2_C9 [Enabled]
U32G1_E1 [Enabled]
U32G1_E2 [Enabled]
U32G1_E3 [Enabled]
U32G1_E4 [Enabled]
Network Stack [Disabled]
Device [N/A]
Restore AC Power Loss [Power Off]
Max Power Saving [Disabled]
ErP Ready [Disabled]
Power On By PCI-E [Disabled]
Power On By RTC [Disabled]
USB Audio [Enabled]
Intel LAN [Enabled]
USB power delivery in Soft Off state (S5) [Disabled]
Connectivity mode (Wi-Fi & Bluetooth) [Disabled]
When system is in working state [All On]
Q-Code LED Function [POST Code Only]
When system is in sleep, hibernate or soft off states [All On]
M.2_2 Configuration [Auto]
ASMedia USB 3.2 Controller_U32G1_E12 [Enabled]
ASMedia USB 3.2 Controller_U32G1_E34 [Enabled]
GNA Device [Disabled]
ASMedia Storage Controller [Enabled]
Windows Hot-plug Notification [Disabled]
ASPM Support [Disabled]
CPU Temperature [Monitor]
CPU Package Temperature [Monitor]
MotherBoard Temperature [Monitor]
VRM Temperature [Monitor]
Chipset Temperature [Monitor]
T_Sensor Temperature [Monitor]
DIMM.2 Sensor 1 Temperature [Monitor]
DIMM.2 Sensor 2 Temperature [Monitor]
Water In T Sensor Temperature [Monitor]
Water Out T Sensor Temperature [Monitor]
DIMM A1 Temperature [Monitor]
DIMM B1 Temperature [Monitor]
CPU Fan Speed [Monitor]
CPU Optional Fan Speed [Monitor]
Chassis Fan 1 Speed [Monitor]
Chassis Fan 2 Speed [Monitor]
Chassis Fan 3 Speed [Monitor]
Water Pump+ Speed [Monitor]
AIO Pump Speed [Monitor]
Flow Rate [Monitor]
CPU Core Voltage [Monitor]
12V Voltage [Monitor]
5V Voltage [Monitor]
3.3V Voltage [Monitor]
Memory Controller Voltage [Monitor]
CPU Fan Q-Fan Control [DC Mode]
CPU Fan Profile [Standard]
CPU Fan Q-Fan Source [CPU]
CPU Fan Step Up [Level 0]
CPU Fan Step Down [Level 4]
CPU Fan Speed Low Limit [200 RPM]
Chassis Fan 1 Q-Fan Control [Auto Detect]
Chassis Fan 1 Profile [Standard]
Chassis Fan 1 Q-Fan Source [CPU]
Chassis Fan 1 Step Up [Level 0]
Chassis Fan 1 Step Down [Level 0]
Chassis Fan 1 Speed Low Limit [200 RPM]
Chassis Fan 2 Q-Fan Control [PWM Mode]
Chassis Fan 2 Profile [Standard]
Chassis Fan 2 Q-Fan Source [Chipset]
Chassis Fan 2 Step Up [Level 0]
Chassis Fan 2 Step Down [Level 4]
Chassis Fan 2 Speed Low Limit [200 RPM]
Chassis Fan 3 Q-Fan Control [DC Mode]
Chassis Fan 3 Profile [Silent]
Chassis Fan 3 Q-Fan Source [CPU]
Chassis Fan 3 Step Up [Level 0]
Chassis Fan 3 Step Down [Level 0]
Chassis Fan 3 Speed Low Limit [200 RPM]
Water Pump+ Q-Fan Control [PWM Mode]
Water Pump+ Profile [Manual]
Water Pump+ Q-Fan Source [CPU]
Water Pump+ Step Up [Level 0]
Water Pump+ Step Down [Level 4]
Water Pump+ Speed Low Limit [Ignore]
Water Pump+ Point4 Temperature [70]
Water Pump+ Point4 Duty Cycle (%) [100]
Water Pump+ Point3 Temperature [50]
Water Pump+ Point3 Duty Cycle (%) [85]
Water Pump+ Point2 Temperature [40]
Water Pump+ Point2 Duty Cycle (%) [80]
Water Pump+ Point1 Temperature [25]
Water Pump+ Point1 Duty Cycle (%) [60]
AIO Pump Q-Fan Control [Auto Detect]
AIO Pump Profile [Full Speed]
CPU Temperature LED Switch [Enabled]
Launch CSM [Disabled]
OS Type [Other OS]
Secure Boot Mode [Custom]
Fast Boot [Enabled]
Next Boot after AC Power Loss [Fast Boot]
Boot Logo Display [Auto]
POST Delay Time [3 sec]
Bootup NumLock State [On]
Wait For 'F1' If Error [Enabled]
Option ROM Messages [Force BIOS]
Interrupt 19 Capture [Disabled]
AMI Native NVMe Driver Support [Enabled]
Setup Mode [Advanced Mode]
Boot Sector (MBR/GPT) Recovery Policy [Local User Control]
Next Boot Recovery Action [Skip]
BIOS Image Rollback Support [Enabled]
Publish HII Resources [Disabled]
Flexkey [Safe Boot]
Setup Animator [Disabled]
Load from Profile [7]
Profile Name [test]
Save to Profile [3]
DIMM Slot Number [DIMM_A1]
Download & Install ARMOURY CRATE app [Disabled]
Download & Install MyASUS service & app [Disabled] -
sz.9
tag
Sziasztok! Van 2 db wifis IP kamerám amelyek jelenleg is üzemelnek, SD kártyás rögzítéssel. Wifin keresztül vannak a hálózaton, stabil kapcsolattal. Szeretnék egy NVR rögzítőt vásárolni a kényelmesebb visszakeresés és esetenként videó fájlt kimenteni/átmásolni megőrzésre, stb. funkciók miatt. Az lenne a kérdésem, hogy Wifis NVR-t kell vásárolnom vagy bármelyik alkalmas lehet és a routerhez csatlakoztatva tudja majd rögzíteni a két wifivel a hálózaton lévő kamerám képeit?
Előre is köszönöm és elnézést, ha már lerágott csont a kérdésem, de elbizonytalanodtam a keresgélés közepette. -
Golden9
veterán
26. Sorszélesség.
A.......................................................................................................................................AB.......................................................................................................................................BC.......................................................................................................................................C -
#13350
homerhamm
addikt
Intruder2k5
#13345
homerhamm
addikt
válasz
Intruder2k5
#13345
üzenetére
Mi lett a végső eredmény?
-
#13349
4Grider
nagyúr
Hullyzsolt24
#13348
4Grider
nagyúr
válasz
Hullyzsolt24
#13348
üzenetére
-
#13348
Hullyzsolt24
újonc
Hullyzsolt24
újonc
Üdv Mindenkinek!
Vettem egy Hikvision ip kamerát, és a beállított jelszót 2x rosszul irtam be, és így letiltott.
Felvettem a kapcsolatot a Riel céggel, mert azt az informáciot kaptam, hogy ők tudnak nekem segíteni a jelszó visszaállitásában.
Mivel nem vagyok szerződött partnerük, így megtagadták a segítséget. Azt irták, hogy van más lehetőség is, hogy visszaállítsam a jelszót, de nem találram semmit.
Valaki tudna benne segiteni? -
pictigjis - 2023-10-10 - Kölyök tigris - forráskép - kész
bucsher - 2023-08-14 - Ferro, Aliens - forráskép - kész - (CSERE)
Neurotoxin - 2023-08-22 - Kirk Hammett, gitáros - forráskép - kész (CSERE)
Sumptuous - 2023-08-29 - Paladins, Mal'Damba, játék - forráskép - kész
pergabb - 2023-12-10 - dinoszaurusz, dínó, T-Rex, Tyrannosaurus Rex - SZABAD - kész
Yodamest - 2023-08-21 - Nelliel Tu Odelschwanck, Bleach, Nel Tu - forráskép - kész
7etape - 2023-09-01 - Denis Leary, Ments meg, sorozat - forráskép - kész (CSERE)
Lacielvtárs - 2023-09-08 - Tifa Lockhart, Final Fantasy - forrásképek - kész (CSERE)
suhico - 2023-10-08 - Erik Killmonger, Marvel - forráskép - kész
Rowon - 2023-10-24 - Toy Story, Squeeze - forráskép - kész
Dévacsen - 2023-12-16 - Hob, játék, (SZABAD) - kész
olle - 2023-10-10 - Escape From Tarkov, Killa - forráskép - kész
hanti - 2023-11-14 - Captain Pike, Star Trek, USS Enterprise - forráskép - kész
sylex - 2023-09-04 - Pablo Escobar - forráskép - kész (nevet váltott)
Mauzes - 2023-10-05 - Agent 47, Hitman - forráskép - kész
Norbi. - 2023-11-15 - Johnny Cage, Mortal Kombat - forráskép1, forráskép2 - kész (CSERE)
ferni - 2023-10-27 - Majom, Eye Toy Play, PS2, játék- forráskép - kész
mayday00 - 2023-11-05 - Dipper Pines, Gravity Falls, Disney - forráskép (CSERE) - kész
Pakmara - 2023-11-22 - Pak'ma'ra, Babylon 5, sci-fi - forráskép - kész
Guitar14 - 2023-11-15 - Doomslayer - forráskép - kész
cof - 2023-12-12- önarckép - forráskép, plusz kérés - kész
HREH - 2023-10-25 - Naruto, Sasuke - forráskép - kész
Phoen|x - 2023-10-09 - Radagon, Elden Ring, játék - forráskép - kész
Dani_kp - 2023-11-26 - Robotember, Robot Man, Doom Patrol - forráskép - kész
xmad - 2023-12-06 - Pedro Pascal, Narcos- forráskép - kész -
zebra_hun
veterán
[2023/12/19 12:01:55]
Ai Overclock Tuner [Auto]
Intel(R) Adaptive Boost Technology [Auto]
ASUS MultiCore Enhancement [Auto – Lets BIOS Optimize]
SVID Behavior [Auto]
BCLK Frequency : DRAM Frequency Ratio [100:100]
Memory Controller : DRAM Frequency Ratio [1:2]
DRAM Frequency [DDR5-7200MHz]
Performance Core Ratio [By Core Usage]
1-Core Ratio Limit [58]
2-Core Ratio Limit [58]
3-Core Ratio Limit [57]
4-Core Ratio Limit [57]
5-Core Ratio Limit [56]
6-Core Ratio Limit [56]
7-Core Ratio Limit [55]
8-Core Ratio Limit [55]
Performance Core0 Specific Ratio Limit [Auto]
Performance Core0 specific Voltage [Auto]
Performance Core1 Specific Ratio Limit [Auto]
Performance Core1 specific Voltage [Auto]
*Performance Core2 Specific Ratio Limit [Auto]
Performance Core2 specific Voltage [Auto]
*Performance Core3 Specific Ratio Limit [Auto]
Performance Core3 specific Voltage [Auto]
Performance Core4 Specific Ratio Limit [Auto]
Performance Core4 specific Voltage [Auto]
Performance Core5 Specific Ratio Limit [Auto]
Performance Core5 specific Voltage [Auto]
Performance Core6 Specific Ratio Limit [Auto]
Performance Core6 specific Voltage [Auto]
Performance Core7 Specific Ratio Limit [Auto]
Performance Core7 specific Voltage [Auto]
Efficient Core Ratio [By Core Usage]
Efficient Turbo Ratio Limit 1 [44]
Efficient Turbo Ratio Cores 1 [Auto]
Efficient Core Group0 Specific Ratio Limit [45]
Efficient Core Group0 specific Voltage [Auto]
Efficient Core Group1 Specific Ratio Limit [45]
Efficient Core Group1 specific Voltage [Auto]
Efficient Core Group2 Specific Ratio Limit [45]
Efficient Core Group2 specific Voltage [Auto]
Efficient Core Group3 Specific Ratio Limit [45]
Efficient Core Group3 specific Voltage [Auto]
AVX2 [Enabled]
AVX2 Ratio Offset to per-core Ratio Limit [User Specify]
AVX2 Ratio Offset [0]
AVX2 Voltage Guardband Scale Factor [User Specify]
AVX2 Voltage Guardband Scale Factor [0]
Maximus Tweak [Mode 2]
DRAM CAS# Latency [30]
DRAM RAS# to CAS# Delay Read [41]
DRAM RAS# to CAS# Delay Write [17]
DRAM RAS# PRE Time [41]
DRAM RAS# ACT Time [53]
DRAM Command Rate [2N]
DRAM RAS# to RAS# Delay L [12]
DRAM RAS# to RAS# Delay S [8]
DRAM REF Cycle Time 2 [448]
DRAM REF Cycle Time Same Bank [Auto]
DRAM Refresh Interval [171071]
DRAM WRITE Recovery Time [24]
DRAM READ to PRE Time [12]
DRAM FOUR ACT WIN Time [32]
DRAM WRITE to READ Delay L [18]
DRAM WRITE to READ Delay S [6]
DRAM CKE Minimum Pulse Width [Auto]
DRAM Write Latency [28]
Ctl0 dqvrefup [154]
Ctl0 dqvrefdn [72]
Ctl0 dqodtvrefup [Auto]
Ctl0 dqodtvrefdn [Auto]
Ctl1 cmdvrefup [Auto]
Ctl1 ctlvrefup [Auto]
Ctl1 clkvrefup [Auto]
Ctl1 ckecsvrefup [Auto]
Ctl2 cmdvrefdn [Auto]
Ctl2 ctlvrefdn [Auto]
Ctl2 clkvrefdn [Auto]
Read Equalization RxEq Start Sign [-]
Read Equalization RxEq Start [Auto]
Read Equalization RxEq Stop Sign [-]
Read Equalization RxEq Stop [Auto]
ODT_READ_DURATION [Auto]
ODT_READ_DELAY [Auto]
ODT_WRITE_DURATION [Auto]
ODT_WRITE_DELAY [Auto]
DQ RTT WR [40 DRAM Clock]
DQ RTT NOM RD [40 DRAM Clock]
DQ RTT NOM WR [40 DRAM Clock]
DQ RTT PARK [34 DRAM Clock]
DQ RTT PARK DQS [34 DRAM Clock]
GroupA CA ODT [240 DRAM Clock]
GroupA CS ODT [0 DRAM Clock]
GroupA CK ODT [0 DRAM Clock]
GroupB CA ODT [60 DRAM Clock]
GroupB CS ODT [40 DRAM Clock]
GroupB CK ODT [40 DRAM Clock]
Pull-up Output Driver Impedance [34 DRAM Clock]
Pull-Down Output Driver Impedance [34 DRAM Clock]
DQ RTT WR [40 DRAM Clock]
DQ RTT NOM RD [40 DRAM Clock]
DQ RTT NOM WR [40 DRAM Clock]
DQ RTT PARK [34 DRAM Clock]
DQ RTT PARK DQS [34 DRAM Clock]
GroupA CA ODT [240 DRAM Clock]
GroupA CS ODT [0 DRAM Clock]
GroupA CK ODT [0 DRAM Clock]
GroupB CA ODT [60 DRAM Clock]
GroupB CS ODT [40 DRAM Clock]
GroupB CK ODT [40 DRAM Clock]
Pull-up Output Driver Impedance [34 DRAM Clock]
Pull-Down Output Driver Impedance [34 DRAM Clock]
Round Trip Latency Init Value MC0 CHA [Auto]
Round Trip Latency Max Value MC0 CHA [Auto]
Round Trip Latency Offset Value Mode Sign MC0 CHA [-]
Round Trip Latency Offset Value MC0 CHA [Auto]
Round Trip Latency Init Value MC0 CHB [Auto]
Round Trip Latency Max Value MC0 CHB [Auto]
Round Trip Latency Offset Value Mode Sign MC0 CHB [-]
Round Trip Latency Offset Value MC0 CHB [Auto]
Round Trip Latency Init Value MC1 CHA [Auto]
Round Trip Latency Max Value MC1 CHA [Auto]
Round Trip Latency Offset Value Mode Sign MC1 CHA [-]
Round Trip Latency Offset Value MC1 CHA [Auto]
Round Trip Latency Init Value MC1 CHB [Auto]
Round Trip Latency Max Value MC1 CHB [Auto]
Round Trip Latency Offset Value Mode Sign MC1 CHB [-]
Round Trip Latency Offset Value MC1 CHB [Auto]
Round Trip Latency MC0 CHA R0 [Auto]
Round Trip Latency MC0 CHA R1 [Auto]
Round Trip Latency MC0 CHA R2 [0]
Round Trip Latency MC0 CHA R3 [0]
Round Trip Latency MC0 CHA R4 [0]
Round Trip Latency MC0 CHA R5 [0]
Round Trip Latency MC0 CHA R6 [0]
Round Trip Latency MC0 CHA R7 [0]
Round Trip Latency MC0 CHB R0 [Auto]
Round Trip Latency MC0 CHB R1 [Auto]
Round Trip Latency MC0 CHB R2 [0]
Round Trip Latency MC0 CHB R3 [0]
Round Trip Latency MC0 CHB R4 [0]
Round Trip Latency MC0 CHB R5 [0]
Round Trip Latency MC0 CHB R6 [0]
Round Trip Latency MC0 CHB R7 [0]
Round Trip Latency MC1 CHA R0 [Auto]
Round Trip Latency MC1 CHA R1 [Auto]
Round Trip Latency MC1 CHA R2 [0]
Round Trip Latency MC1 CHA R3 [0]
Round Trip Latency MC1 CHA R4 [0]
Round Trip Latency MC1 CHA R5 [0]
Round Trip Latency MC1 CHA R6 [0]
Round Trip Latency MC1 CHA R7 [0]
Round Trip Latency MC1 CHB R0 [Auto]
Round Trip Latency MC1 CHB R1 [Auto]
Round Trip Latency MC1 CHB R2 [0]
Round Trip Latency MC1 CHB R3 [0]
Round Trip Latency MC1 CHB R4 [0]
Round Trip Latency MC1 CHB R5 [0]
Round Trip Latency MC1 CHB R6 [0]
Round Trip Latency MC1 CHB R7 [0]
Early Command Training [Auto]
SenseAmp Offset Training [Auto]
Early ReadMPR Timing Centering 2D [Auto]
Read MPR Training [Auto]
Receive Enable Training [Auto]
Jedec Write Leveling [Auto]
Early Write Time Centering 2D [Auto]
Early Read Time Centering 2D [Auto]
Write Timing Centering 1D [Auto]
Write Voltage Centering 1D [Auto]
Read Timing Centering 1D [Auto]
Read Timing Centering with JR [Auto]
Dimm ODT Training* [Disabled]
Max RTT_WR [ODT Off]
DIMM RON Training* [Auto]
Write Drive Strength/Equalization 2D* [Auto]
Write Slew Rate Training* [Auto]
Read ODT Training* [Auto]
Comp Optimization Training [Auto]
Read Equalization Training* [Auto]
Read Amplifier Training* [Auto]
Write Timing Centering 2D [Auto]
Read Timing Centering 2D [Auto]
Command Voltage Centering [Auto]
Early Command Voltage Centering [Auto]
Write Voltage Centering 2D [Auto]
Read Voltage Centering 2D [Auto]
Late Command Training [Auto]
Round Trip Latency [Enabled]
Turn Around Timing Training [Auto]
CMD CTL CLK Slew Rate [Auto]
CMD/CTL DS & E 2D [Auto]
Read Voltage Centering 1D [Auto]
TxDqTCO Comp Training* [Auto]
ClkTCO Comp Training* [Auto]
TxDqsTCO Comp Training* [Auto]
VccDLL Bypass Training [Auto]
CMD/CTL Drive Strength Up/Dn 2D [Auto]
DIMM CA ODT Training [Auto]
PanicVttDnLp Training* [Auto]
Read Vref Decap Training* [Auto]
Vddq Training [Auto]
Duty Cycle Correction Training [Auto]
Periodic DCC [Auto]
Rank Margin Tool Per Bit [Auto]
DIMM DFE Training [Auto]
EARLY DIMM DFE Training [Auto]
Tx Dqs Dcc Training [Auto]
DRAM DCA Training [Auto]
Write Driver Strength Training [Auto]
Rank Margin Tool [Auto]
Memory Test [Auto]
DIMM SPD Alias Test [Auto]
Receive Enable Centering 1D [Auto]
Retrain Margin Check [Auto]
Write Drive Strength Up/Dn independently [Auto]
LPDDR DqDqs Re-Training [Auto]
Margin Check Limit [Disabled]
tRDRD_sg_Training [Auto]
tRDRD_sg_Runtime [16]
tRDRD_dg_Training [Auto]
tRDRD_dg_Runtime [8]
tRDWR_sg [20]
tRDWR_dg [20]
tWRWR_sg [16]
tWRWR_dg [8]
tWRRD_sg [Auto]
tWRRD_dg [Auto]
tRDRD_dr [0]
tRDRD_dd [Auto]
tRDWR_dr [0]
tRDWR_dd [Auto]
tWRWR_dr [0]
tWRWR_dd [Auto]
tWRRD_dr [0]
tWRRD_dd [Auto]
tRPRE [Auto]
tWPRE [Auto]
tWPOST [Auto]
tWRPRE [Auto]
tPRPDEN [Auto]
tRDPDEN [Auto]
tWRPDEN [Auto]
tCPDED [Auto]
tREFIX9 [Auto]
Ref Interval [Auto]
tXPDLL [Auto]
tXP [Auto]
tPPD [Auto]
tCCD_L_tDLLK [Auto]
tZQCAL [Auto]
tZQCS [Auto]
OREF_RI [Auto]
Refresh Watermarks [High]
Refresh Hp Wm [Auto]
Refresh Panic Wm [Auto]
Refresh Abr Release [Auto]
tXSDLL [Auto]
tZQOPER [Auto]
tMOD [Auto]
CounttREFIWhileRefEn [Auto]
HPRefOnMRS [Auto]
SRX Ref Debits [Auto]
RAISE BLK WAIT [Auto]
Ref Stagger En [Auto]
Ref Stagger Mode [Auto]
Disable Stolen Refresh [Auto]
En Ref Type Display [Auto]
Trefipulse Stagger Disable [Auto]
tRPab ext [Auto]
derating ext [Auto]
Allow 2cyc B2B LPDDR [Auto]
tCSH [Auto]
tCSL [Auto]
powerdown Enable [Auto]
idle length [Auto]
raise cke after exit latency [Auto]
powerdown latency [Auto]
powerdown length [Auto]
selfrefresh latency [Auto]
selfrefresh length [Auto]
ckevalid length [Auto]
ckevalid enable [Auto]
idle enable [Auto]
selfrefresh enable [Auto]
Address mirror [Auto]
no gear4 param divide [Auto]
x8 device [Auto]
no gear2 param divide [Auto]
ddr 1dpc split ranks on subch [Auto]
write0 enable [Auto]
MultiCycCmd [Auto]
WCKDiffLowInIdle [Auto]
PBR Disable [Auto]
PBR OOO Dis [Auto]
PBR Disable on hot [Auto]
PBR Exit on Idle Cnt [Auto]
tXSR [Auto]
Dec tCWL [Auto]
Add tCWL [Auto]
Add 1Qclk delay [Auto]
MRC Fast Boot [Disabled]
MCH Full Check [Enabled]
Mem Over Clock Fail Count [2]
Training Profile [Auto]
RxDfe [Auto]
Mrc Training Loop Count [2]
DRAM CLK Period [Auto]
Dll_bwsel [Auto]
Controller 0, Channel 0 Control [Enabled]
Controller 0, Channel 1 Control [Enabled]
Controller 1, Channel 0 Control [Enabled]
Controller 1, Channel 1 Control [Enabled]
MC_Vref0 [Auto]
MC_Vref1 [Auto]
MC_Vref2 [Auto]
Fine Granularity Refresh mode [Auto]
SDRAM Density Per Die [Auto]
SDRAM Banks Per Bank Group [Auto]
SDRAM Bank Groups [Auto]
Dynamic Memory Boost [Disabled]
Realtime Memory Frequency [Disabled]
SA GV [Disabled]
Voltage Monitor [Die Sense]
VRM Initialization Check [Enabled]
CPU Input Voltage Load-line Calibration [Auto]
CPU Load-line Calibration [Level 5]
Synch ACDC Loadline with VRM Loadline [Disabled]
CPU Current Capability [Auto]
CPU Current Reporting [Auto]
Core Voltage Suspension [Auto]
CPU VRM Switching Frequency [Manual]
Fixed CPU VRM Switching Frequency(KHz) [300]
CPU Power Duty Control [T.Probe]
CPU Power Phase Control [Optimized]
CPU Power Thermal Control [125]
CPU Core/Cache Boot Voltage [Auto]
CPU Input Boot Voltage [Auto]
PLL Termination Boot Voltage [Auto]
CPU Standby Boot Voltage [Auto]
Memory Controller Boot Voltage [Auto]
CPU Core Auto Voltage Cap [Auto]
CPU Input Auto Voltage Cap [Auto]
Memory Controller Auto Voltage Cap [Auto]
Maximum CPU Core Temperature [85]
Fast Throttle Threshold [Auto]
Package Temperature Threshold [Auto]
Regulate Frequency by above Threshold [Auto]
IVR Transmitter VDDQ ICCMAX [Auto]
Unlimited ICCMAX [Auto]
CPU Core/Cache Current Limit Max. [Auto]
Long Duration Package Power Limit [255]
Package Power Time Window [Auto]
Short Duration Package Power Limit [270]
Dual Tau Boost [Disabled]
IA AC Load Line [0.01]
IA DC Load Line [0.84]
IA CEP Enable [Auto]
SA CEP Enable [Auto]
IA SoC Iccmax Reactive Protector [Auto]
Inverse Temperature Dependency Throttle [Auto]
IA VR Voltage Limit [1500]
CPU SVID Support [Auto]
Cache Dynamic OC Switcher [Disabled]
TVB Voltage Optimizations [Disabled]
Enhanced TVB [Disabled]
Overclocking TVB [Disabled]
Overclocking TVB Global Temperature Offset Sign [+]
Overclocking TVB Global Temperature Offset Value [Auto]
Offset Mode Sign 1 [+]
V/F Point 1 Offset [Auto]
Offset Mode Sign 2 [+]
V/F Point 2 Offset [Auto]
Offset Mode Sign 3 [+]
V/F Point 3 Offset [Auto]
Offset Mode Sign 4 [+]
V/F Point 4 Offset [Auto]
Offset Mode Sign 5 [+]
V/F Point 5 Offset [Auto]
Offset Mode Sign 6 [+]
V/F Point 6 Offset [Auto]
Offset Mode Sign 7 [+]
V/F Point 7 Offset [Auto]
Offset Mode Sign 8 [+]
V/F Point 8 Offset [Auto]
Offset Mode Sign 9 [+]
V/F Point 9 Offset [Auto]
Offset Mode Sign 10 [+]
V/F Point 10 Offset [Auto]
Offset Mode Sign 11 [+]
V/F Point 11 Offset [Auto]
Initial BCLK Frequency [Auto]
Runtime BCLK OC [Auto]
BCLK Amplitude [Auto]
BCLK Slew Rate [Auto]
BCLK Spread Spectrum [Auto]
Initial PCIE Frequency [Auto]
PCIE/DMI Amplitude [Auto]
PCIE/DMI Slew Rate [Auto]
PCIE/DMI Spread Spectrum [Auto]
Cold Boot PCIE Frequency [Auto]
Realtime Memory Timing [Disabled]
SPD Write Disable [TRUE]
PVD Ratio Threshold [Auto]
SA PLL Frequency Override [Auto]
BCLK TSC HW Fixup [Enabled]
Core Ratio Extension Mode [Disabled]
FLL OC mode [Auto]
UnderVolt Protection [Disabled]
Switch Microcode [Current Microcode]
Xtreme Tweaking [Disabled]
Core PLL Voltage [Auto]
GT PLL Voltage [Auto]
Ring PLL Voltage [Auto]
System Agent PLL Voltage [Auto]
Memory Controller PLL Voltage [Auto]
Efficient-core PLL Voltage [Auto]
CPU 1.8V Small Rail [Auto]
PLL Termination Voltage [Auto]
CPU Standby Voltage [Auto]
PCH 1.05V Voltage [Auto]
PCH 0.82V Voltage [Auto]
CPU Input Voltage Reset Voltage [Auto]
Eventual CPU Input Voltage [Auto]
Eventual Memory Controller Voltage [Auto]
Package Temperature Threshold [Auto]
Regulate Frequency by above Threshold [Auto]
Cooler Efficiency Customize [Keep Training]
Cooler Re-evaluation Algorithm [Normal]
Optimism Scale [100]
Ring Down Bin [Enabled]
Min. CPU Cache Ratio [8]
Max. CPU Cache Ratio [49]
BCLK Aware Adaptive Voltage [Auto]
Actual VRM Core Voltage [Auto]
Global Core SVID Voltage [Adaptive Mode]
- Offset Mode Sign [-]
- Additional Turbo Mode CPU Core Voltage [Auto]
- Offset Voltage [0.09500]
Cache SVID Voltage [Adaptive Mode]
- Offset Mode Sign [-]
- Additional Turbo Mode Cache Voltage [Auto]
- Offset Voltage [0.04000]
CPU L2 Voltage [Adaptive Mode]
- Offset Mode Sign [-]
- Additional Turbo Mode CPU L2 Voltage [Auto]
- Offset Voltage [0.02000]
CPU System Agent Voltage [Manual Mode]
- CPU System Agent Voltage Override [1.14500]
CPU Input Voltage [Auto]
High DRAM Voltage Mode [Enabled]
DRAM VDD Voltage [1.57000]
DRAM VDDQ Voltage [1.51000]
IVR Transmitter VDDQ Voltage [1.26000]
Memory Controller Voltage [1.23750]
MC Voltage Calculation Voltage Base [Auto]
VDD Calculation Voltage Base [Auto]
PMIC Voltages [Auto]
PCI Express Native Power Management [Enabled]
Native ASPM [Disabled]
DMI Link ASPM Control [Disabled]
ASPM [Auto]
L1 Substates [Disabled]
DMI ASPM [Disabled]
DMI Gen3 ASPM [Disabled]
PEG - ASPM [Disabled]
PCI Express Clock Gating [Enabled]
Hardware Prefetcher [Enabled]
Adjacent Cache Line Prefetch [Enabled]
Intel (VMX) Virtualization Technology [Disabled]
Per P-Core Control [Disabled]
Per E-Core Control [Disabled]
Active Performance Cores [All]
Active Efficient Cores [All]
Hyper-Threading [Enabled]
Hyper-Threading of Core 0 [Enabled]
Hyper-Threading of Core 1 [Enabled]
Hyper-Threading of Core 2 [Enabled]
Hyper-Threading of Core 3 [Enabled]
Hyper-Threading of Core 4 [Enabled]
Hyper-Threading of Core 5 [Enabled]
Hyper-Threading of Core 6 [Enabled]
Hyper-Threading of Core 7 [Enabled]
Total Memory Encryption [Disabled]
Legacy Game Compatibility Mode [Disabled]
Boot performance mode [Auto]
Intel(R) SpeedStep(tm) [Enabled]
Intel(R) Speed Shift Technology [Disabled]
Turbo Mode [Enabled]
Acoustic Noise Mitigation [Disabled]
CPU C-states [Auto]
Thermal Monitor [Enabled]
Dual Tau Boost [Disabled]
VT-d [Disabled]
Memory Remap [Enabled]
Enable VMD controller [Enabled]
Map PCIE Storage under VMD [Disabled]
Map SATA Controller under VMD [Disabled]
M.2_1 Link Speed [Auto]
PCIEX16(G5)_1 Link Speed [Auto]
PCIEX16(G5)_2 Link Speed [Auto]
PCIEX1(G4) Link Speed [Auto]
PCIEX4(G4) Link Speed [Auto]
M.2_2 Link Speed [Auto]
DIMM.2_1 Link Speed [Auto]
DIMM.2_2 Link Speed [Auto]
SATA Controller(s) [Enabled]
Aggressive LPM Support [Disabled]
SMART Self Test [Enabled]
M.2_3 [Enabled]
M.2_3 Hot Plug [Disabled]
SATA6G_1 [Enabled]
SATA6G_1 Hot Plug [Disabled]
SATA6G_2 [Enabled]
SATA6G_2 Hot Plug [Disabled]
SATA6G_3 [Enabled]
SATA6G_3 Hot Plug [Disabled]
SATA6G_4 [Enabled]
SATA6G_4 Hot Plug [Disabled]
PTT [Enable]
Intel(R) Dynamic Tuning Technology [Disabled]
PCIE Tunneling over USB4 [Enabled]
Discrete Thunderbolt(TM) Support [Disabled]
Security Device Support [Enable]
SHA256 PCR Bank [Enabled]
Pending operation [None]
Platform Hierarchy [Enabled]
Storage Hierarchy [Enabled]
Endorsement Hierarchy [Enabled]
Physical Presence Spec Version [1.3]
Disable Block Sid [Disabled]
Password protection of Runtime Variables [Enable]
Above 4G Decoding [Enabled]
Resize BAR Support [Enabled]
SR-IOV Support [Disabled]
Legacy USB Support [Enabled]
XHCI Hand-off [Enabled]
SanDisk [Auto]
LAN_U32G2_1 [Enabled]
U32G1_E5 [Enabled]
U32G1_E6 [Enabled]
U32G1_E7 [Enabled]
U32G1_E8 [Enabled]
U32G2X2_C3 [Enabled]
U32G2_5 [Enabled]
U32G2_6 [Enabled]
U32G2_7 [Enabled]
U32G2_P8 [Enabled]
U32G2X2_C9 [Enabled]
U32G1_E1 [Enabled]
U32G1_E2 [Enabled]
U32G1_E3 [Enabled]
U32G1_E4 [Enabled]
Network Stack [Disabled]
Device [N/A]
Restore AC Power Loss [Power Off]
Max Power Saving [Disabled]
ErP Ready [Disabled]
Power On By PCI-E [Disabled]
Power On By RTC [Disabled]
USB Audio [Enabled]
Intel LAN [Enabled]
USB power delivery in Soft Off state (S5) [Disabled]
Connectivity mode (Wi-Fi & Bluetooth) [Disabled]
When system is in working state [All On]
Q-Code LED Function [POST Code Only]
When system is in sleep, hibernate or soft off states [All On]
M.2_2 Configuration [Auto]
ASMedia USB 3.2 Controller_U32G1_E12 [Enabled]
ASMedia USB 3.2 Controller_U32G1_E34 [Enabled]
GNA Device [Disabled]
ASMedia Storage Controller [Enabled]
Windows Hot-plug Notification [Disabled]
ASPM Support [Disabled]
CPU Temperature [Monitor]
CPU Package Temperature [Monitor]
MotherBoard Temperature [Monitor]
VRM Temperature [Monitor]
Chipset Temperature [Monitor]
T_Sensor Temperature [Monitor]
DIMM.2 Sensor 1 Temperature [Monitor]
DIMM.2 Sensor 2 Temperature [Monitor]
Water In T Sensor Temperature [Monitor]
Water Out T Sensor Temperature [Monitor]
DIMM A1 Temperature [Monitor]
DIMM B1 Temperature [Monitor]
CPU Fan Speed [Monitor]
CPU Optional Fan Speed [Monitor]
Chassis Fan 1 Speed [Monitor]
Chassis Fan 2 Speed [Monitor]
Chassis Fan 3 Speed [Monitor]
Water Pump+ Speed [Monitor]
AIO Pump Speed [Monitor]
Flow Rate [Monitor]
CPU Core Voltage [Monitor]
12V Voltage [Monitor]
5V Voltage [Monitor]
3.3V Voltage [Monitor]
Memory Controller Voltage [Monitor]
CPU Fan Q-Fan Control [DC Mode]
CPU Fan Profile [Standard]
CPU Fan Q-Fan Source [CPU]
CPU Fan Step Up [Level 0]
CPU Fan Step Down [Level 4]
CPU Fan Speed Low Limit [200 RPM]
Chassis Fan 1 Q-Fan Control [Auto Detect]
Chassis Fan 1 Profile [Standard]
Chassis Fan 1 Q-Fan Source [CPU]
Chassis Fan 1 Step Up [Level 0]
Chassis Fan 1 Step Down [Level 0]
Chassis Fan 1 Speed Low Limit [200 RPM]
Chassis Fan 2 Q-Fan Control [PWM Mode]
Chassis Fan 2 Profile [Standard]
Chassis Fan 2 Q-Fan Source [Chipset]
Chassis Fan 2 Step Up [Level 0]
Chassis Fan 2 Step Down [Level 4]
Chassis Fan 2 Speed Low Limit [200 RPM]
Chassis Fan 3 Q-Fan Control [DC Mode]
Chassis Fan 3 Profile [Silent]
Chassis Fan 3 Q-Fan Source [CPU]
Chassis Fan 3 Step Up [Level 0]
Chassis Fan 3 Step Down [Level 0]
Chassis Fan 3 Speed Low Limit [200 RPM]
Water Pump+ Q-Fan Control [PWM Mode]
Water Pump+ Profile [Manual]
Water Pump+ Q-Fan Source [CPU]
Water Pump+ Step Up [Level 0]
Water Pump+ Step Down [Level 4]
Water Pump+ Speed Low Limit [Ignore]
Water Pump+ Point4 Temperature [70]
Water Pump+ Point4 Duty Cycle (%) [100]
Water Pump+ Point3 Temperature [50]
Water Pump+ Point3 Duty Cycle (%) [85]
Water Pump+ Point2 Temperature [40]
Water Pump+ Point2 Duty Cycle (%) [80]
Water Pump+ Point1 Temperature [25]
Water Pump+ Point1 Duty Cycle (%) [60]
AIO Pump Q-Fan Control [Auto Detect]
AIO Pump Profile [Full Speed]
CPU Temperature LED Switch [Enabled]
Launch CSM [Disabled]
OS Type [Other OS]
Secure Boot Mode [Custom]
Fast Boot [Enabled]
Next Boot after AC Power Loss [Fast Boot]
Boot Logo Display [Disabled]
POST Report [5 sec]
Bootup NumLock State [On]
Wait For 'F1' If Error [Enabled]
Option ROM Messages [Force BIOS]
Interrupt 19 Capture [Disabled]
AMI Native NVMe Driver Support [Enabled]
Setup Mode [Advanced Mode]
Boot Sector (MBR/GPT) Recovery Policy [Local User Control]
Next Boot Recovery Action [Skip]
BIOS Image Rollback Support [Enabled]
Publish HII Resources [Disabled]
Flexkey [Safe Boot]
Setup Animator [Disabled]
Load from Profile [6]
Profile Name [7200CL30TEST]
Save to Profile [6]
DIMM Slot Number [DIMM_A1]
Download & Install ARMOURY CRATE app [Disabled]
Download & Install MyASUS service & app [Disabled] -
vacs
veterán
Hasznos információk, olvasd el:
- a kamerákhoz minden esetben tartozik mobil és pc app, nézhető az élő kép és vissza lehet nézni a felvételeket
- vezetékes kamerákat fogunk ajánlani PoE táplálással = egy utp kábelen megy az áram és az adat
- wifi-s kamerákat csak abban az esetben vásárolj, ha a kábeles kapcsolat nem kivitelezhető, mert nagyon stabil, erős wifi kell a megfelelő működéshez
- a kameráknál lévő internet feltöltési sebessége számít, ha csak 1-2 Mbit, akkor felejtős mobilról "hazanézni" pl a kutyára, macskára
- a motorosan, kb 360°-ban forgatható PTZ kamera jól hangzik, csak akkor van baj, ha X irányba néz és közben Y helyen történik valami
- a PTZ kamerákban a Z betű a zoom-ot jelenti, de ez az olcsóbb modellekben csak egy sima belenagyítás a képbe, semmi köze a valódi zoom-hoz, ezzel legyünk tisztában
- a beépített akkumulátoros kamera is jól hangzik, de pár havonta le kell szerelni a helyéről, mert fel kell tölteni
Az ugyismegveszel.hu, lealkudtuk.hu stb oldalakon elérhető kamerarendszernek kinéző tárgyakat senkinek nem ajánljuk!Kérdéssor:
1. Hány db kamerát tervezel (kültéri/beltéri)?
2. Később lesz-e bővítve?
3. NVR (rögzítő) kerül-e a rendszerbe, vagy SD kártyára lesz a rögzítés?
4. Mekkora területet szeretnél figyelni (milyen messze van a kerítés vagy az utcafront)?
5. Kellenek-e "okos" funkciók (személy/gépjármű felismerés)? > hasznos infó, olvasd el
6. Külföldi vásárlás szóba jöhet-e (EU raktárból, plusz költség nélkül)?
7. Mennyi pénz lenne a vásárlásra?
8. WiFi-s kamerát szeretnél (alapból vezetékest ajánlunk)?
9. Egyéb igények (pl forgatható, sim kártyás, napelemes, színes éjjeli kép stb)? -
zebra_hun
veterán
[2023/12/10 15:03:22]
Ai Overclock Tuner [Manual]
BCLK Frequency [100.0000]
PCIE Frequency [100.0000]
Intel(R) Adaptive Boost Technology [Enabled]
ASUS MultiCore Enhancement [Enabled – Remove All limits (90°C)]
SVID Behavior [Auto]
BCLK Frequency : DRAM Frequency Ratio [100:100]
Memory Controller : DRAM Frequency Ratio [1:2]
DRAM Frequency [DDR5-8000MHz]
Performance Core Ratio [By Core Usage]
1-Core Ratio Limit [58]
2-Core Ratio Limit [58]
3-Core Ratio Limit [57]
4-Core Ratio Limit [57]
5-Core Ratio Limit [56]
6-Core Ratio Limit [56]
7-Core Ratio Limit [55]
8-Core Ratio Limit [55]
Performance Core0 Specific Ratio Limit [Auto]
Performance Core0 specific Voltage [Auto]
Performance Core1 Specific Ratio Limit [Auto]
Performance Core1 specific Voltage [Auto]
*Performance Core2 Specific Ratio Limit [Auto]
Performance Core2 specific Voltage [Auto]
*Performance Core3 Specific Ratio Limit [Auto]
Performance Core3 specific Voltage [Auto]
Performance Core4 Specific Ratio Limit [Auto]
Performance Core4 specific Voltage [Auto]
Performance Core5 Specific Ratio Limit [Auto]
Performance Core5 specific Voltage [Auto]
Performance Core6 Specific Ratio Limit [Auto]
Performance Core6 specific Voltage [Auto]
Performance Core7 Specific Ratio Limit [Auto]
Performance Core7 specific Voltage [Auto]
Efficient Core Ratio [By Core Usage]
Efficient Turbo Ratio Limit 1 [44]
Efficient Turbo Ratio Cores 1 [Auto]
Efficient Core Group0 Specific Ratio Limit [Auto]
Efficient Core Group0 specific Voltage [Auto]
Efficient Core Group1 Specific Ratio Limit [Auto]
Efficient Core Group1 specific Voltage [Auto]
Efficient Core Group2 Specific Ratio Limit [Auto]
Efficient Core Group2 specific Voltage [Auto]
Efficient Core Group3 Specific Ratio Limit [Auto]
Efficient Core Group3 specific Voltage [Auto]
AVX2 [Auto]
AVX2 Ratio Offset to per-core Ratio Limit [Auto]
AVX2 Voltage Guardband Scale Factor [Auto]
Maximus Tweak [Mode 2]
DRAM CAS# Latency [36]
DRAM RAS# to CAS# Delay Read [46]
DRAM RAS# to CAS# Delay Write [16]
DRAM RAS# PRE Time [46]
DRAM RAS# ACT Time [68]
DRAM Command Rate [2N]
DRAM RAS# to RAS# Delay L [12]
DRAM RAS# to RAS# Delay S [8]
DRAM REF Cycle Time 2 [480]
DRAM REF Cycle Time Same Bank [Auto]
DRAM Refresh Interval [65535]
DRAM WRITE Recovery Time [24]
DRAM READ to PRE Time [12]
DRAM FOUR ACT WIN Time [32]
DRAM WRITE to READ Delay L [Auto]
DRAM WRITE to READ Delay S [Auto]
DRAM CKE Minimum Pulse Width [16]
DRAM Write Latency [34]
Ctl0 dqvrefup [170]
Ctl0 dqvrefdn [88]
Ctl0 dqodtvrefup [Auto]
Ctl0 dqodtvrefdn [Auto]
Ctl1 cmdvrefup [Auto]
Ctl1 ctlvrefup [Auto]
Ctl1 clkvrefup [Auto]
Ctl1 ckecsvrefup [Auto]
Ctl2 cmdvrefdn [Auto]
Ctl2 ctlvrefdn [Auto]
Ctl2 clkvrefdn [Auto]
Read Equalization RxEq Start Sign [-]
Read Equalization RxEq Start [Auto]
Read Equalization RxEq Stop Sign [-]
Read Equalization RxEq Stop [Auto]
ODT_READ_DURATION [Auto]
ODT_READ_DELAY [Auto]
ODT_WRITE_DURATION [Auto]
ODT_WRITE_DELAY [Auto]
DQ RTT WR [40 DRAM Clock]
DQ RTT NOM RD [34 DRAM Clock]
DQ RTT NOM WR [34 DRAM Clock]
DQ RTT PARK [34 DRAM Clock]
DQ RTT PARK DQS [34 DRAM Clock]
GroupA CA ODT [240 DRAM Clock]
GroupA CS ODT [0 DRAM Clock]
GroupA CK ODT [0 DRAM Clock]
GroupB CA ODT [60 DRAM Clock]
GroupB CS ODT [40 DRAM Clock]
GroupB CK ODT [40 DRAM Clock]
Pull-up Output Driver Impedance [34 DRAM Clock]
Pull-Down Output Driver Impedance [34 DRAM Clock]
DQ RTT WR [40 DRAM Clock]
DQ RTT NOM RD [34 DRAM Clock]
DQ RTT NOM WR [34 DRAM Clock]
DQ RTT PARK [34 DRAM Clock]
DQ RTT PARK DQS [34 DRAM Clock]
GroupA CA ODT [240 DRAM Clock]
GroupA CS ODT [0 DRAM Clock]
GroupA CK ODT [0 DRAM Clock]
GroupB CA ODT [60 DRAM Clock]
GroupB CS ODT [40 DRAM Clock]
GroupB CK ODT [40 DRAM Clock]
Pull-up Output Driver Impedance [34 DRAM Clock]
Pull-Down Output Driver Impedance [34 DRAM Clock]
Round Trip Latency Init Value MC0 CHA [Auto]
Round Trip Latency Max Value MC0 CHA [Auto]
Round Trip Latency Offset Value Mode Sign MC0 CHA [-]
Round Trip Latency Offset Value MC0 CHA [Auto]
Round Trip Latency Init Value MC0 CHB [Auto]
Round Trip Latency Max Value MC0 CHB [Auto]
Round Trip Latency Offset Value Mode Sign MC0 CHB [-]
Round Trip Latency Offset Value MC0 CHB [Auto]
Round Trip Latency Init Value MC1 CHA [Auto]
Round Trip Latency Max Value MC1 CHA [Auto]
Round Trip Latency Offset Value Mode Sign MC1 CHA [-]
Round Trip Latency Offset Value MC1 CHA [Auto]
Round Trip Latency Init Value MC1 CHB [Auto]
Round Trip Latency Max Value MC1 CHB [Auto]
Round Trip Latency Offset Value Mode Sign MC1 CHB [-]
Round Trip Latency Offset Value MC1 CHB [Auto]
Round Trip Latency MC0 CHA R0 [Auto]
Round Trip Latency MC0 CHA R1 [Auto]
Round Trip Latency MC0 CHA R2 [0]
Round Trip Latency MC0 CHA R3 [0]
Round Trip Latency MC0 CHA R4 [0]
Round Trip Latency MC0 CHA R5 [0]
Round Trip Latency MC0 CHA R6 [0]
Round Trip Latency MC0 CHA R7 [0]
Round Trip Latency MC0 CHB R0 [Auto]
Round Trip Latency MC0 CHB R1 [Auto]
Round Trip Latency MC0 CHB R2 [0]
Round Trip Latency MC0 CHB R3 [0]
Round Trip Latency MC0 CHB R4 [0]
Round Trip Latency MC0 CHB R5 [0]
Round Trip Latency MC0 CHB R6 [0]
Round Trip Latency MC0 CHB R7 [0]
Round Trip Latency MC1 CHA R0 [Auto]
Round Trip Latency MC1 CHA R1 [Auto]
Round Trip Latency MC1 CHA R2 [0]
Round Trip Latency MC1 CHA R3 [0]
Round Trip Latency MC1 CHA R4 [0]
Round Trip Latency MC1 CHA R5 [0]
Round Trip Latency MC1 CHA R6 [0]
Round Trip Latency MC1 CHA R7 [0]
Round Trip Latency MC1 CHB R0 [Auto]
Round Trip Latency MC1 CHB R1 [Auto]
Round Trip Latency MC1 CHB R2 [0]
Round Trip Latency MC1 CHB R3 [0]
Round Trip Latency MC1 CHB R4 [0]
Round Trip Latency MC1 CHB R5 [0]
Round Trip Latency MC1 CHB R6 [0]
Round Trip Latency MC1 CHB R7 [0]
Early Command Training [Auto]
SenseAmp Offset Training [Auto]
Early ReadMPR Timing Centering 2D [Auto]
Read MPR Training [Auto]
Receive Enable Training [Auto]
Jedec Write Leveling [Auto]
Early Write Time Centering 2D [Auto]
Early Read Time Centering 2D [Auto]
Write Timing Centering 1D [Auto]
Write Voltage Centering 1D [Auto]
Read Timing Centering 1D [Auto]
Read Timing Centering with JR [Auto]
Dimm ODT Training* [Disabled]
Max RTT_WR [ODT Off]
DIMM RON Training* [Auto]
Write Drive Strength/Equalization 2D* [Auto]
Write Slew Rate Training* [Auto]
Read ODT Training* [Auto]
Comp Optimization Training [Auto]
Read Equalization Training* [Auto]
Read Amplifier Training* [Auto]
Write Timing Centering 2D [Auto]
Read Timing Centering 2D [Auto]
Command Voltage Centering [Auto]
Early Command Voltage Centering [Auto]
Write Voltage Centering 2D [Auto]
Read Voltage Centering 2D [Auto]
Late Command Training [Auto]
Round Trip Latency [Enabled]
Turn Around Timing Training [Auto]
CMD CTL CLK Slew Rate [Auto]
CMD/CTL DS & E 2D [Auto]
Read Voltage Centering 1D [Auto]
TxDqTCO Comp Training* [Auto]
ClkTCO Comp Training* [Auto]
TxDqsTCO Comp Training* [Auto]
VccDLL Bypass Training [Auto]
CMD/CTL Drive Strength Up/Dn 2D [Auto]
DIMM CA ODT Training [Auto]
PanicVttDnLp Training* [Auto]
Read Vref Decap Training* [Auto]
Vddq Training [Auto]
Duty Cycle Correction Training [Auto]
Periodic DCC [Auto]
Rank Margin Tool Per Bit [Auto]
DIMM DFE Training [Auto]
EARLY DIMM DFE Training [Auto]
Tx Dqs Dcc Training [Auto]
DRAM DCA Training [Auto]
Write Driver Strength Training [Auto]
Rank Margin Tool [Auto]
Memory Test [Auto]
DIMM SPD Alias Test [Auto]
Receive Enable Centering 1D [Auto]
Retrain Margin Check [Auto]
Write Drive Strength Up/Dn independently [Auto]
LPDDR DqDqs Re-Training [Auto]
Margin Check Limit [Disabled]
tRDRD_sg_Training [Auto]
tRDRD_sg_Runtime [16]
tRDRD_dg_Training [Auto]
tRDRD_dg_Runtime [8]
tRDWR_sg [20]
tRDWR_dg [20]
tWRWR_sg [16]
tWRWR_dg [8]
tWRRD_sg [64]
tWRRD_dg [50]
tRDRD_dr [Auto]
tRDRD_dd [Auto]
tRDWR_dr [Auto]
tRDWR_dd [Auto]
tWRWR_dr [Auto]
tWRWR_dd [Auto]
tWRRD_dr [Auto]
tWRRD_dd [Auto]
tRPRE [Auto]
tWPRE [Auto]
tWPOST [Auto]
tWRPRE [Auto]
tPRPDEN [Auto]
tRDPDEN [Auto]
tWRPDEN [Auto]
tCPDED [Auto]
tREFIX9 [Auto]
Ref Interval [Auto]
tXPDLL [Auto]
tXP [Auto]
tPPD [Auto]
tCCD_L_tDLLK [Auto]
tZQCAL [Auto]
tZQCS [Auto]
OREF_RI [Auto]
Refresh Watermarks [High]
Refresh Hp Wm [Auto]
Refresh Panic Wm [Auto]
Refresh Abr Release [Auto]
tXSDLL [Auto]
tZQOPER [Auto]
tMOD [Auto]
CounttREFIWhileRefEn [Auto]
HPRefOnMRS [Auto]
SRX Ref Debits [Auto]
RAISE BLK WAIT [Auto]
Ref Stagger En [Auto]
Ref Stagger Mode [Auto]
Disable Stolen Refresh [Auto]
En Ref Type Display [Auto]
Trefipulse Stagger Disable [Auto]
tRPab ext [Auto]
derating ext [Auto]
Allow 2cyc B2B LPDDR [Auto]
tCSH [Auto]
tCSL [Auto]
powerdown Enable [Auto]
idle length [Auto]
raise cke after exit latency [Auto]
powerdown latency [Auto]
powerdown length [Auto]
selfrefresh latency [Auto]
selfrefresh length [Auto]
ckevalid length [Auto]
ckevalid enable [Auto]
idle enable [Auto]
selfrefresh enable [Auto]
Address mirror [Auto]
no gear4 param divide [Auto]
x8 device [Auto]
no gear2 param divide [Auto]
ddr 1dpc split ranks on subch [Auto]
write0 enable [Auto]
MultiCycCmd [Auto]
WCKDiffLowInIdle [Auto]
PBR Disable [Auto]
PBR OOO Dis [Auto]
PBR Disable on hot [Auto]
PBR Exit on Idle Cnt [Auto]
tXSR [Auto]
Dec tCWL [Auto]
Add tCWL [Auto]
Add 1Qclk delay [Auto]
MRC Fast Boot [Disabled]
MCH Full Check [Enabled]
Mem Over Clock Fail Count [2]
Training Profile [Auto]
RxDfe [Auto]
Mrc Training Loop Count [2]
DRAM CLK Period [Auto]
Dll_bwsel [Auto]
Controller 0, Channel 0 Control [Enabled]
Controller 0, Channel 1 Control [Enabled]
Controller 1, Channel 0 Control [Enabled]
Controller 1, Channel 1 Control [Enabled]
MC_Vref0 [Auto]
MC_Vref1 [Auto]
MC_Vref2 [Auto]
Fine Granularity Refresh mode [Auto]
SDRAM Density Per Die [Auto]
SDRAM Banks Per Bank Group [Auto]
SDRAM Bank Groups [Auto]
Dynamic Memory Boost [Disabled]
Realtime Memory Frequency [Disabled]
SA GV [Disabled]
Voltage Monitor [Die Sense]
VRM Initialization Check [Enabled]
CPU Input Voltage Load-line Calibration [Auto]
CPU Load-line Calibration [Level 5]
Synch ACDC Loadline with VRM Loadline [Disabled]
CPU Current Capability [Auto]
CPU Current Reporting [Auto]
Core Voltage Suspension [Auto]
CPU VRM Switching Frequency [Auto]
VRM Spread Spectrum [Auto]
CPU Power Duty Control [Auto]
CPU Power Phase Control [Auto]
CPU Power Thermal Control [125]
CPU Core/Cache Boot Voltage [Auto]
CPU Input Boot Voltage [Auto]
PLL Termination Boot Voltage [Auto]
CPU Standby Boot Voltage [Auto]
Memory Controller Boot Voltage [Auto]
CPU Core Auto Voltage Cap [Auto]
CPU Input Auto Voltage Cap [Auto]
Memory Controller Auto Voltage Cap [Auto]
Fast Throttle Threshold [Auto]
Package Temperature Threshold [Auto]
Regulate Frequency by above Threshold [Auto]
IVR Transmitter VDDQ ICCMAX [Auto]
Unlimited ICCMAX [Auto]
CPU Core/Cache Current Limit Max. [Auto]
Long Duration Package Power Limit [270]
Package Power Time Window [Auto]
Short Duration Package Power Limit [295]
Dual Tau Boost [Disabled]
IA AC Load Line [0.03]
IA DC Load Line [0.82]
IA CEP Enable [Disabled]
SA CEP Enable [Disabled]
IA SoC Iccmax Reactive Protector [Auto]
Inverse Temperature Dependency Throttle [Auto]
IA VR Voltage Limit [1500]
CPU SVID Support [Auto]
Cache Dynamic OC Switcher [Auto]
TVB Voltage Optimizations [Auto]
Enhanced TVB [Auto]
Overclocking TVB [Auto]
Overclocking TVB Global Temperature Offset Sign [+]
Overclocking TVB Global Temperature Offset Value [Auto]
Offset Mode Sign 1 [+]
V/F Point 1 Offset [Auto]
Offset Mode Sign 2 [+]
V/F Point 2 Offset [Auto]
Offset Mode Sign 3 [+]
V/F Point 3 Offset [Auto]
Offset Mode Sign 4 [+]
V/F Point 4 Offset [Auto]
Offset Mode Sign 5 [+]
V/F Point 5 Offset [Auto]
Offset Mode Sign 6 [+]
V/F Point 6 Offset [Auto]
Offset Mode Sign 7 [+]
V/F Point 7 Offset [Auto]
Offset Mode Sign 8 [+]
V/F Point 8 Offset [Auto]
Offset Mode Sign 9 [+]
V/F Point 9 Offset [Auto]
Offset Mode Sign 10 [+]
V/F Point 10 Offset [Auto]
Offset Mode Sign 11 [+]
V/F Point 11 Offset [Auto]
Initial BCLK Frequency [Auto]
Runtime BCLK OC [Auto]
BCLK Amplitude [Auto]
BCLK Slew Rate [Auto]
BCLK Spread Spectrum [Auto]
Initial PCIE Frequency [Auto]
PCIE/DMI Amplitude [Auto]
PCIE/DMI Slew Rate [Auto]
PCIE/DMI Spread Spectrum [Auto]
Cold Boot PCIE Frequency [Auto]
Realtime Memory Timing [Disabled]
SPD Write Disable [TRUE]
PVD Ratio Threshold [Auto]
SA PLL Frequency Override [3200 MHz]
BCLK TSC HW Fixup [Enabled]
Core Ratio Extension Mode [Disabled]
FLL OC mode [Auto]
UnderVolt Protection [Disabled]
Switch Microcode [Current Microcode]
Xtreme Tweaking [Disabled]
Core PLL Voltage [Auto]
GT PLL Voltage [Auto]
Ring PLL Voltage [Auto]
System Agent PLL Voltage [Auto]
Memory Controller PLL Voltage [Auto]
Efficient-core PLL Voltage [Auto]
CPU 1.8V Small Rail [Auto]
PLL Termination Voltage [Auto]
CPU Standby Voltage [Auto]
PCH 1.05V Voltage [Auto]
PCH 0.82V Voltage [Auto]
CPU Input Voltage Reset Voltage [Auto]
Eventual CPU Input Voltage [Auto]
Eventual Memory Controller Voltage [Auto]
Package Temperature Threshold [Auto]
Regulate Frequency by above Threshold [Auto]
Cooler Efficiency Customize [Keep Training]
Cooler Re-evaluation Algorithm [Normal]
Optimism Scale [100]
Ring Down Bin [Enabled]
Min. CPU Cache Ratio [8]
Max. CPU Cache Ratio [49]
BCLK Aware Adaptive Voltage [Auto]
Actual VRM Core Voltage [Auto]
Global Core SVID Voltage [Adaptive Mode]
- Offset Mode Sign [-]
- Additional Turbo Mode CPU Core Voltage [Auto]
- Offset Voltage [0.05000]
Cache SVID Voltage [Auto]
CPU L2 Voltage [Auto]
CPU System Agent Voltage [Manual Mode]
- CPU System Agent Voltage Override [1.15000]
CPU Input Voltage [Auto]
High DRAM Voltage Mode [Enabled]
DRAM VDD Voltage [1.46000]
DRAM VDDQ Voltage [1.44000]
IVR Transmitter VDDQ Voltage [1.25500]
Memory Controller Voltage [1.36250]
MC Voltage Calculation Voltage Base [Auto]
VDD Calculation Voltage Base [Auto]
PMIC Voltages [Sync All PMICs]
SPD HUB VLDO (1.8V) [Auto]
SPD HUB VDDIO (1.0V) [Auto]
DRAM VDD Voltage [1.46000]
DRAM VDDQ Voltage [1.44000]
DRAM VPP Voltage [Auto]
DRAM VDD Switching Frequency [1.50000]
DRAM VDDQ Switching Frequency [1.50000]
DRAM VPP Switching Frequency [1.50000]
DRAM Current Capability [7.87500]
PCI Express Native Power Management [Enabled]
Native ASPM [Disabled]
DMI Link ASPM Control [Disabled]
ASPM [Auto]
L1 Substates [Disabled]
DMI ASPM [Disabled]
DMI Gen3 ASPM [Disabled]
PEG - ASPM [Disabled]
PCI Express Clock Gating [Enabled]
Hardware Prefetcher [Enabled]
Adjacent Cache Line Prefetch [Enabled]
Intel (VMX) Virtualization Technology [Disabled]
Per P-Core Control [Disabled]
Per E-Core Control [Disabled]
Active Performance Cores [All]
Active Efficient Cores [All]
Hyper-Threading [Enabled]
Hyper-Threading of Core 0 [Enabled]
Hyper-Threading of Core 1 [Enabled]
Hyper-Threading of Core 2 [Enabled]
Hyper-Threading of Core 3 [Enabled]
Hyper-Threading of Core 4 [Enabled]
Hyper-Threading of Core 5 [Enabled]
Hyper-Threading of Core 6 [Enabled]
Hyper-Threading of Core 7 [Enabled]
Total Memory Encryption [Disabled]
Legacy Game Compatibility Mode [Disabled]
Boot performance mode [Auto]
Intel(R) SpeedStep(tm) [Enabled]
Intel(R) Speed Shift Technology [Enabled]
Intel(R) Turbo Boost Max Technology 3.0 [Enabled]
Turbo Mode [Enabled]
Acoustic Noise Mitigation [Disabled]
CPU C-states [Auto]
Thermal Monitor [Enabled]
Dual Tau Boost [Disabled]
VT-d [Disabled]
Memory Remap [Enabled]
Enable VMD controller [Enabled]
Map PCIE Storage under VMD [Disabled]
Map SATA Controller under VMD [Disabled]
M.2_1 Link Speed [Auto]
PCIEX16(G5)_1 Link Speed [Auto]
PCIEX16(G5)_2 Link Speed [Auto]
PCIEX1(G4) Link Speed [Auto]
PCIEX4(G4) Link Speed [Auto]
M.2_2 Link Speed [Auto]
DIMM.2_1 Link Speed [Auto]
DIMM.2_2 Link Speed [Auto]
SATA Controller(s) [Enabled]
Aggressive LPM Support [Disabled]
SMART Self Test [Enabled]
M.2_3 [Enabled]
M.2_3 Hot Plug [Disabled]
SATA6G_1 [Enabled]
SATA6G_1 Hot Plug [Disabled]
SATA6G_2 [Enabled]
SATA6G_2 Hot Plug [Disabled]
SATA6G_3 [Enabled]
SATA6G_3 Hot Plug [Disabled]
SATA6G_4 [Enabled]
SATA6G_4 Hot Plug [Disabled]
PTT [Enable]
Intel(R) Dynamic Tuning Technology [Disabled]
PCIE Tunneling over USB4 [Enabled]
Discrete Thunderbolt(TM) Support [Disabled]
Security Device Support [Enable]
SHA256 PCR Bank [Enabled]
Pending operation [None]
Platform Hierarchy [Enabled]
Storage Hierarchy [Enabled]
Endorsement Hierarchy [Enabled]
Physical Presence Spec Version [1.3]
Disable Block Sid [Disabled]
Password protection of Runtime Variables [Enable]
Above 4G Decoding [Enabled]
Resize BAR Support [Enabled]
SR-IOV Support [Disabled]
Legacy USB Support [Enabled]
XHCI Hand-off [Enabled]
SanDisk [Auto]
LAN_U32G2_1 [Enabled]
U32G1_E5 [Enabled]
U32G1_E6 [Enabled]
U32G1_E7 [Enabled]
U32G1_E8 [Enabled]
U32G2X2_C3 [Enabled]
U32G2_5 [Enabled]
U32G2_6 [Enabled]
U32G2_7 [Enabled]
U32G2_P8 [Enabled]
U32G2X2_C9 [Enabled]
U32G1_E1 [Enabled]
U32G1_E2 [Enabled]
U32G1_E3 [Enabled]
U32G1_E4 [Enabled]
Network Stack [Disabled]
Device [N/A]
Restore AC Power Loss [Power Off]
Max Power Saving [Disabled]
ErP Ready [Disabled]
Power On By PCI-E [Disabled]
Power On By RTC [Disabled]
USB Audio [Enabled]
Intel LAN [Enabled]
USB power delivery in Soft Off state (S5) [Disabled]
Connectivity mode (Wi-Fi & Bluetooth) [Disabled]
When system is in working state [All On]
Q-Code LED Function [POST Code Only]
When system is in sleep, hibernate or soft off states [All On]
M.2_2 Configuration [Auto]
ASMedia USB 3.2 Controller_U32G1_E12 [Enabled]
ASMedia USB 3.2 Controller_U32G1_E34 [Enabled]
GNA Device [Disabled]
ASMedia Storage Controller [Enabled]
Windows Hot-plug Notification [Disabled]
ASPM Support [Disabled]
CPU Temperature [Monitor]
CPU Package Temperature [Monitor]
MotherBoard Temperature [Monitor]
VRM Temperature [Monitor]
Chipset Temperature [Monitor]
T_Sensor Temperature [Monitor]
DIMM.2 Sensor 1 Temperature [Monitor]
DIMM.2 Sensor 2 Temperature [Monitor]
Water In T Sensor Temperature [Monitor]
Water Out T Sensor Temperature [Monitor]
DIMM A1 Temperature [Monitor]
DIMM B1 Temperature [Monitor]
CPU Fan Speed [Monitor]
CPU Optional Fan Speed [Monitor]
Chassis Fan 1 Speed [Monitor]
Chassis Fan 2 Speed [Monitor]
Chassis Fan 3 Speed [Monitor]
Water Pump+ Speed [Monitor]
AIO Pump Speed [Monitor]
Flow Rate [Monitor]
CPU Core Voltage [Monitor]
12V Voltage [Monitor]
5V Voltage [Monitor]
3.3V Voltage [Monitor]
Memory Controller Voltage [Monitor]
CPU Fan Q-Fan Control [DC Mode]
CPU Fan Profile [Standard]
CPU Fan Q-Fan Source [CPU]
CPU Fan Step Up [Level 0]
CPU Fan Step Down [Level 4]
CPU Fan Speed Low Limit [200 RPM]
Chassis Fan 1 Q-Fan Control [Auto Detect]
Chassis Fan 1 Profile [Standard]
Chassis Fan 1 Q-Fan Source [CPU]
Chassis Fan 1 Step Up [Level 0]
Chassis Fan 1 Step Down [Level 0]
Chassis Fan 1 Speed Low Limit [200 RPM]
Chassis Fan 2 Q-Fan Control [PWM Mode]
Chassis Fan 2 Profile [Standard]
Chassis Fan 2 Q-Fan Source [Chipset]
Chassis Fan 2 Step Up [Level 0]
Chassis Fan 2 Step Down [Level 4]
Chassis Fan 2 Speed Low Limit [200 RPM]
Chassis Fan 3 Q-Fan Control [DC Mode]
Chassis Fan 3 Profile [Silent]
Chassis Fan 3 Q-Fan Source [CPU]
Chassis Fan 3 Step Up [Level 0]
Chassis Fan 3 Step Down [Level 0]
Chassis Fan 3 Speed Low Limit [200 RPM]
Water Pump+ Q-Fan Control [PWM Mode]
Water Pump+ Profile [Manual]
Water Pump+ Q-Fan Source [CPU]
Water Pump+ Step Up [Level 0]
Water Pump+ Step Down [Level 4]
Water Pump+ Speed Low Limit [Ignore]
Water Pump+ Point4 Temperature [70]
Water Pump+ Point4 Duty Cycle (%) [100]
Water Pump+ Point3 Temperature [50]
Water Pump+ Point3 Duty Cycle (%) [85]
Water Pump+ Point2 Temperature [40]
Water Pump+ Point2 Duty Cycle (%) [80]
Water Pump+ Point1 Temperature [25]
Water Pump+ Point1 Duty Cycle (%) [60]
AIO Pump Q-Fan Control [Auto Detect]
AIO Pump Profile [Full Speed]
CPU Temperature LED Switch [Enabled]
Launch CSM [Disabled]
OS Type [Other OS]
Secure Boot Mode [Custom]
Fast Boot [Enabled]
Next Boot after AC Power Loss [Fast Boot]
Boot Logo Display [Auto]
POST Delay Time [3 sec]
Bootup NumLock State [On]
Wait For 'F1' If Error [Enabled]
Option ROM Messages [Force BIOS]
Interrupt 19 Capture [Disabled]
AMI Native NVMe Driver Support [Enabled]
Setup Mode [Advanced Mode]
Boot Sector (MBR/GPT) Recovery Policy [Local User Control]
Next Boot Recovery Action [Skip]
BIOS Image Rollback Support [Enabled]
Publish HII Resources [Disabled]
Flexkey [Safe Boot]
Setup Animator [Disabled]
Load from Profile [1]
Profile Name [8000CL36*46*46]
Save to Profile [2]
DIMM Slot Number [DIMM_A1]
Download & Install ARMOURY CRATE app [Disabled]
Download & Install MyASUS service & app [Disabled] -
Giovan! - 2022-12-13 - Metal bat - forráskép -
- kész (CSERE)
hkari - 2022-11-13 - saját arcos emoji - ezekkel a módosításokkal -
kész - (SZABAD)
rwin5 - 2022-12-07 - Vaják, Kökörcsin, Witcher, Jaskier - forráskép kész
Aksomatic - 2022-12-15 - Darwin Watterson, Gumball - forráskép kész
Adam_Shepard - 2022-12-21- River City Girls, Kyo - forráskép kész - (CSERE)
Tyler Durden - 2022-10-16 - Tyler Durden, Fight Club, Harcosok Klubja, lego - kész - (CSERE)
marinea2 - 2023-01-25 - forráskép - kész - (CSERE)
*Tata* - 2023-01-05 - Getafix, Panoramix, Csodaturmix, Asterix és Obelix, druida + kérés piros palást - - kész - (SZABAD)CitroghostCitroware (nevet változtatott) - 2023-01-10 - Akali, K/DA Skin, League of Legends - játék - forráskép1, forráskép2 - - kész (CSERE)
razorbenke92 - 2023-01-19 - - kész
updog - 2022-10-11 - Gruffalo, mese - forráskép -
- kész (CSERE)
this is life - 2023-02-25 - Tweak, South Park - forráskép - kész
zetor2000 - 2023-03-02 - forráskép - zetor piros - kész
Mr.Silkó - 2023-02-06 - forráskép - (+kép, amin látszik az arca) - kész (CSERE)
Mushu™ - 2023-01-06 - Minami Kamakura Koukou Joshi Jitensha-bu + kérés - Anime - - kész - (CSERE)
winbox - 2023-02-24 - forráskép - kész
GEIL - 2023-04-01 - forráskép - kész
BigManus - 2023-04-04 - Paprika Jancsi, báb, bábu, TV Maci - SZABAD
callmeakos - 2023-02-01 - forráskép - Ryuuji Takasu, Toradora! - kész
Lali-213 - 2023-03-24 - forráskép - Inci, Pixie and Dixie and Mr.Jinks, Inci és Finci és Kandúr Bandi - kész
Csorbi - 2023-03-18 - forráskép - Leo, oroszlán - kész
castiels - 2023-01-16 - Gilgamesh, Fate/Zero, Fate/Stay Night, Unlimited Blade Works - forráskép (felső sor középső) - kész (CSERE)
Szellem. - (Plag) - 2023-02-11 - forráskép - CoD, Soap, Red Team - kész- (CSERE) (nicket váltott!)
Sanyi19 - 2023-01-23 - Jack Orlando, A Cinematic Adventure - játék - forráskép - kész
belashx - 2023-01-26 - forráskép - kész
zozyk - 2023-07-06 - online avatar maker, South Park, sör, söröskorsó - kész (SZABAD)
tepenzed - 2023-02-17 - forráskép1, forráskép2 - kész (CSERE)
Ferenczi Áko - 2023-01-03 - Anakin - forráskép (jobb felső) - - kész (CSERE)
ballazol - 2023-02-19 - forráskép - - kész
mark! (Korábban ZedMester) - 2023-06-21 - Gordon Quid, Csacska Macskák, Catscratch, macska, Nickelodeon - forrás - SZABAD, kiskép kell csak (+png)! - kész - (CSERE, SZABAD)
Oposzumtoszó - 2023-04-29 - BoDeanLynn, Brickleberry - forráskép - - kész
Remington - 2023-06-15 -Tyrannosaurus rex, T-Rex, dínó, dinoszaurusz, dinosaur, dino - forrás - - kész (SZABAD)
viragdani01 - Star Wars, Chopper - kész.
Balcsix - 2023-03-25 - Armin Van Buuren - forráskép - - kész
RangerFox - 2023-05-31 - Mocha maci, Mocha bear - forráskép (+kék bögre) - - kész -(CSERE)
LackoMester - 2023-01-05 - forráskép - (meglévő arckép frissítés) - - kész
Sliderxy - 2023-06-09 - Hornet, Hollow Knight - forráskép - - kész
AnonymusX - 2023-02-24 - forráskép - - kész
5150head - 2023-04-01- Úrhajós, koponya, astronauta - forráskép - kész
SkiDev - 2023-05-06 - Jesus "Soos" Alzamirano Ramirez, Gravity Falls - forrás - kész
novinyul - 2023-03-17 - Egon Spengler, Szellemírtók, Ghostbusters - forráskép -
- (meglévő arckép frissítés)- kész
Daffchy - 2023-04-05 - Madara Uchiha - forráskép + kérés - - kész - (CSERE)
soo277 - 2023-04-06 - Bo-Katan Kryze, Mandalorian - forráskép - - kész - (CSERE)
SoulReaver - 2023-04-11- Briareos/Appleseed - forráskép - - kész - (CSERE)
ρσгτσ - 2023-10-11 - Marc Anthony, Marco Antonio Muniz, Puerto Rico, - kész (korábbi nickjének az arcképe)
D@niel - 2023-04-06- COD, Firestarter Krueger - forráskép - - kész
Peace - 2023-04-18 - The last of us, Ellie - forráskép - - kész - (CSERE)
Sundesz - 2023-05-02 - Fernando Alnoso, f1, formula1 - forráskép - - kész (CSERE) - (karakter ugyanaz)
Warzoz - 2023-05-27 - fantasy warrior - forráskép kész
spleenszuru - 2023-05-30 - Hunter, Star Wars: The Bad Batch - forráskép (ha belefér, késsel együtt) kész
thebigK - 2023-07-04 - Roy Kent - forráskép kész
rigoberto - 2023-07-23 - férfi portré - forráskép kész
Busterftw - 2023-08-02 - Deep Rock Galactic, Bosco - forráskép kész
belan - 2023-06-15 - Darth Malgus, Star Wars - forráskép (plusz kapucnit szeretne rá) - kész- (CSERE)
MmDorian - 2023-09-21 - cica, macska - forráskép - kész- (CSERE)
BioNiCMaN - 2023-10-08 - Walter Sobchak, John Goodman, The Big Lebowski - forráskép - kész- (CSERE)
Tuomas - 2023-09-28 - Kutya, corgi, űrhajós - forráskép - kész- (CSERE)
bigrob - 2023-05-22 - Inosuke, Demon Slayer, anime - forráskép - - kész - (CSERE)
Xelo - 2023-09-18 - Buddhist Monkey, Happy Tree friends - forráskép - kész- (Meglévő arckép frissítés)
Diokhan - 2023-08-06 - Gavin Harrison - forráskép -- kész - (CSERE)
beci - 2023-08-09 - angol bullterrier, kutya - forráskép - kész- (CSERE)
ELG - 2023-10-20 - Jet Sunset, synthwave-vaporwave - forráskép - -kész - (CSERE) -
vacs
veterán
Hasznos információk, olvasd el:
- a kamerákhoz minden esetben tartozik mobil és pc app, nézhető az élő kép és vissza lehet nézni a felvételeket
- vezetékes kamerákat fogunk ajánlani PoE táplálással = egy utp kábelen megy az áram és az adat
- wifi-s kamerákat csak abban az esetben vásárolj, ha a kábeles kapcsolat nem kivitelezhető, mert nagyon stabil, erős wifi kell a megfelelő működéshez
- a kameráknál lévő internet feltöltési sebessége számít, ha csak 1-2 Mbit, akkor felejtős mobilról "hazanézni" pl a kutyára, macskára
- a motorosan, kb 360°-ban forgatható PTZ kamera jól hangzik, csak akkor van baj, ha X irányba néz és közben Y helyen történik valami
- a PTZ kamerákban a Z betű a zoom-ot jelenti, de ez az olcsóbb modellekben csak egy sima belenagyítás a képbe, semmi köze a valódi zoom-hoz, ezzel legyünk tisztában
- a beépített akkumulátoros kamera is jól hangzik, de pár havonta le kell szerelni a helyéről, mert fel kell tölteni
Az ugyismegveszel.hu, lealkudtuk.hu stb oldalakon elérhető kamerarendszernek kinéző tárgyakat senkinek nem ajánljuk!Kérdéssor:
1. Hány db kamerát tervezel (kültéri/beltéri)?
2. Később lesz-e bővítve?
3. NVR (rögzítő) kerül-e a rendszerbe, vagy SD kártyára lesz a rögzítés?
4. Mekkora területet szeretnél figyelni (milyen messze van a kerítés vagy az utcafront)?
5. Kellenek-e "okos" funkciók (személy/gépjármű felismerés)? > hasznos infó, olvasd el
6. Külföldi vásárlás szóba jöhet-e (EU raktárból, plusz költség nélkül)?
7. Mennyi pénz lenne a vásárlásra?
8. WiFi-s kamerát szeretnél (alapból vezetékest ajánlunk)?
9. Egyéb extra igény (pl forgatható, színes éjjeli kép)? -
zebra_hun
veterán
Az első fele lesz a lényeg neked, V/F Offset:
[2023/11/24 13:40:58]
Ai Overclock Tuner [Auto]
Intel(R) Adaptive Boost Technology [Auto]
ASUS MultiCore Enhancement [Auto – Lets BIOS Optimize]
SVID Behavior [Auto]
BCLK Frequency : DRAM Frequency Ratio [100:100]
Memory Controller : DRAM Frequency Ratio [1:2]
DRAM Frequency [DDR5-6800MHz]
Performance Core Ratio [By Core Usage]
1-Core Ratio Limit [58]
2-Core Ratio Limit [58]
3-Core Ratio Limit [57]
4-Core Ratio Limit [57]
5-Core Ratio Limit [56]
6-Core Ratio Limit [56]
7-Core Ratio Limit [55]
8-Core Ratio Limit [55]
Performance Core0 Specific Ratio Limit [Auto]
Performance Core0 specific Voltage [Auto]
Performance Core1 Specific Ratio Limit [Auto]
Performance Core1 specific Voltage [Auto]
Performance Core2 Specific Ratio Limit [Auto]
Performance Core2 specific Voltage [Auto]
Performance Core3 Specific Ratio Limit [Auto]
Performance Core3 specific Voltage [Auto]
*Performance Core4 Specific Ratio Limit [Auto]
Performance Core4 specific Voltage [Auto]
*Performance Core5 Specific Ratio Limit [Auto]
Performance Core5 specific Voltage [Auto]
Performance Core6 Specific Ratio Limit [Auto]
Performance Core6 specific Voltage [Auto]
Performance Core7 Specific Ratio Limit [Auto]
Performance Core7 specific Voltage [Auto]
Efficient Core Ratio [By Core Usage]
Efficient 1-Core Ratio Limit [44]
Efficient 2-Core Ratio Limit [44]
Efficient 3-Core Ratio Limit [44]
Efficient 4-Core Ratio Limit [44]
Efficient 5-Core Ratio Limit [44]
Efficient 6-Core Ratio Limit [44]
Efficient 7-Core Ratio Limit [44]
Efficient 8-Core Ratio Limit [44]
Efficient Core Group0 Specific Ratio Limit [Auto]
Efficient Core Group0 specific Voltage [Auto]
Efficient Core Group1 Specific Ratio Limit [Auto]
Efficient Core Group1 specific Voltage [Auto]
AVX2 [Auto]
AVX2 Ratio Offset to per-core Ratio Limit [Auto]
AVX2 Voltage Guardband Scale Factor [Auto]
Maximus Tweak [Mode 2]
DRAM CAS# Latency [32]
DRAM RAS# to CAS# Delay Read [40]
DRAM RAS# to CAS# Delay Write [40]
DRAM RAS# PRE Time [36]
DRAM RAS# ACT Time [52]
DRAM Command Rate [2N]
DRAM RAS# to RAS# Delay L [8]
DRAM RAS# to RAS# Delay S [8]
DRAM REF Cycle Time 2 [400]
DRAM REF Cycle Time Same Bank [Auto]
DRAM Refresh Interval [171072]
DRAM WRITE Recovery Time [16]
DRAM READ to PRE Time [12]
DRAM FOUR ACT WIN Time [16]
DRAM WRITE to READ Delay L [Auto]
DRAM WRITE to READ Delay S [Auto]
DRAM CKE Minimum Pulse Width [14]
DRAM Write Latency [30]
Ctl0 dqvrefup [Auto]
Ctl0 dqvrefdn [Auto]
Ctl0 dqodtvrefup [Auto]
Ctl0 dqodtvrefdn [Auto]
Ctl1 cmdvrefup [Auto]
Ctl1 ctlvrefup [Auto]
Ctl1 clkvrefup [Auto]
Ctl1 ckecsvrefup [Auto]
Ctl2 cmdvrefdn [Auto]
Ctl2 ctlvrefdn [Auto]
Ctl2 clkvrefdn [Auto]
Read Equalization RxEq Start Sign [-]
Read Equalization RxEq Start [Auto]
Read Equalization RxEq Stop Sign [-]
Read Equalization RxEq Stop [Auto]
ODT_READ_DURATION [Auto]
ODT_READ_DELAY [Auto]
ODT_WRITE_DURATION [Auto]
ODT_WRITE_DELAY [Auto]
DQ RTT WR [Auto]
DQ RTT NOM RD [Auto]
DQ RTT NOM WR [Auto]
DQ RTT PARK [Auto]
DQ RTT PARK DQS [Auto]
GroupA CA ODT [Auto]
GroupA CS ODT [Auto]
GroupA CK ODT [Auto]
GroupB CA ODT [Auto]
GroupB CS ODT [Auto]
GroupB CK ODT [Auto]
Pull-up Output Driver Impedance [Auto]
Pull-Down Output Driver Impedance [Auto]
DQ RTT WR [Auto]
DQ RTT NOM RD [Auto]
DQ RTT NOM WR [Auto]
DQ RTT PARK [Auto]
DQ RTT PARK DQS [Auto]
GroupA CA ODT [Auto]
GroupA CS ODT [Auto]
GroupA CK ODT [Auto]
GroupB CA ODT [Auto]
GroupB CS ODT [Auto]
GroupB CK ODT [Auto]
Pull-up Output Driver Impedance [Auto]
Pull-Down Output Driver Impedance [Auto]
Round Trip Latency Init Value MC0 CHA [Auto]
Round Trip Latency Max Value MC0 CHA [Auto]
Round Trip Latency Offset Value Mode Sign MC0 CHA [-]
Round Trip Latency Offset Value MC0 CHA [Auto]
Round Trip Latency Init Value MC0 CHB [Auto]
Round Trip Latency Max Value MC0 CHB [Auto]
Round Trip Latency Offset Value Mode Sign MC0 CHB [-]
Round Trip Latency Offset Value MC0 CHB [Auto]
Round Trip Latency Init Value MC1 CHA [Auto]
Round Trip Latency Max Value MC1 CHA [Auto]
Round Trip Latency Offset Value Mode Sign MC1 CHA [-]
Round Trip Latency Offset Value MC1 CHA [Auto]
Round Trip Latency Init Value MC1 CHB [Auto]
Round Trip Latency Max Value MC1 CHB [Auto]
Round Trip Latency Offset Value Mode Sign MC1 CHB [-]
Round Trip Latency Offset Value MC1 CHB [Auto]
Round Trip Latency MC0 CHA R0 [Auto]
Round Trip Latency MC0 CHA R1 [Auto]
Round Trip Latency MC0 CHA R2 [Auto]
Round Trip Latency MC0 CHA R3 [Auto]
Round Trip Latency MC0 CHA R4 [Auto]
Round Trip Latency MC0 CHA R5 [Auto]
Round Trip Latency MC0 CHA R6 [Auto]
Round Trip Latency MC0 CHA R7 [Auto]
Round Trip Latency MC0 CHB R0 [Auto]
Round Trip Latency MC0 CHB R1 [Auto]
Round Trip Latency MC0 CHB R2 [Auto]
Round Trip Latency MC0 CHB R3 [Auto]
Round Trip Latency MC0 CHB R4 [Auto]
Round Trip Latency MC0 CHB R5 [Auto]
Round Trip Latency MC0 CHB R6 [Auto]
Round Trip Latency MC0 CHB R7 [Auto]
Round Trip Latency MC1 CHA R0 [Auto]
Round Trip Latency MC1 CHA R1 [Auto]
Round Trip Latency MC1 CHA R2 [Auto]
Round Trip Latency MC1 CHA R3 [Auto]
Round Trip Latency MC1 CHA R4 [Auto]
Round Trip Latency MC1 CHA R5 [Auto]
Round Trip Latency MC1 CHA R6 [Auto]
Round Trip Latency MC1 CHA R7 [Auto]
Round Trip Latency MC1 CHB R0 [Auto]
Round Trip Latency MC1 CHB R1 [Auto]
Round Trip Latency MC1 CHB R2 [Auto]
Round Trip Latency MC1 CHB R3 [Auto]
Round Trip Latency MC1 CHB R4 [Auto]
Round Trip Latency MC1 CHB R5 [Auto]
Round Trip Latency MC1 CHB R6 [Auto]
Round Trip Latency MC1 CHB R7 [Auto]
Early Command Training [Disabled]
SenseAmp Offset Training [Disabled]
Early ReadMPR Timing Centering 2D [Auto]
Read MPR Training [Auto]
Receive Enable Training [Auto]
Jedec Write Leveling [Auto]
Early Write Time Centering 2D [Auto]
Early Read Time Centering 2D [Auto]
Write Timing Centering 1D [Auto]
Write Voltage Centering 1D [Auto]
Read Timing Centering 1D [Auto]
Read Timing Centering with JR [Auto]
Dimm ODT Training* [Enabled]
Max RTT_WR [ODT Off]
DIMM RON Training* [Auto]
Write Drive Strength/Equalization 2D* [Enabled]
Write Slew Rate Training* [Auto]
Read ODT Training* [Auto]
Comp Optimization Training [Auto]
Read Equalization Training* [Auto]
Read Amplifier Training* [Auto]
Write Timing Centering 2D [Auto]
Read Timing Centering 2D [Auto]
Command Voltage Centering [Auto]
Early Command Voltage Centering [Auto]
Write Voltage Centering 2D [Auto]
Read Voltage Centering 2D [Auto]
Late Command Training [Enabled]
Round Trip Latency [Enabled]
Turn Around Timing Training [Auto]
CMD CTL CLK Slew Rate [Auto]
CMD/CTL DS & E 2D [Enabled]
Read Voltage Centering 1D [Auto]
TxDqTCO Comp Training* [Auto]
ClkTCO Comp Training* [Auto]
TxDqsTCO Comp Training* [Auto]
VccDLL Bypass Training [Auto]
CMD/CTL Drive Strength Up/Dn 2D [Auto]
DIMM CA ODT Training [Auto]
PanicVttDnLp Training* [Auto]
Read Vref Decap Training* [Auto]
Vddq Training [Enabled]
Duty Cycle Correction Training [Auto]
Periodic DCC [Auto]
Rank Margin Tool Per Bit [Auto]
DIMM DFE Training [Enabled]
EARLY DIMM DFE Training [Auto]
Tx Dqs Dcc Training [Auto]
DRAM DCA Training [Auto]
Write Driver Strength Training [Auto]
Rank Margin Tool [Auto]
Memory Test [Auto]
DIMM SPD Alias Test [Auto]
Receive Enable Centering 1D [Auto]
Retrain Margin Check [Auto]
Write Drive Strength Up/Dn independently [Auto]
LPDDR DqDqs Re-Training [Auto]
Margin Check Limit [Disabled]
tRDRD_sg_Training [14]
tRDRD_sg_Runtime [14]
tRDRD_dg_Training [7]
tRDRD_dg_Runtime [7]
tRDWR_sg [18]
tRDWR_dg [18]
tWRWR_sg [12]
tWRWR_dg [7]
tWRRD_sg [58]
tWRRD_dg [44]
tRDRD_dr [0]
tRDRD_dd [0]
tRDWR_dr [0]
tRDWR_dd [0]
tWRWR_dr [0]
tWRWR_dd [0]
tWRRD_dr [0]
tWRRD_dd [0]
tRPRE [Auto]
tWPRE [Auto]
tWPOST [Auto]
tWRPRE [Auto]
tPRPDEN [Auto]
tRDPDEN [Auto]
tWRPDEN [Auto]
tCPDED [Auto]
tREFIX9 [Auto]
Ref Interval [Auto]
tXPDLL [Auto]
tXP [Auto]
tPPD [0]
tCCD_L_tDLLK [Auto]
tZQCAL [Auto]
tZQCS [Auto]
OREF_RI [Auto]
Refresh Watermarks [High]
Refresh Hp Wm [Auto]
Refresh Panic Wm [Auto]
Refresh Abr Release [Auto]
tXSDLL [Auto]
tZQOPER [Auto]
tMOD [Auto]
CounttREFIWhileRefEn [Auto]
HPRefOnMRS [Auto]
SRX Ref Debits [Auto]
RAISE BLK WAIT [Auto]
Ref Stagger En [Auto]
Ref Stagger Mode [Auto]
Disable Stolen Refresh [Auto]
En Ref Type Display [Auto]
Trefipulse Stagger Disable [Auto]
tRPab ext [Auto]
derating ext [Auto]
Allow 2cyc B2B LPDDR [Auto]
tCSH [Auto]
tCSL [Auto]
powerdown Enable [Auto]
idle length [Auto]
raise cke after exit latency [Auto]
powerdown latency [Auto]
powerdown length [Auto]
selfrefresh latency [Auto]
selfrefresh length [Auto]
ckevalid length [Auto]
ckevalid enable [Auto]
idle enable [Auto]
selfrefresh enable [Auto]
Address mirror [Auto]
no gear4 param divide [Auto]
x8 device [Auto]
no gear2 param divide [Auto]
ddr 1dpc split ranks on subch [Auto]
write0 enable [Auto]
MultiCycCmd [Auto]
WCKDiffLowInIdle [Auto]
PBR Disable [Auto]
PBR OOO Dis [Auto]
PBR Disable on hot [Auto]
PBR Exit on Idle Cnt [Auto]
tXSR [Auto]
Dec tCWL [Auto]
Add tCWL [Auto]
Add 1Qclk delay [Auto]
MRC Fast Boot [Enabled]
MCH Full Check [Auto]
Mem Over Clock Fail Count [2]
Training Profile [ASUS User Profile]
RxDfe [Auto]
Mrc Training Loop Count [2]
DRAM CLK Period [Auto]
Dll_bwsel [Auto]
Controller 0, Channel 0 Control [Enabled]
Controller 0, Channel 1 Control [Enabled]
Controller 1, Channel 0 Control [Enabled]
Controller 1, Channel 1 Control [Enabled]
MC_Vref0 [Auto]
MC_Vref1 [Auto]
MC_Vref2 [Auto]
Fine Granularity Refresh mode [Auto]
SDRAM Density Per Die [Auto]
SDRAM Banks Per Bank Group [Auto]
SDRAM Bank Groups [Auto]
Dynamic Memory Boost [Disabled]
Realtime Memory Frequency [Disabled]
SA GV [Disabled]
Voltage Monitor [Die Sense]
VRM Initialization Check [Enabled]
CPU Input Voltage Load-line Calibration [Auto]
CPU Load-line Calibration [Level 5]
Synch ACDC Loadline with VRM Loadline [Disabled]
CPU Current Capability [Auto]
CPU Current Reporting [Auto]
Core Voltage Suspension [Auto]
CPU VRM Switching Frequency [Auto]
VRM Spread Spectrum [Disabled]
CPU Power Duty Control [Extreme]
CPU Power Phase Control [Standard]
CPU Power Thermal Control [125]
CPU Core/Cache Boot Voltage [Auto]
CPU Input Boot Voltage [Auto]
PLL Termination Boot Voltage [Auto]
CPU Standby Boot Voltage [Auto]
Memory Controller Boot Voltage [Auto]
CPU Core Auto Voltage Cap [Auto]
CPU Input Auto Voltage Cap [Auto]
Memory Controller Auto Voltage Cap [Auto]
Maximum CPU Core Temperature [Auto]
Package Temperature Threshold [Auto]
Regulate Frequency by above Threshold [Auto]
IVR Transmitter VDDQ ICCMAX [Auto]
Unlimited ICCMAX [Auto]
CPU Core/Cache Current Limit Max. [Auto]
Long Duration Package Power Limit [200]
Package Power Time Window [48]
Short Duration Package Power Limit [220]
Dual Tau Boost [Disabled]
IA AC Load Line [0.01]
IA DC Load Line [0.82]
IA CEP Enable [Auto]
SA CEP Enable [Auto]
IA SoC Iccmax Reactive Protector [Auto]
Inverse Temperature Dependency Throttle [Auto]
IA VR Voltage Limit [Auto]
CPU SVID Support [Auto]
Cache Dynamic OC Switcher [Disabled]
TVB Voltage Optimizations [Disabled]
Enhanced TVB [Disabled]
Overclocking TVB [Disabled]
Overclocking TVB Global Temperature Offset Sign [+]
Overclocking TVB Global Temperature Offset Value [Auto]
Offset Mode Sign 1 [-]
V/F Point 1 Offset [0.02000]
Offset Mode Sign 2 [-]
V/F Point 2 Offset [0.02000]
Offset Mode Sign 3 [-]
V/F Point 3 Offset [0.02000]
Offset Mode Sign 4 [-]
V/F Point 4 Offset [0.04000]
Offset Mode Sign 5 [-]
V/F Point 5 Offset [0.04000]
Offset Mode Sign 6 [-]
V/F Point 6 Offset [0.07000]
Offset Mode Sign 7 [-]
V/F Point 7 Offset [0.07000]
Offset Mode Sign 8 [-]
V/F Point 8 Offset [0.07000]
Offset Mode Sign 9 [-]
V/F Point 9 Offset [0.07000]
Offset Mode Sign 10 [-]
V/F Point 10 Offset [0.07000]
Offset Mode Sign 11 [-]
V/F Point 11 Offset [0.07000]
Initial BCLK Frequency [Auto]
Runtime BCLK OC [Auto]
BCLK Amplitude [Auto]
BCLK Slew Rate [Auto]
BCLK Spread Spectrum [Auto]
Initial PCIE Frequency [Auto]
PCIE/DMI Amplitude [Auto]
PCIE/DMI Slew Rate [Auto]
PCIE/DMI Spread Spectrum [Auto]
Cold Boot PCIE Frequency [Auto]
Realtime Memory Timing [Enabled]
SPD Write Disable [TRUE]
PVD Ratio Threshold [Auto]
SA PLL Frequency Override [Auto]
BCLK TSC HW Fixup [Enabled]
Core Ratio Extension Mode [Disabled]
FLL OC mode [Auto]
UnderVolt Protection [Disabled]
Switch Microcode [Current Microcode]
Xtreme Tweaking [Disabled]
Core PLL Voltage [Auto]
GT PLL Voltage [Auto]
Ring PLL Voltage [Auto]
System Agent PLL Voltage [Auto]
Memory Controller PLL Voltage [Auto]
Efficient-core PLL Voltage [Auto]
CPU 1.8V Small Rail [Auto]
PLL Termination Voltage [Auto]
CPU Standby Voltage [Auto]
PCH 1.05V Voltage [Auto]
PCH 0.82V Voltage [Auto]
CPU Input Voltage Reset Voltage [Auto]
Eventual CPU Input Voltage [Auto]
Eventual Memory Controller Voltage [Auto]
Package Temperature Threshold [Auto]
Regulate Frequency by above Threshold [Auto]
Cooler Efficiency Customize [Keep Training]
Cooler Re-evaluation Algorithm [Normal]
Optimism Scale [100]
Ring Down Bin [Auto]
Min. CPU Cache Ratio [8]
Max. CPU Cache Ratio [49]
BCLK Aware Adaptive Voltage [Auto]
Actual VRM Core Voltage [Auto]
Global Core SVID Voltage [Auto]
Cache SVID Voltage [Auto]
CPU L2 Voltage [Auto]
CPU System Agent Voltage [Manual Mode]
- CPU System Agent Voltage Override [1.10000]
CPU Input Voltage [Auto]
High DRAM Voltage Mode [Auto]
DRAM VDD Voltage [1.39000]
DRAM VDDQ Voltage [1.37000]
IVR Transmitter VDDQ Voltage [1.23000]
Memory Controller Voltage [1.20625]
MC Voltage Calculation Voltage Base [Auto]
VDD Calculation Voltage Base [Auto]
PMIC Voltages [Auto]
PCI Express Native Power Management [Enabled]
Native ASPM [Disabled]
DMI Link ASPM Control [Disabled]
ASPM [Auto]
L1 Substates [Disabled]
DMI ASPM [Disabled]
DMI Gen3 ASPM [Disabled]
PEG - ASPM [Disabled]
PCI Express Clock Gating [Enabled]
Hardware Prefetcher [Enabled]
Adjacent Cache Line Prefetch [Enabled]
Intel (VMX) Virtualization Technology [Disabled]
Per P-Core Control [Disabled]
Per E-Core Control [Disabled]
Active Performance Cores [All]
Active Efficient Cores [All]
Hyper-Threading [Enabled]
Hyper-Threading of Core 0 [Enabled]
Hyper-Threading of Core 1 [Enabled]
Hyper-Threading of Core 2 [Enabled]
Hyper-Threading of Core 3 [Enabled]
Hyper-Threading of Core 4 [Enabled]
Hyper-Threading of Core 5 [Enabled]
Hyper-Threading of Core 6 [Enabled]
Hyper-Threading of Core 7 [Enabled]
Total Memory Encryption [Disabled]
Legacy Game Compatibility Mode [Disabled]
Boot performance mode [Auto]
Intel(R) SpeedStep(tm) [Enabled]
Intel(R) Speed Shift Technology [Enabled]
Intel(R) Turbo Boost Max Technology 3.0 [Enabled]
Turbo Mode [Enabled]
Acoustic Noise Mitigation [Disabled]
CPU C-states [Auto]
Thermal Monitor [Enabled]
Dual Tau Boost [Disabled]
VT-d [Disabled]
Memory Remap [Enabled]
Enable VMD controller [Enabled]
Map PCIE Storage under VMD [Disabled]
Map SATA Controller under VMD [Disabled]
M.2_1 Link Speed [Auto]
PCIEX16(G5)_1 Link Speed [Auto]
PCIEX16(G5)_2 Link Speed [Auto]
PCIEX1(G4) Link Speed [Auto]
PCIEX4(G4) Link Speed [Auto]
M.2_2 Link Speed [Auto]
DIMM.2_1 Link Speed [Auto]
DIMM.2_2 Link Speed [Auto]
SATA Controller(s) [Enabled]
Aggressive LPM Support [Disabled]
SMART Self Test [Enabled]
M.2_3 [Enabled]
M.2_3 Hot Plug [Disabled]
SATA6G_1 [Enabled]
SATA6G_1 Hot Plug [Disabled]
SATA6G_2 [Enabled]
SATA6G_2 Hot Plug [Disabled]
SATA6G_3 [Enabled]
SATA6G_3 Hot Plug [Disabled]
SATA6G_4 [Enabled]
SATA6G_4 Hot Plug [Disabled]
PTT [Enable]
Intel(R) Dynamic Tuning Technology [Disabled]
PCIE Tunneling over USB4 [Enabled]
Discrete Thunderbolt(TM) Support [Disabled]
Security Device Support [Enable]
SHA256 PCR Bank [Enabled]
Pending operation [None]
Platform Hierarchy [Enabled]
Storage Hierarchy [Enabled]
Endorsement Hierarchy [Enabled]
Physical Presence Spec Version [1.3]
Disable Block Sid [Disabled]
Password protection of Runtime Variables [Enable]
Above 4G Decoding [Enabled]
Resize BAR Support [Enabled]
SR-IOV Support [Disabled]
Legacy USB Support [Enabled]
XHCI Hand-off [Enabled]
SanDisk [Auto]
LAN_U32G2_1 [Enabled]
U32G1_E5 [Enabled]
U32G1_E6 [Enabled]
U32G1_E7 [Enabled]
U32G1_E8 [Enabled]
U32G2X2_C3 [Enabled]
U32G2_5 [Enabled]
U32G2_6 [Enabled]
U32G2_7 [Enabled]
U32G2_P8 [Enabled]
U32G2X2_C9 [Enabled]
U32G1_E1 [Enabled]
U32G1_E2 [Enabled]
U32G1_E3 [Enabled]
U32G1_E4 [Enabled]
Network Stack [Disabled]
Device [N/A]
Restore AC Power Loss [Power Off]
Max Power Saving [Disabled]
ErP Ready [Disabled]
Power On By PCI-E [Disabled]
Power On By RTC [Disabled]
USB Audio [Enabled]
Intel LAN [Enabled]
USB power delivery in Soft Off state (S5) [Disabled]
Connectivity mode (Wi-Fi & Bluetooth) [Disabled]
When system is in working state [All On]
Q-Code LED Function [Auto]
When system is in sleep, hibernate or soft off states [All On]
M.2_2 Configuration [Auto]
ASMedia USB 3.2 Controller_U32G1_E12 [Enabled]
ASMedia USB 3.2 Controller_U32G1_E34 [Enabled]
GNA Device [Disabled]
ASMedia Storage Controller [Enabled]
Windows Hot-plug Notification [Disabled]
ASPM Support [Disabled]
CPU Temperature [Monitor]
CPU Package Temperature [Monitor]
MotherBoard Temperature [Monitor]
VRM Temperature [Monitor]
Chipset Temperature [Monitor]
T_Sensor Temperature [Monitor]
DIMM.2 Sensor 1 Temperature [Monitor]
DIMM.2 Sensor 2 Temperature [Monitor]
Water In T Sensor Temperature [Monitor]
Water Out T Sensor Temperature [Monitor]
DIMM A1 Temperature [Monitor]
DIMM B1 Temperature [Monitor]
CPU Fan Speed [Monitor]
CPU Optional Fan Speed [Monitor]
Chassis Fan 1 Speed [Monitor]
Chassis Fan 2 Speed [Monitor]
Chassis Fan 3 Speed [Monitor]
Water Pump+ Speed [Monitor]
AIO Pump Speed [Monitor]
Flow Rate [Monitor]
CPU Core Voltage [Monitor]
12V Voltage [Monitor]
5V Voltage [Monitor]
3.3V Voltage [Monitor]
Memory Controller Voltage [Monitor]
CPU Fan Q-Fan Control [DC Mode]
CPU Fan Profile [Silent]
CPU Fan Q-Fan Source [CPU]
CPU Fan Step Up [Level 0]
CPU Fan Step Down [Level 0]
CPU Fan Speed Low Limit [200 RPM]
Chassis Fan 1 Q-Fan Control [Auto Detect]
Chassis Fan 1 Profile [Standard]
Chassis Fan 1 Q-Fan Source [CPU]
Chassis Fan 1 Step Up [Level 0]
Chassis Fan 1 Step Down [Level 0]
Chassis Fan 1 Speed Low Limit [200 RPM]
Chassis Fan 2 Q-Fan Control [Auto Detect]
Chassis Fan 2 Profile [Standard]
Chassis Fan 2 Q-Fan Source [CPU]
Chassis Fan 2 Step Up [Level 0]
Chassis Fan 2 Step Down [Level 0]
Chassis Fan 2 Speed Low Limit [200 RPM]
Chassis Fan 3 Q-Fan Control [DC Mode]
Chassis Fan 3 Profile [Silent]
Chassis Fan 3 Q-Fan Source [CPU]
Chassis Fan 3 Step Up [Level 0]
Chassis Fan 3 Step Down [Level 0]
Chassis Fan 3 Speed Low Limit [200 RPM]
Water Pump+ Q-Fan Control [PWM Mode]
Water Pump+ Profile [Manual]
Water Pump+ Q-Fan Source [CPU]
Water Pump+ Step Up [Level 0]
Water Pump+ Step Down [Level 4]
Water Pump+ Speed Low Limit [Ignore]
Water Pump+ Point4 Temperature [75]
Water Pump+ Point4 Duty Cycle (%) [100]
Water Pump+ Point3 Temperature [60]
Water Pump+ Point3 Duty Cycle (%) [85]
Water Pump+ Point2 Temperature [45]
Water Pump+ Point2 Duty Cycle (%) [75]
Water Pump+ Point1 Temperature [25]
Water Pump+ Point1 Duty Cycle (%) [60]
AIO Pump Q-Fan Control [Auto Detect]
AIO Pump Profile [Full Speed]
CPU Temperature LED Switch [Enabled]
Launch CSM [Disabled]
OS Type [Other OS]
Secure Boot Mode [Custom]
Fast Boot [Enabled]
Next Boot after AC Power Loss [Fast Boot]
Boot Logo Display [Auto]
POST Delay Time [3 sec]
Bootup NumLock State [On]
Wait For 'F1' If Error [Enabled]
Option ROM Messages [Force BIOS]
Interrupt 19 Capture [Disabled]
AMI Native NVMe Driver Support [Enabled]
Setup Mode [Advanced Mode]
Boot Sector (MBR/GPT) Recovery Policy [Local User Control]
Next Boot Recovery Action [Skip]
BIOS Image Rollback Support [Enabled]
Publish HII Resources [Disabled]
Flexkey [Reset]
Setup Animator [Disabled]
Load from Profile [3]
Profile Name [6800CL32]
Save to Profile [3]
DIMM Slot Number [DIMM_A1]
Download & Install ARMOURY CRATE app [Enabled]
Download & Install MyASUS service & app [Disabled] -
vacs
veterán
Reklámmentes Youtube Chromecast with Google TV-n: SmartTube app!Telefonon Github-ról töltsd le a latest stable apk-t: [link]
A letöltött smarttube_stable.apk-t küldd át a Chromecast with Google TV-re: link1 vagy link2 és telepítsd!
Visszalépve a főképernyőre ott lesz a SmartTube ikon a sor végén (a gyári youtube akár törölhető is).
Pár hetente/havonta a SmartTube app indításkor egy felugró ablakban tájékoztat, hogy frissítés érhető el, ekkor nyomj a telepítés gombra és mindent megcsinál magától egy perc alatt! -
vacs
veterán
Play Store ikon elhelyezése a főképernyőn, Chromecast with Google TV-n!
Androidos telefonon tesztelve!1. Fejlesztői beállítások engedélyezése:
Chromecast beállítások > rendszer > névjegy > Android os tv build sorra kattintsunk addig, míg ki nem írja, hogy Ön mostantól fejlesztő!
Videós segítség itt.2. Indítsuk el a Play Áruházat:
Chromecast beállítások, alkalmazások, összes alkalmazás, Rendszer alkalmazások megjelenítése, Google Play Áruház.
3.1 Keresd meg és telepítsd fel a Send files to TV app-ot!
3.2 Keresd meg a Cx File Explorer appot (vagy bármelyik fájlkezelőt) és telepítsd fel!
4. Telefonra is telepítsd fel a Send files to TV app-ot!5. Telefonra letöltöd xda-ról a Play Áruház parancsikonját! [link]
Fontos: a telefon és a Chromecast azonos wifi hálózaton legyen!
6.1 Indítsd el a Send files to TV appot Chromecast-en és válaszd a Receive opciót!
6.2 Indítsd el a Send files to TV appot telefonodon és válaszd a Send opciót!
6.3 Telefonon válaszd ki a korábban letöltött Play_Store_ATV_Shortcut.apk-t és küldd át!
Videós segítség itt7. Ismeretlen források engedélyezése:
Chromecast beállítások > alkalmazások > biztonság és korlátozások > ismeretlen források8. Indítsd el Chromecast-en a korábban letöltött Cx File Explorer fájlkezelőt és telepítsd a Play_Store_ATV_Shortcut.apk-t.
Visszalépve a főképernyőre ott lesz a Play Store ikon a sor végén.
by vacs -
szaszlaci
addikt
KTL-1 HiVi "szélessávú" mélyközéphangszóró, exponenciális tölcsér és transmission line keresztezett doboztípusban. Akai ortodinamikus magassugárzóval, részben mechanikus hangváltóval.
Valódi mérések az aktuális dobozról:
Átvitel
Hangszórók válogatás utáni hasonlósága
Kész hangsugárzó impedanciamenete illetve hasonlósága
-
Az új Topikot a Logoszférába kell nyitnom?
Ne ott nyisd a topikot! Az elkészült topikok fejezeteit rakd be Logoszférás topikba. Itt egy példa:
ez egy szaktopik: Linux kezdőknek Ha bemész az Összefoglalóba és a Leírások, ismertetők részben rákattintasz mondjuk az elsőre, akkor egy Linuxos topikok Összefoglalójának szerkesztése nevű Logoszféra topikba visz, az alaptopikban már nem is én vagyok Tg, de magát a fejezetet itt tudom szerkeszteni:
Mik azok a disztribúciók, mi a különbség az "asztali" és az egyéb disztrók között
Egyszóval ha csinálsz egy fix topikot és nem leszel ott Tg, a Logoszféra-ban a fejezeteknek létrehozott topikban mindig tudod szerkeszteni az így linkelt tartalmat. Mindenképpen a Logoszférás topikban kell legalább a linkelendő fejezeteket létrehoznod...
-
RR-13
őstag
válasz
Oldman2
#13320
üzenetére
Köszi ezt nem tudtam, akkor majd lehet, hogy ez lesz.
Korábban Topikgazda voltam, és ott a Bank Topikban tudtam szerkeszteni egyből, de most csak bemásoltatni tudom, kérés után.
Te most is Topikgazda vagy, igaz máshol, nem ezért tudsz szerkeszteni itt mindent?
Most, ha nyitok egy új Topikot, akkor abban csak az 1db Hsz-em lesz mindig, amit szerkesztek?
Az új Topikot a Logoszférába kell nyitnom?
Köszi.
-
Oldman2
nagyúr
Azokat a legegyszerűbb a Fórum Logoszféra részén létrehozni és onnan linkelni vagy átmásolni a végleges helyre.
Ha itt hozol létre egy új témát, azt korlátlan ideig tudod szerkeszteni.
Pl. a Macrodroid Témaösszefoglalója is itt lett létrehozva.
Itt én, minden hozzászólást tudok máig is szerkeszteni, pedig a Téma 2018-ban lett létrehozva.
de birka vagyok...
-
- (meglévő arckép frissítés)-
Új hozzászólás Aktív témák
Hirdetés
- AMD K6-III, és minden ami RETRO - Oldschool tuning
- Építő/felújító topik
- Politika
- Gigantikus igényt adott le a H20 gyorsítóra több kínai cég
- Viber: ingyen telefonálás a mobilodon
- NVIDIA GeForce RTX 5070 / 5070 Ti (GB205 / 203)
- Ukrajnai háború
- Sweet.tv - internetes TV
- VR topik (Oculus Rift, stb.)
- Villanyszerelés
- További aktív témák...
- Hp Prodesk 600 G5/G6 SFF/ i5 8-9-10 gen, i7-9700 vagy "félkonfig"/ Win11- Számla, garancia
- Xiaomi Redmi Note 9 Pro 128GB, Kártyafüggetlen, 1 Év Garanciával
- Azonnali készpénzes Microsoft XBOX Series S és Series X felvásárlás személyesen/csomagküldéssel
- BESZÁMÍTÁS! MSI B450 R5 3600 16GB DDR4 512GB SSD RX 6500XT 4GB Zalman S2 TG Zalman 500W
- BESZÁMÍTÁS! Intel Arc B580 12GB Limited Edition videokártya garanciával hibátlan működéssel
Állásajánlatok
Cég: PCMENTOR SZERVIZ KFT.
Város: Budapest
Cég: Laptopszaki Kft.
Város: Budapest
