CPU support
Socket AM2/AM2+ Phenom X3, X4, Athlon X2, Sempron processors
4+1 phase PWM
North bridge
HD 3300 IGP(@700MHz) + 128MB/32bit DDR3-1333(@1066def.) sideport RAM + 128-512MB UMA
South bridge
Expansion slots3
2x PCI Express 2.0 x16 (2x8 in CrossFire)
3x PCI Express 2.0 x1
2x 32-bit/33MHz PCI
Memory
4x 240-pin DIMM sockets
Maximum of 8GB of DDR2-533/667/800/1067 SDRAM
Storage I/O
Floppy disk
1 channel ATA/133
6 channels 300MB/s Serial ATA with RAID 0, 1, 0+1, 5 support
Audio
8-channel HD audio via Realtek ALC889A codec
1x front out
1x analog bass/center out
1x analog rear out
1x analog surround out
1x analog line in
1x analog mic in
1x digital TOS-Link S/PDIF out
Ports
1x PS/2 keyboard
1x PS/2 mouse
4x USB 2.0 with headers for 8 more
1x RJ45 10/100/1000 via Realtek RTL8111C
1x 1394a Firewire via Texas Instruments TSB43AB23 with headers for 2 more
1x DVI out
1x VGA out
1x HDMI out
BIOS
Bus speeds
CPU base clock: 200-500MHz in 1MHz increments
PCIe: 100-200MHz in 1MHz increments
HT: 200-2600MHz in 200MHz increments
GPU: 200-2000MHz in 1MHz increments
Bus multipliers
CPU: 5-25X in 0.5X increments
Memory controller: 5-16X in 1X increments
DRAM: 2, 2.66, 3.3, 4, 5.33
Voltages
CPU: +/-0.6V in 0.025V increments
CPU NB: +/-0.6V in 0.025V increments
DRAM: +0.05-0.55V in 0.05V increments
NB: -0.2-+0.3V in 0.025V increments
SB: +0.1-0.3V in 0.1V increments
Sideport: +0.1-0.3V in 0.1V increments
